Intelix DIGI-HD-4X8 Installation Manual page 13

DIGI-HD-4X8 RS232 Codes
*
\r = Carriage Return (hex=0D)
*
\n= Line Feed (hex=0A)
*
<sp> = Space (hex=20) is required as part of command
Misc. Commands
Function
Get Device Type
Get Crosspoint Status
Get UTP Mode
www.intelix.com
Intelix DIGI-HD-4X8 Installation Manual
Code
br<sp>\r
bc<sp>\r
gup<sp>\r
Return String
ASCII String ―DIGI-HD-
4X8‖
ASCII string in the
format of: ―\r\n‖ +
―s1Ys2Ys3Ys4Ys5Ys6Y
s7Ys8Y‖ + ―\r\n‖ where
Y is the input source
being routed to each
output. The value of Y
maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
The outputs channels
map as follows:
s1 = output 1
s2 = output 2
s3 = output 3
s4 = output 4
s5 = output 5
s6 = output 6
s7 = output 7
s8 = output 8
ASCII string in the
format of:
u1Xu2Xu3Xu4Xu5Xu6
Xu7Xu8X‖ + ―\r\n‖
where X is the UTP
Mode. The value of X
maps as follows:
0 = dual UTP
1 = single UTP
The outputs channels
map as follows:
u1 = output 1
u2 = output 2
u3 = output 3
u4 = output 4
u5 = output 5
u6 = output 6
u7 = output 7
u8 = output 8
13
