TVS electronics Jus' Print RP-3200 User Manual

3” thermal printer
Hide thumbs Also See for Jus' Print RP-3200:
Table of Contents

Advertisement

Quick Links

See also: User Manual
3" Thermal Printer
Jus' Print RP-3200
All specifications are subject to change without notice
TVS electronics Ltd.
No 34, Developed Plots, South Phase, Industrial Estate, Guindy, Chennai - 600032
Toll Free no- 1800 103 2345

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jus' Print RP-3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TVS electronics Jus' Print RP-3200

Summary of Contents for TVS electronics Jus' Print RP-3200

  • Page 1 3” Thermal Printer Jus' Print RP-3200 All specifications are subject to change without notice TVS electronics Ltd. No 34, Developed Plots, South Phase, Industrial Estate, Guindy, Chennai - 600032 Toll Free no- 1800 103 2345...

  • Page 3: Table Of Contents

    1. Parts Identifications 2. Setting up the printer 2.1 Unpacking 2.2 Connecting the cables 2.3 Loading the roll paper 2.4 Dip switch setting 3. Control panel and other functions 3.1 Control panel 3.2 Error Indicating 4. Self Test 5. Hexadecimal Dump 6.

  • Page 4: Parts Identifications

    Jus' Print RP-3200 User’s Manual 1. Parts Identifications...

  • Page 5: Setting Up The Printer

    Jus' Print RP-3200 User’s Manual 2. Setting Up the Printer 2-1. Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. The Printer User’s Manual Roll Paper Adaptor (Option)

  • Page 6: Connecting The Cables

    Jus' Print RP-3200 User’s Manual 2-2. Connecting the Cables Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Before connecting any of the cables, make sure that both the printer and the computer are...

  • Page 7: Serial Interface

    Jus' Print RP-3200 User’s Manual 2-2-1. Interface Connector <D-SUB 25 Female Serial> <USB “B” Type> <USB COMBO> Serial Interface SIGNAL Output Input 4, 20 Output Input 1, 7 USB Interface SIGNAL DATA- DATA+ Printer transmit data line RS-232C level Printer receive data line RS-232C level...
  • Page 8 GROUND SELLECT IN- Ethernet Interface SIGNAL Data Out + Data Out - Data IN + Data IN - Jus' Print RP-3200 User’s Manual Input Synchronize signal Data received Input/Output Data bit Transmitted 0~7 Output Data receiving completed. Output Impossible to print of data receiving.
  • Page 9 Jus' Print RP-3200 User’s Manual 2-2-2. Cash Drawer Connector The printer can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A/24VDC for 510ms or less when not printing.

  • Page 10: Loading The Roll Paper

    1. Make sure that the printer is not receiving data; Otherwise, data may be lost. 2. Open the paper roll cover by pushing down the cover open button. 3. Remove the used paper roll core if there is one inside. 4. Insert new paper roll as shown. Jus' Print RP-3200 User’s Manual...
  • Page 11 Jus' Print RP-3200 User’s Manual 5. Pull out a small amount of paper, as shown. Then, close the cover. 6. Tear off the paper as shown.

