5.2 Printing Paper

Use the paper shown in the following table or paper of the same quality.
Signal Pin
FG 1
TXD 2
RXD 3
CTS 5
Paper width 83
+0
-1
Maximum print area 80
Paper width 60
+0
-1
Maximum print area 48
(Initial setting)
CAUTION
Use paper that is wound as follows:
Not creased and fits tight to the core.
Not folded.
Not glued to the core.
Rolled with the printable side out.
Paper width 80
+0
-1
Maximum print area 72
Paper width 58
+0
-1
Maximum print area 48
(Initial setting)
Signal Pin
FG 1
TXD 2
RXD 3
CTS 5
DSR 6
SG 7
— 36 —
(Unit: mm)
Printable side
