2 Operation of the IP Bell doorphone

2.1 Overview of signalling

The IP Bell doorphone signals acustically statuses, which can occur
during operation, another signalling is provided with red LED (located next to
the camera – valid for camera versions only).
Status
Line pick up
Line hang up
Report after calling
Command confirmation from
phone (parameter confirmation)
Notification about call end
Line connection (Reset)
Error (generally anything
unsuitable)
Empty memory (no number
programmed)
Establishing connection
Connection established – active
call

2.2 Visitor at the door entrance

IP Bell functionality is influenced by settings of doorphone parameters.
Pushbuttons of the doorphone are provided with name tags. The visitor
presses a desired pushbutton, the doorphone picks up the line either
immediately (the pushbutton is not the first digit of the access code) or with a
delay (time period between induvidual presses of the pushbuttons) and dials a
preprogrammed telephone number. The dialled number differs only according
to the set dialling mode of the doorphone:
- Day/Night mode = if the doorphone is set to the Day mode, it always
dials number set in the first column. If the doorphone is set to the Night
mode, it always dials number set in the second column. Day/Night
mode switcihng can be done manually or automatically. See the basic
parameters settings. If you choose Day/Night switching, then "Daily
intervals" appear in the web interface menu. Here you can set up to 3
daily intervals for 7 days per week. Correct functionality requires setting
IP address of NTP server and network setting enabling internet access
Tones
–▄–■–▀–
–▀–■–▄
–▄–■–▀–
––█––
–■–■–■–
–■–▄–■–
–■–■–■–■–■–■–
–█–▄–■–▄–■–▄–
-
-
IP Bell
- User guide and installation manual
Tone frequency
425-850-1275
1275-850-425
425-850-1275
425
1275
1275-850-1275
425....
850-1275-1700...
LED
shines
goes
out
shines
shines
blinks
blinks
shines
