Vertical 480I Administrator's Manual

Sip ip phone
Hide thumbs Also See for 480I:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Quick Reference Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 480I and is the answer not in the manual?

Questions and answers

Related Manuals for Vertical 480I

Summary of Contents for Vertical 480I

  • Page 2: Software License Agreement

    SOFTWARE LICENSE AGREEMENT Aastra Telecom Inc., hereinafter known as "Seller", grants to Customer a personal, worldwide, non-transferable, non-sublicenseable and non-exclusive, restricted use license to use Software in object form solely with the Equipment for which the Software was intended. This Product may integrate programs, licensed to Aastra by third party Suppliers, for distribution under the terms of this agreement.

  • Page 3: Table Of Contents

    Overview... 1 General Requirements ... 1 About this Guide... 1 Methods of Installation... 2 480i IP Phone Set up... 2 The 480i’s Options List... 3 Administrator Level Options... 3 Network: ... 3 SIP Settings: ... 4 Phone Status: ... 5 The Vertical 480i Web Client...
  • Page 4 Limited Warranty ... 62 Exclusions ... 62 Warranty Repair Services ... 63 After Warranty Service ... 63...

  • Page 5: Overview

    Overview This SIP 480i IP Phone Administration Guide provides information on the basic network setup that is required for the SIP 480i IP phone. It also includes details on the functioning and configuration of the 480i phone. General Requirements • A SIP based IP PBX system or...

  • Page 6: Methods Of Installation

    Vertical 480i IP Phone Installation Guide. SIP 480i IP Phone Admin Guide 480i IP Phone Set up When the 480i is first plugged in or reset it will automatically download any firmware updates for the phone. The binary and configuration files that are required for the 480i are: “firmware.st”,...

  • Page 7: The 480I's Options List

    “22222”. For all other phone options, please refer to the Vertical 480i IP Phone Installation Guide. The administrator level options in the phone’s Options List are: • “8.Network” • “9.SIP Settings”...

  • Page 8: Sip Settings

    Registrar's database, and the phone’s screen displays "No Service". 6. User Name This is used in the name field of the SIP URI for the 480i phone This and for registering the 480i at the registrar. 7. Display Name...

  • Page 9: Phone Status

    • To re-load the configuration information modified through the configuration files to the phone, • If the settings for the 480i on the IP PBX system had been modified. 4. Factory Default This option lets you reset the...

  • Page 10: The Vertical 480I Web Client

    The Vertical 480i Web Client To access the Vertical 480i Web Client, open your web browser (supports Internet Explorer and Gecko engine based browsers like Firefox, Mozilla or Netscape) and enter the phone’s IP address into the address field, starting with the web prefix “http://”.

  • Page 11: 480I Ip Phone Configuration

    480i IP Phone Configuration The Network and SIP options within the 480i phone can be configured from the phone or from the Vertical 480i Web Client web interface. Some options can also be set through the configuration files. Administrator level options are password protected in both the phone and the web interface.

  • Page 12: From The Web Client

    Subnet Mask and the Gateway IP address in their corresponding fields. TFTP Server Settings The 480i phone uses the TFTP server to download updates firmware and configuration files. You must set the TFTP server address in the phone.
  • Page 13 At this point modifications performed to the User name, Screen name, NOTE: Authentication name and Password affect line 1 of the 480i only. Modifications to the other lines should be done through the <mac>.cfg file. From the Web Client: 1.

  • Page 14: Setting Parameters Through Configuration Files

    Setting Parameters through Configuration Files The following are the parameters that can be used to configure the 480i phone through the configuration files - aastra.cfg and <mac>.cfg. The "aastra.cfg" file configures the settings server wide, while the <mac> configures only the phones with the MAC address for which the file is named.

  • Page 15: Network Settings

    Enabling dhcp will populate most of the network information. The network information that the 480i requires should be served by the dhcp server. If the 480i is unable to get any required information then it should be entered manually. Parameters affected: ip...
  • Page 16 Parameter ip Configurable through the 480i's Options List, the Vertical 480i web client or through the configuration files Description This parameter assigns a static IP address to the 480i device. Format IP address 0.0.0.0 Default Value Not Applicable Range Example ip: 192.168.0.25...
  • Page 17 Description Primary domain name servers’ IP address. For any of the IP address settings on the 480i a domain name value can be entered instead of an IP address. With the help of the domain name servers the domain names for such parameters can then be resolved to their corresponding IP addresses.
  • Page 18 Configurable through the web client or the configuration files Description The administrator’s password that will be required to change the phone’s administrator level settings Format Numerals – maximum of 10 characters Default Value 22222 Range Not applicable Example admin password: 1675436 SIP 480i IP Phone Admin Guide...
  • Page 19 You may want to use this parameter to send RTP data using a different port. Format IP address Default Value 3000 Not Applicable Range Example sip rtp port: 5130 SIP 480i IP Phone Admin Guide 15...
  • Page 20 Description Flag indicating whether the phone will be reset to implement any config parameter changes if necessary. 0:off, 1: on. Format Integer Default Value Range 0 – 1 reset on config change: 1 Example SIP 480i IP Phone Admin Guide...

