Submenu
I/P MODE (picture delay
minimum)
LED BRIGHTNESS
RGB RANGE
DVI
26
Adjustment Using the Menus
Setting
Selects to set the delay by the
picture processing to the minimum
level when the interlace signal is
input.
*
• INTER-FIELD
: Mode for
giving precedence to the
picture quality. Performs
interpolation depending on
the movement of the images
between the fields. It takes
longer than the other setting
modes to process the
picture.
• FIELD MERGE: The
processing time is shorter.
Combines the lines in the
odd fields and even fields
alternately regardless of the
movement of images.
Suitable for viewing still
images.
• LINE DOUBLER: The
processing time is shorter.
Performs interpolation by
repeating each line in the
data receiving sequence
regardless of the field. As
the line flicker is displayed
in this mode, it is available
for checking the line flicker
of the telop work and so on.
• INTRA-FIELD: INTRA-FIELD
is only available for 1920 ×
1080 SDI signal input.
Mode to provide naturally
reproduced image and quick
picture processing. Performs
interpolation within the
fields. Suitable for 1920 ×
1080 SDI signal input.
*
When DISPLAY in WFM/ALM/
VECTOR SETTING is activated,
INTER-FIELD cannot be
selected.
Selects the brightness of the LED of
the buttons.
• HIGH: The LED becomes
brighter.
• LOW: The LED becomes darker.
Sets the black level and white level
for the RGB format of HDMI input.
• FULL: 0 (black level) to 255
(white level)
• LIMITED: 16 (black level) to
235 (white level)
Selects a format for DVI input
signal.
• PC: For RGB signal format
• VIDEO: For YP
P
signal
B
R
format
Submenu
Setting
SCREEN SAVER
Sets the screen saver function on or
off.
• ON: If a still image is displayed
• OFF: The screen saver function
FLICKER FREE
Set this to ON to enable view
images without flicker.
The ON setting will eliminate
flicker, but quick-moving images
may exhibit contours or an
afterimage.
For details, see "About the function
assigned to the function button"
(page 30).
SD PIXEL MAPPING
Selects SD picture size (pixels)
according to the input signal format
from the COMPOSITE IN
connector.
When picture signals in the size
of 720 × 576 (50i) (or 720 × 487
(60i)) are input
When picture signals in the size
of 702 × 576 (50i) (or 712 × 483
(60i)) or equivalent are input
for more than 10 minutes,
the brightness of the screen
is automatically decreased to
reduce burn-in. The screen
returns to normal brightness
when you input an image to
the unit or operate the
buttons on the front panel of
the unit. While the screen
saver is activated, the LED
of the selected input select
button flashes. (To decrease
the brightness of the LED,
see "LED BRIGHTNESS"
on page 26.) This is the
factory setting.
is deactivated.
Select 720 × 576 (or 720 ×
487). This is the default
setting.
When 702 × 576 (or 712 ×
483) is selected, all sides of
the input picture are cut off
by several pixels.
Select 702 × 576 (or 712 ×
483).
When 720 × 576 (or 720 ×
487) is selected, a black
border (of several pixels
wide) appears around the
input picture.
