1.2 Basic Specifications

Item
Model RP-3200
Print method Line thermal dot print method
Print width 80 mm/640 dots, 72 mm/576 dots, 64 mm/512 dots, 54.5 mm/436 dots,
*1
54 mm/432 dots, 52.5 mm/420 dots, 48 mm/384 dots, 45 mm/360 dots,
48.75 mm/390 dots, 68.25 mm/546 dots
Dot density 8 ⋅ 8 dots/mm (203 dpi)
Print speed 200 mm/s (fastest, print density 100%), 1600 dot-lines/s
Number of print
—
columns
*2
Paper width
Font
Font A
Font B
Font C
Character size Font A: 1.50 ⋅ 3.00 mm
*3
Font B: 1.13 ⋅ 2.13 mm
Font C: 1.00 ⋅ 2.00 mm
Character type Alphanumeric, international, PC437/850/852/857/858/860/863/864/865/866/
WPC1252/katakana/Thai code 18
User memory 384 KB (capable of storing user-defined characters and logos)
Bar code types UPC-A/E, JAN (EAN) 13/8 columns, ITF, CODE39, CODE128, CODABAR (NW-7),
CODE93, PDF417, QR Code
Line spacing 4.25 mm (1/6 inch) (changeable using commands)
Paper roll
Paper roll: 83
Paper thickness: 65-75 ⎧m (core tube diameter: inner 12 mm/outer 18 mm)
Interface parallel (IEEE 1284 compliant), USB
Cash drawer kick-out Supports 2 cash drawers
Buffer size 4 k bytes/45 bytes
Supply voltage DC 24 V ±5%
Power consumption Approximately 45 W (normal printing), 3 W (standby)
AC adapter Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA
*4
(36AD3) Rated output: DC 24 V, 2.1 A
Weight Approx. 2 kg
Outside dimensions 145 (W) ⋅ 192 (D) ⋅ 148 (H) mm
Operating temperature 5 to 45°C, 10 to 90% RH (no condensation)
and humidity
Storage temperature -20 to 60°C, 10 to 90% RH (no condensation)
and humidity
Reliability Print head life: 150 km, 200 million pulses (at normal temperature and
humidity using recommended paper)
Auto cutter life: 2 million cuts (at normal temperature/humidity, using
recommended paper and paper thickness)
Safety standard UL, C-UL, FCC Class A, TÜV-Bauart, CE Marking
*5
Specifications
Maximum number of characters
(columns)
83 mm 80 mm 60 mm
53 48 36
71 64 48
80 72 54
+0 +0 +0 +0
mm/80 mm/60 mm/58 mm ⋅ maximum ⎞83 mm
-1 -1 -1 -1
75-85 ⎧m (core tube diameter: inner 25.4 mm/outer 32 mm)
— 10 —
Dot configuration
(dots)
58 mm
35
12 ⋅ 24
46
9 ⋅ 17
52
8 ⋅ 16
