Emulation mode, communications mode, baud rate, serial/parallel handshake, and head printing characteristics are all configured through dip switch settings. ♣Data Buffer The Jus' Bill RP-35 printer has a built-in 16 Kilobyte I/O buffer allowing the host computer to free itself after sending the print data. ♣Reliable communications The Jus' Bill RP-35 supports multiple baud rates, protocols, and handshaking on its parallel &...
DIMENSIONS Cutter Non cutter WEIGHT Cutter Non cutter Jus' Bill RP-35 9-pin serial impact dot matrix Bi-directional (with logical seeking) Epson Mode : 42/35, 40/33, Star Sp200 : 42/35 Other Modes : 40/32 7 x 9, 9 x 9 dots n/144 inch 63.5mm (2.5”)
CR Character : Flow Control : Data Bits : Parity : Baud Rate : CPL : Two Color : Auto Cutter : Journal : Jus' Bill RP-35 Ver X.XX Serial Epson TM-U200 CR=CR only DTR/DSR 8 Bits None 9600 40/33 Char / Line...
A Power switch located on the lower left side of the printer is used to turn the printer on/off. Indicators This section explains the different patterns signaled by the two LED indicators located on the top cover of the Jus' Bill RP-35. LED1 LED2...
6. Interface 6-1. Interface Connector <D-SUB 25 Female Serial> <USB “B” Type> <USB COMBO> Serial Interface SIGNAL Output Input 4, 20 Output Input 1, 7 USB Interface SIGNAL DATA- DATA+ <Centronics Parallel> <Ethernet> <Wi-fi> DESCRIPTION Printer transmit data line RS-232C level Printer receive data line RS-232C level Printer handshake to host line RS-232C level Data Send Ready...
Page 13
Centronics Parallel Interface SIGNAL STROBE- DATA0~7 Input/Output ACK- BUSY SELECT AUTO FEED- GROUND GROUND LOGIC-H 19~30 GROUND INIT- ERROR- GROUND SELLECT IN- Ethernet Interface SIGNAL Data Out + Data Out - Data IN + Data IN - DESCRIPTION Input Synchronize signal Data received Data bit Transmitted 0~7 Output Data receiving completed.
7. Cash Drawer Connector The Jus' Bill RP-35 can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A for 510 ms or less, when not printing. SIGNAL...
8. Electrical Specifications The Jus' Bill RP-35 requires a power supply with the following parameters. A linear power Adapter is included in the Jus' Bill RP-35 box. Power Supply Voltage : 24VDC±10% Power Supply Current : 2.5 A <Power Supply Connector>...
9. Dip Switch Settings This table gives the definition for the DIP switch settings. Function Setting Epson TM-U200 Epson TM-U300 Emulation Citizen iDP3540 Star SP200 CR=CR Only Character CR=CR + LF 40/33 Char/Line 42/35 Char/Line Auto Not Install Cutter Install Not Install 2Color Install...
Page 17
Function Setting Epson TM-U200 Epson TM-U300 Emulation Citizen iDP3540 Star SP200 CR=CR Only Character CR=CR + LF 40/33 Char/Line 42/35 Char/Line Auto Not Installed Cutter Installed Not Installed 2 Color Installed Not Installed Journal Installed Function Setting Auto Not Install Melody Installed...
