Icom IC-706 Service Manual page 37

[PLL UNIT]
REF. ORDER
DESCRIPTION
NO.
NO.
C179
4030007010 S.CERAMIC
C1S08 CH lH 100D-T-A
C180 4030009470
S.CERAMIC C1S08 CH lH R75C-T-A
C181 4030006990
S.CERAMIC C1808 CH lH 080D-T-A
C182
4030006880 S.CERAMIC
C1608 JB lH 472K-T-A
C183
4030006880 S.CERAMIC
C1608 JB 1H 472K·T-A
C184 4030006860
S.CERAMIC C1608 JB lH 102K·T-A
C185 4030006850
S.CERAMIC C1608 JB lH 471K·T-A
C186
4510004990 ELECTROLlTtC
16 MV 100 HC
C188 4030006850 S.CERAMIC
C1608 JB lH 471K-T-A
C195
4030006880 S.CERAMtC C1608 JB lH 472K·T-A
C196 4030006880
S.CERAMIC C1608 JB 1H 472K-T-A
C197 4030006860 S.CERAMIC C1608 JB lH 102K-T-A
C198
4030007010 S.CERAMIC C1608 CH lH 100D-T-A
C200
4510005600 S.ELECTROLITIC ECEV1CS100SR
C201 4510005600
S.ELECTROLlTIC ECEVI CS 1OOSR
C202 4510005600 S.ELECTROLlTIC ECEV1CS100SR
C204
4030006980 S.CERAMtC
C1608 CH lH 070D-T-A
C205 4030006980
S.CERAMIC C1608 CH lH 070D-T-A
C206
4030007030 S.CERAMIC C1608 CH lH 150J-T-A
C207 4030006880
S.CERAMIC C1608 JB lH 472K·T-A
C212 4030006880 S.CERAMIC
C1608 JB 1H 472K-T-A
C213
4030006880 S.CERAMIC
C1608 JB lH 472K-T-A
C217
4030007030 S.CERAMtC C1608 CH lH 150J-T-A
C218 4030006990
S.CERAMIC C1608 CH lH 080D·T·A
C219 4030007030 S.CERAMIC
C1608 CH lH 150J-T-A
C220 4030006880 S.CERAMIC C1608 JB lH 472K-T-A
C223
4040000690 BARRIERLAYR UAT 08X 473K
C224 4510005000 ELECTROLITIC 16 MV 220 HC
C225
4030006680 S.CERAMIC C1608 JB lH 472K·T-A
C226 4030010070
S.CERAMIC C1608 X7S lC 104K-T-A
C227
4030010070 S.CERAMIC C1608 X7S lC 104K-T-A
C228
4030010070 S.CERAMIC
C1608 X7S lC 104K-T-A
C233 4030006880
S.CERAMIC C1608 JB lH 472K·T-A
C236
4510004590 ELECTROLlTIC 16 MV 470 HC
C237
4030006920 S.CERAMIC C1608 CH lH 010C·T·A
C238 4030006850 S.CERAMIC
C1608JB lH471K-T-A
C239 4030006850 S.CERAMIC C1608 JB lH 471K-T-A
C240
4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C241 4550006080
S.TANTALUM TEMSVB2 lC 106M-8L
C242 4550006080 S.TANTALUM
TEMSVB2 lC 106M-8L
C243
4040000690 BARRIERLAYR UAT08X473K
C244 4030006880 S.CERAMIC
C1608 JB 1H 472K-T-A
C245 4030006880
S.CERAMIC C1608 JB lH 472K-T-A
C246 4550000460
S.TANTALUM TESVA lC 105Ml-8L
C247 4030007100 S.CERAMIC C1608 CH lH 560J·T-A
C248
4030006880 S.CERAMIC C1608 JB 1H 472K·T-A
C249 4030007030 S.CERAMIC C1608 CH lH 150J-T-A
C250
4030006880 S.CERAMIC C1608 JB 1H 472K-T·A
C251 4030006880
S.CERAMIC C1608 JB lH 472K·T·A
C252 4030006880 S.CERAMIC C1608 JB lH 472K·T-A
C253
4030006880 S.CERAMIC C1608 JB lH 472K-T-A
C254 4030006880 S.CERAMIC C1608 JB lH 472K-T-A
C255
4030006880 S.CERAMIC C1608 JB lH 472K-T-A
C256 4030006880
S.CERAMIC C1608 JB lH 472K-T-A
C257 4030010070
S.CERAMIC C1608 X7S lC 104K-T·A
C258 4030010070
S.CERAMIC C1608 X7S lC 104K-T-A
C259
4030007050 S.CERAMIC C1608 CH lH 220J-T-A
C260 4030007050 S.CERAMIC C1608 CH lH 220J-T·A
C261 4030007050 S.CERAMIC C1608 CH lH 220J-T-A
RLI
6330001320 RELAY AHY103
Jl 6510018950 S.CONNECTOR B7B-PH-SM3·TB
J2 6510019070 S.CONNECTOR 52559-3092
J5 6510018960 S.CONNECTOR B2B-PH-SM3-TB
WSl
8600034620 CABLE
1691 POI *J04PL
WS2 8970022090
CABLE 1691 1.50 COAXIAL (3}/PL
EPI 0910045448
PCB B 4561H
[PA UNIT]
REF. ORDER
DESCRIPTION
NO. NO.