  • Page 21: Vlan And Tos/Qos: Type And Quality Of Service

    The parameters are case-sensitive. Parameter tos rtp Description DSCP value for RTP protocol Format Integer Default Value Default Priority Range 0-63 Example tos rtp: 2 PRIORITY Configurable through the configuration files only SIP 480i IP Phone Admin Guide 17...
  • Page 22 Default Value Default Priority Range Example priority non-ip: 5 SIP 480i IP Phone Admin Guide Configurable through the configuration files only Configurable through the configuration files only Configurable through the configuration files only (DSCP_2,priority_2). Configurable through the configuration files only...

  • Page 23: Setting Parameters - Time Server Settings

    Setting Parameters – Time Server Settings The following section contains the parameters to configure settings specific to the timeserver. Parameter time server Configurable through the 480i's Options List or the disabled configuration files Description This parameter enables or disables the time server. This parameter affects the time server1, time server2 and time server3 parameters.
  • Page 24 Parameter time server1 Configurable through the 480i's Options List or the configuration files. Description The primary time server's IP address. If the time server is enabled, the value for time server1 will be used to request the time from. Format...
  • Page 25 Parameter date format Configurable through the 480i's Options List or the configuration files This parameter allows the user to change the date to various Description formats. Format Integer Default Value Range Following table shows the format for the corresponding date...
  • Page 26 This parameter affects the dst start date and the dst start week parameters. Format Integer Default Value Range 0 or 1 dst start relative date: 1 Example SIP 480i IP Phone Admin Guide...
  • Page 27 The week in which the daylight savings time should come into effect. Information for this parameter will be automatically populated once the time server and time zone name are configured and found. Format Integer Default Value Range dst start week: 2 Example SIP 480i IP Phone Admin Guide 23...
  • Page 28 The month in which the daylight savings time should end. Description Information for this parameter will be automatically populated once the time server and time zone name are configured and found. Format Integer Default Value Range 1-12 Example dst end month: 10 SIP 480i IP Phone Admin Guide...
  • Page 29 The hour of the day in which the daylight savings time should end. Information for this parameter will be automatically populated once the time server and time zone name are configured and found. Format Integer Default Value Range 1-24 Example dst end hour: 4 SIP 480i IP Phone Admin Guide 25...

  • Page 30: Setting Parameters - Sip Settings

    Request - URI Format fully qualified host domain name or ip address Default Value Range Example sip outbound proxy: sip.proxy.com SIP 480i IP Phone Admin Guide • sip outbound proxy • sip proxy ip • sip proxy port •...
  • Page 31 Description A SIP registrar is a server that maintains the location information of the 480i phone. This parameter’s IP address will be the address of the registrar that the 480i will use to send REGISTER requests to. Format IP address Default Value 0.0.0.0...
  • Page 32 Configurable only through the configuration files. period Description The time in seconds that the 480i should use to send re- registration requests to the registrar. The value of this parameter will be used in the expires header field value in the SIP REGISTER request.
  • Page 33 480i's Options List or the Vertical 480i web client affect the first line only. The value for this parameter is used in the name field of the SIP URI for the 480i phone and for registering the 480i at the registrar. Text...
  • Page 34 Parameter sip lineN screen Configurable through the configuration files. Configurations done through the 480i's Options List or the Vertical 480i web name client affect the first line only. Description This is used to display text on the screen of the phone. You may want to set this parameter to display the phone user's name.
  • Page 35 (1), then the terminator of the dial plan is ‘. ‘ Format Boolean 0: false, 1: true Default Value 0 (false) Range 0 or 1 Example sip dial plan terminator: 1 SIP 480i IP Phone Admin Guide 31...
  • Page 36 Integer (0:RTP only, 1: SIP Info only, 2: both RTP and SIP info) Default Value Range Example sip dtmf method: 1 SIP 480i IP Phone Admin Guide Configurable through the configuration files only Configurable through the configuration files only This parameter sets the method by which DTMF signals...

