TVS electronics RP-3200 User Manual page 41

Switch no. Function
MSW1-1 Power ON Info
MSW1-2 Buffer Size
MSW1-3 Busy Condition
MSW1-4 Receive Error
MSW1-5 CR Mode
MSW1-6 Reserved
MSW1-7 DSR Signal
MSW1-8 Init Signal
Switch no. Function
MSW1-1 Power ON Info
MSW1-2 Buffer Size
MSW1-3 Busy Condition
MSW1-4 Receive Error
MSW1-5 CR Mode
MSW1-6 Reserved
MSW1-7 DSR Signal
MSW1-8 Init Signal
MSW2-1 Reserved
MSW2-2 Auto Cutter
* MSW2-3 Spool Print
MSW2-4 Full Col Print
MSW2-5 Resume aft PE
MSW2-6 Reserved
MSW2-7 Reserved
MSW2-8 PNE Sensor
MSW3-1 Resume Cttr Err
MSW3-2 PE signal by PNE
MSW3-3 Parallel 31 Pin
MSW3-4 Reserved
MSW3-5 Reserved
MSW3-6 Reserved
MSW3-7 CBM1000 Mode
MSW3-8 Resume Open Err
MSW4-1 Reserved
MSW4-2 Reserved
MSW4-3 Feed&Cut at TOF
MSW4-4 Reserved
Note:
*: If print data is very dense, the print head is hot, data transmission is slow, or some other conditions,
the motor and printing may occasionally stop which causes white stripes in the printout. To print
high-density data, set MSW2-3 (Spool Print) to ON to reduce striping, although this increases the
time before printing starts.
For a serial interface, increase the transmission speed to prevent the motor from stopping.
OFF
Valid
4K bytes
Full/Err
Print" ?"
Ignored
Fixed
Invalid
Invalid
OFF
Valid
4K bytes
Full/Err
Print" ?"
Ignored
Fixed
Invalid
Invalid
—
Invalid
Invalid
LineFeed
Next
Fixed
Fixed
Valid
Valid
Valid
Valid
Fixed
Fixed
Fixed
Invalid
Close
Fixed
Fixed
Invalid
Fixed
-41-
ON
Not Send
45 bytes
Full
No Print
LF
—
Valid
Valid
ON
Not Send
45 bytes
Full
No Print
LF
—
Valid
Valid
Fixed
Valid
Valid
WaitData
Top
—
—
Invalid
Invalid
Invalid
Invalid
—
—
—
Valid
Command
—
—
Valid
—
