4 TECHNICAL PARAMETERS......................................................................43
4.1 E
LECTRICAL PARAMETERS
4.2 M
ECHANICAL DIMENSIONS
4.3 P
ARAMETERS OF VIDEO

1 Basic description

1.1 Features

Ø two 25 digit numbers stored at each pushbutton (including * and #)
Ø commands for doorhphone can be two or one digit
shortened to one digit 5 by storing *5 replacing the original two digit command 55)
Ø the basic module (1 or 2 pushbuttons) can be expanded by add-on 8
pushbutton module up to maximum capacity of 58 pushbuttons
Ø day/night switching - automatically or manually
Ø prolongation of call duration by entering * or #
Ø possibility to connect two independent locks for door opening
Ø 5 modes of switches (e.g. camera, illumination, sequential opening)
Ø two codes for hang-up of the doorphone via the telephone
Ø two codes for door opening via the telephone
Ø six access codes (passwords entered via pushbuttons of the
doorphone)
Ø optional number of rings before you answer the incomming call
Ø optional time period between individual presses of pushbuttons when
entering access code via pushbuttons of the doorphone
Ø optional time period of hang-up during repeating of the dialling
Ø optional time period before start of the dialling
Ø powered either by 12V or PoE (both norms)
Ø integrated heating of the circuit board
Ø pernament illumination of visit cards
Ø automatic illumination for camera (white LEDs)
Ø integrated colour camera with autofocus
Ø Ethernet - 10/100Mb with standard 10BaseT and 100BaseTx
Ø Web server for remote programming - BOA
Ø Linux 2.6 operating system
Ø USB connection of the internal camera - USB guest 1.1, software
GSPCA software for video transmission to a web browser on the PC -
W3CAM (J-PEG, RTSP Stream) and video stream H.263 / H.264
Ø SIP connection in P2P mode or SIP Proxy (PBX network system)
Ø WEB based firmware upgrades
Ø WEB web programming tool for set-up of doorphone parameters
........................................................................43
........................................................................44
.............................................................................45
IP Bell
(command 55 can be
- User guide and installation manual
5