  • Page 37: Sip Intercom Parameters

    SIP Intercom Parameters The following 3 parameters are used to configure the Intercom button functioning on the 480i. Intercom calls can be implemented either locally from the phone, or through the SIP server. If your server has a supported intercom feature, select the server-side implementation.

  • Page 38: Setting Parameters - Softkey Settings

    Setting parameters – Softkey Settings: Softkey Settings: This section describes the softkey parameters that can be configured on the 480i phone. There are twenty softkeys that can be configured. These parameters can be configured either from the aastra.cfg or the <mac>.cfg file, depending upon whether you wish the settings to be server wide (aastra.cfg) or phone-specific (<mac>.cfg).
  • Page 39 In the connected state, the first key displayed on the screen will be a Drop softkey, for disconnecting from calls. Meaning Same meaning as the keypad keys 500ms pause On-hook More__ SIP 480i IP Phone Admin Guide 35 position will...

  • Page 40: Softkey Parameters

    9 for the speeddial softkey type is suggested. N in the softkeyN label ranges from 1 to 20 Examples softkey1 label: "Line 9" softkey2 label: “411” SIP 480i IP Phone Admin Guide...

  • Page 41: Mapped Key Parameters

    Configurable through the configuration files only maps the redial key to a custom-defined value string <empty> Any alphanumeric string, except “#”, “””, less than 10 characters 1014 map redial key to: SIP 480i IP Phone Admin Guide 37...
  • Page 42 (note: the flash(!) DTMF is sent in the connected state only) SIP 480i IP Phone Admin Guide Configurable through the configuration files only maps the conference key to a custom defined value "!,a,,,b,,,#"...

  • Page 43: Firmware Upgrade

    You can download the firmware stored on the TFTP server in one of two ways, by either resetting the phone through the options list of the 480i or by activating a firmware download through the web client. Resetting the phone will force the...
  • Page 44 Figure 1 Figure 2 SIP 480i IP Phone Admin Guide...

  • Page 45: Troubleshooting

    USER main category. 2. Enter the administrator level user name prompted. On the web page that just opened click on the Reset button to reset the phone. will Recovery SIP 480i IP Phone Admin Guide 41 E.g. button to password when...
  • Page 46 SIP 480i IP Phone Admin Guide 6. Press the Cancel softkey to cancel the operation. How to reset a user’s password? If a 480i user has forgotten the password the following steps can be performed to reset the password. From the web client: 1.

  • Page 47: Appendix A: Sample Configuration Files

    Appendix A: Sample Configuration Files This section consists of the sample configuration files necessary to configure the 480i IP Phones. The general format is similar to configuration files used by several Unix-based programs. Any text following a number sign (#) on a line is considered to be a comment, unless the # is contained within double-quotes.
  • Page 48 3600 sip rtp port: 3000 3000. sip silence suppression: 2 SIP 480i IP Phone Admin Guide # DHCP enabled. # Eg. every 3600 seconds, a re-register # request is sent to the SIP server. # Eg. RTP packets are sent to port...
  • Page 49 # dialing behavior (in seconds) # 3 seconds is the default # Time server disabled. # Enable time server and enter at # least one time server IP address. # Currently set to time.nist.gov SIP 480i IP Phone Admin Guide 45...
  • Page 50 “<mac>.cfg” file. Notes: Currently, there are a maximum of 20 user definable softkeys that can be configured on the 480i phone. These can be set up through either of the 2 configuration files, depending on whether this is to be server wide ("aastra.cfg") or phone specific...
  • Page 51 DND. This softkey can be defined in the Idle or Connected state. = define a softkey as empty to create a blank softkey on the screen for the purpose of positioning of other softkeys. SIP 480i IP Phone Admin Guide 47...
  • Page 52 "NoCallWait" softkey7 value: *70 softkey8 type: speeddial softkey8 label: "StationID" softkey8 value: *0 softkey9 type: speeddial softkey9 label: "AnsrPhone" softkey9 value: *91 softkey10 type: speeddial softkey10 label: "AnsrWrkgrps" softkey10 value: *99 SIP 480i IP Phone Admin Guide...
  • Page 53 The phone automatically populates the name and value parameters for the Flash key. = define a programmable key as a DND key. The phone automatically populates the name and value parameters for the DND key. SIP 480i IP Phone Admin Guide 49...
  • Page 54 46 sip dial plan terminator: 1 sip dial plan: "X+." SIP 480i IP Phone Admin Guide # Using this parameter, phone will only use # pcma, pcmu and G729 # This parameter can be used to select one...
  • Page 55 "*66" #---------------------------------------------------------------------- For more information on parameters that can be set in the configuration files, please refer to your administration guide for Vertical 480i, Vertical 9133i or Vertical 9112i IP phone. #---------------------------------------------------------------------- SIP 480i IP Phone Admin Guide 51...
  • Page 56 This file contains sample configurations for the “<mac>.cfg” file. Please rename this file with the MAC address (with the dashes removed) of the specific 480i, 9133i or 9112i device that you want to configure, for example “00085d03059f.cfg”. Settings that have already appeared in “aastra.cfg” will be overridden by those in this file.
  • Page 57 Notes: Setting parameters for line 1 configures the 1 the 480i, 9133i and the one line on the 9112i. TeleVantage 7.0 does not currently support the multiple lines on the 480i and 9133i phones, so only line 1 need be configured.
  • Page 58 For the default softkey speed dials, please refer to the sample “aastra.cfg” file. Example User Specific Softkeys ------------------------------ Note: On Vertical 480i IP phones, softkeys 1 – 11 are predefined with TeleVantage system functions. Please refer to the sample “aastra.cfg” file for details. # softkey12 type: speeddial # softkey12 label: "Home"...
  • Page 59 # prgkey2 value: "9,16045551234" #---------------------------------------------------------------------- For more information on parameters that can be set in the configuration files, please refer to your administration guide for Vertical 480i, Vertical 9133i or Vertical 9112i IP phone. #---------------------------------------------------------------------- SIP 480i IP Phone Admin Guide 55...