ICI 1110003970 S.lC IlPC1658G-E1
01
1590002020 TRANSISTOR MRF555
02 1590002260 TRANSISTOR MRF5015
05
1590001940 S.TRANSISTOR DTC144EETL
06 1590001870 S.TRANSISTOR
DTA114EE TL
07 1590001940 S.TRANSISTOR DTC144EETL
08
1590001940 S.TRANSISTOR DTC144EETL
09 1590001870 S.TRANSISTOR DTA114EETL
010 1590000680 S.TRANSISTOR
DTCl14EUT107
all
1590001940 S.TRANSISTOR DTC144EETL
012 1590001870
S.TRANSISTOR DTA114EE TL
014 1590001150 S.TRANSISTOR
UN9211(TX)
015
1540000250 S.TRANSISTOR 2S0999-T2 CK
016 1590002360 TRANSISTOR MRF581
017
1590001940 S.TRANSISTOR DTC144EETL
018 1590002280 FET MRF255
019
1590002280 FET MRF255
020 1590001940 S.TRANSISTOR DTC144EETL
021 1590001870 S.TRANSISTOR DTA114EETL
022
1590001940 S.TRANSISTOR DTC144EETL
023 1590001870
S.TRANSISTOR DTAl14EETL
024 1590001940 S.TRANSISTOR DTC144EETL
025
1590001940 S.TRANSISTOR DTC144EETL
01 1160000140
S.DIODE DAP222TL
02
1790000490 S.DIODE HSM88AS-TR
03 1790000490 S.DIODE
HSM88AS-TR
04 1710000730 S.DIODE M1809-Tl1
06
1790000450 S.DIODE MA862(TX}
07 1750000450 S.DIODE lSV265-TR
011 1160000140
S.DIODE DAP222TL
012 1790000700 DIODE
DSA3Al
013 1790000700 DIODE DSA3Al
014
1710000730 S.DIODE MI809-T11
015 1710000730 S.DIODE MI809-T11
016 1750000270 S.DIODE
lSS301 (TE85R}
017
1750000270 S.DIODE lSS301 (TE85R)
018
1750000520 S.DIODE DAN222TL
L3
6140002220 COIL LR-270 (TR6X3X2 3A9)
L4
6140003030 COIL LR-321B
L5 6140003040 COIL
LR-322B
L9
6140002030 COIL LR-230 (SK-l0M·15Y 120}
UO 6110001570 COIL LA-237
Ll1 6110002150 COIL LA-385
L12 6110002070
COIL LA-227
L13 6200004740
S.COIL NL 252018T-1R2J
L14
6200004740 S.COIL NL 252018T-l R2J
L16 6110002120 COIL LA-228
L17
6110002070 COIL LA-227
U8
6110002070 COIL LA-227
L19 6110002070 COIL LA-227
L20 6200004740 S.COIL NL 252018T-1R2J
L22
6200004740 S.COIL NL 252018T-l R2J
L25 6200002640
S.COIL NL 252018T-R15J
L26 6200002650 S.COIL NL 252018T-R18J
L27 6200004740 S.COIL NL 252018T-1R2J
L29 6150002780 COIL LS-295
L30
6150002780 COIL LS-295
L31 6200004740 S.COIL NL 252018T-1R2J
L33
6200004740 S.COIL NL 252018T-l R2J
L35 6200002410 S.COIL NL 252018T·056J
L37 6200003950 S.COIL HF50ACC 322513-T
L40
6200002420 S.COIL NL 252018T-o68J
L41
6200003590 S.COIL EXCCl3225Ul
L42
6180000900 COIL LAL03NA 101K
L43
6140003060 COIL LR-324
L44 6140003060 COIL LR-324
L45 6140000610 COIL LR-83
L46 6140003051 COIL
LR-323B
L48 6200002630 S.COIL NL 252018T-Rl0J
L49
6200002430 S.COIL NL 2520 18T-o82J
S.=Surface mount
5 -14
