3.5 Partition for Paper Roll

Set the partition to the width of the paper roll you are loading.
The partition is set at the factory to the position shown below.
For 3-inch type: 80-mm wide paper roll
For 2-inch type: 58-mm wide paper roll
1. Turn off the power.
2. Press the cover open lever.
3. Open the paper cover.
4. Set the partition in a slot that matches the size of the paper roll you are using.
However, to use an 83-mm wide paper roll, remove the partition.
Refer to " 5.3 Manual Setting of Memory Switches"
5.
settings.
CAUTION
Make sure the partition is not slanted when setting it for 58-mm or 60-mm paper rolls.
to change the paper width
Partition
*1
*1 *2
Notes:
*1: 2-inch type (58/60 mm)
*2: 3-inch type (80/83 mm)