  • Page 12: Dip Switch Setting

    Baud rate selection Transmission speed 4800 bps 9600 bps 19200 bps 38400 bps Print Density (DIP-SW2) Print Density Low Power Normal Normal Dark Jus' Print RP-3200 User’s Manual Ignored Print “?” HEXDUMP NORMAL XON/XOFF DTR/DSR 7bits 8bits ENABLED DISABLED EVEN...
  • Page 13 Jus' Print RP-3200 User’s Manual 2-4-2. Parallel Interface Specification DIP Switch Set 1 Function FUNCTION Hexadecimal Bi-Parallel mode Print Density (DIP-SW2) Print Density Low Power Normal Normal Dark HEXDUMP NORMAL DISABLED ENABLED SW-1 DEFAULT SW-2...
  • Page 14 Baud rate selection Transmission speed 4800 bps 9600 bps 19200 bps 38400 bps Print Density (DIP-SW2) Print Density Low Power Normal Normal Dark Jus' Print RP-3200 User’s Manual HEXDUMP XON/XOFF 7BITS ENABLED EVEN SW-7 SW-1 DEFAULT NORMAL DTR/DSR 8BITS DISABLED...
  • Page 15 Jus' Print RP-3200 User’s Manual 2-4-4. USB Interface Specification DIP Switch Set 1 Function FUNCTION Hexadecimal Print Density (DIP-SW2) Print Density Low Power Normal Normal Dark 2-4-5. Wi-fi Interface Specification DIP Switch Set 1 Function FUNCTION Hexadecimal Print Density (DIP-SW2)
  • Page 16 Normal Dark DIP Switch Set 2 Functions Cutter FUNCTION Cutter Emulation FUNCTION Epson (TM-88) Paper low detect FUNCTION Paper Low Jus' Print RP-3200 User’s Manual HEXDUMP SW-1 FULL CUT PARTIAL CUT SW-4 Detect DEFAULT NORMAL SW-2 Remarks Only Epson mode...
  • Page 17 Jus' Print RP-3200 User’s Manual ♣CAUTION: Turn off the printer while removing the DIP switch cover to prevent an electric short, which can damage the printer. 1. Make sure the printer is turned off. 2. Remove the screw from the DIP switch cover. Then, take off the DIP switch cover as shown in the illustration below.
  • Page 18 Jus' Print RP-3200 User’s Manual ♣CAUTION: When the paper is jammed with cutter, the top cover might be stuck. In this case, repeat power on and off several times. If the top cover is still stuck, please follow the steps to release the papers from jamming.

  • Page 19: Control Panel And Other Functions

    Jus' Print RP-3200 User’s Manual 3. Control panel and other functions. 3-1. Control panel You can control the basic paper feeding operations of the printer with the button on the control panel. The indicator lights help you to monitor the printer’ s status.

  • Page 20: Self Test

    4. The self test automatically ends and cuts the paper after printing the following. The printer is ready to receive data as soon as it completes the self-test. Jus' Print RP-3200 User’s Manual Self test Printing Please press the PAPER FEED button.

  • Page 21: To Use The Hex Dump Feature

    Jus' Print RP-3200 User’s Manual 5. Hexadecimal Dump This feature allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hex dump function, the printer prints all commands and other data in hexadecimal format along with a guide section to help you find specific commands.

  • Page 22: Specifications

    Refer to chapter 2 for details on the recommended roll Paper. Paper width: 50mm ~ 82.5mm Roll diameter : Max. Ø102.0 mm (7) Weight 1.7Kg Jus' Print RP-3200 User’s Manual Direct line thermal printing. 200mm/sec. 180 / 180 (0.141mm / 0.141mm dot) 203 / 180 (0.125mm / 0.141mm dot)
  • Page 23 Jus' Print RP-3200 User’s Manual (8) Overall dimension...

  • Page 24: Auto Cutter Specifications

    USB COMBO Interface, Ethernet Interface(10Mbps), Wi-fi(802.11b) 6-4. Electrical Characteristics (1) Input Voltage (2) Current Consumption (3) Power Connector Jus' Print RP-3200 User’s Manual Max. 30 cuts per minute 0.065 ~ 0.1 mm 1.0 million cuttings (if the paper thickness is between 65 and100µm) DC 24V ±...

  • Page 25: Environmental Requirements

    Jus' Print RP-3200 User’s Manual Important! When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. (1) Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A. (2) Be careful about installing the printer in an area where there is noise.

  • Page 26: Command List

    ESC c 3 Select paper sensor(s) to output paper-end signals ESC c 4 Select paper sensor(s) to stop printing ESC c 5 Enable/disable panel buttons ESC d Print and feed paper n lines Jus' Print RP-3200 User’s Manual Function REMARKS...
  • Page 27 Jus' Print RP-3200 User’s Manual Command ESC p General pulse ESC t Select character code table ESC { Turn upside-down printing mode on/off FS p Print NV bit image FS q Define NV bit image GS ! Select character size...
  • Page 28 Rev. 2.0...