  • Page 60: Appendix B: Tftp Server Set-Up

    All the firmware files should be in the file system root directory. Currently we do not support downloads from files present in sub- directories. Consult PumpKIN’s documentation if you need more information on how to set-up the TFTP server. SIP 480i IP Phone Admin Guide...

  • Page 61: Appendix C: Time Zone Names And Corresponding Codes

    Europe America America Europe America America Pacific Europe Australia Australia Australia Australia Australia Australia Australia Australia Australia Australia America Europe America Europe Europe Atlantic America America America America America America America America America SIP 480i IP Phone Admin Guide 57...
  • Page 62 CN-Beijing CO-Bogota CR-Costa Rica CU-Havana CY-Nicosia CZ-Prague DE-Berlin DK-Copenhagen DM-Dominica DO-Santo Domingo EE-Tallinn ES-Madrid ES-Canary FI-Helsinki FJ-Fiji FK-Stanley SIP 480i IP Phone Admin Guide Location America America America America America America Europe America America America America America America America America...
  • Page 63 Europe America America Europe America Europe Atlantic America Pacific America Asia America Europe America Europe Europe Europe Europe America Asia America America Europe Europe Europe Europe Europe Europe Europe America America Europe America SIP 480i IP Phone Admin Guide 59...
  • Page 64 PT-Madeira PT-Azores PY-Asuncion RO-Bucharest RU-Kaliningrad RU-Moscow RU-Samara RU-Yekaterinburg RU-Omsk RU-Novosibirsk RU-Krasnoyarsk RU-Irkutsk RU-Yakutsk RU-Vladivostok RU-Sakhalin RU-Magadan RU-Kamchatka SIP 480i IP Phone Admin Guide Location America America America America America America America America Europe Europe Pacific Pacific Pacific Pacific America America...
  • Page 65 US-Central US-Mountain US-Pacific US-Alaska US-Aleutian US-Hawaii UY-Montevideo VA-Vatican YU-Belgrade Location Asia Asia Europe Asia Europe Europe Europe America America Europe America Asia Europe America America America America America America America America Europe Europe SIP 480i IP Phone Admin Guide 61...

  • Page 66: Limited Warranty

    SIP 480i IP Phone Admin Guide Aastra Telecom shall not be liable for any incidental or consequential damages, including, but not limited to, loss,...

  • Page 67: Warranty Repair Services

    Repairs to this product may be NOTE: made only by the manufacturer and its authorized agents, or by others who are legally authorized. This restriction applies during and after the warranty period. Unauthorized repair will void the warranty. SIP 480i IP Phone Admin Guide 63...
  • Page 68 31 sip explicit mwi subscription, 29 sip intercom prefix code, 32 sip intercom type, 32 SIP 480i IP Phone Admin Guide sip lineN auth name, 27 sip lineN display name, 28 sip lineN mode, 27 sip lineN password, 27...
