Intelix DIGI-HD-4X8 Installation Manual page 15

4 input by 8 output matrix switcher

Hide thumbs

Table Of Contents

Table of Contents

Output 3 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

Output 4 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

Output 5 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

Output 6 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

Output 7 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

Output 8 Commands

Function

Select Input 1

Select Input 2

Select Input 3

Select Input 4

www.intelix.com

Intelix DIGI-HD-4X8 Installation Manual

Code

cir<sp>17\r

cir<sp>12\r

cir<sp>59\r

cir<sp>08\r

Code

cir<sp>50\r

cir<sp>55\r

cir<sp>48\r

cir<sp>4A\r

Code

cir<sp>5E\r

cir<sp>06\r

cir<sp>05\r

cir<sp>03\r

Code

cir<sp>47\r

cir<sp>07\r

cir<sp>40\r

cir<sp>02\r

Code

cir<sp>18\r

cir<sp>44\r

cir<sp>0F\r

cir<sp>51\r

Code

cir<sp>0A\r

cir<sp>1E\r

cir<sp>0E\r

cir<sp>1A\r

Return

s30

s31

s32

s33

Return

s40

s41

s42

s43

Return

s50

s51

s52

s53

Return

s60

s61

s62

s63

Return

s70

s71

s72

s73

Return

s80

s81

s82

s83
