Intelix DIGI-HD-4X8 Installation Manual page 11

Included Remote Control
The DIGI-HD-4X8 includes a wireless remote
control for switching inputs to the various
outputs. Each output is represented by a bank
of buttons on the remote control.
1. Determine which output you wish to
change.
2. On the determined output, select the
desired input number.
IR Remote Control
The DIGI-HD-4X8 supports remote control
through a front panel IR sensor and a rear
panel 1/8‖ (3.5 mm) input jack.
If controlling the DIGI-HD-4X8 through the 1/8‖ (3.5 mm) input jack on
1.
the rear panel, connect the IR receiver (eye) directly to the matrix.
Note: Operation of the rear panel IR input will disable the front
panel IR sensor. 3
2. If controlling the DIGI-HD-4X8 through the IR sensor on the front panel,
place an IR emitter directly over the front panel sensor.
www.intelix.com
Intelix DIGI-HD-4X8 Installation Manual
rd
party IR systems are not compatible.
11
