Enterview 3V / 3VC (Pinhole Camera)
Remark
Power Source
DC 13V (supplied from Monitor)
Power Consumption
DC 13V, 0.17A
Display Input
1Vp-p/75, Composite CCIR/EIA, PAL/NTSC
Minimum Illuminance
0.1 Lux (B/W) / 3 Lux(Color)
Temperature
-10 C ~ 40 C
Environment
Humidity
Below 90% (relative)
Dimension
91.5W 132.5H 18D(mm) / 3-3/5W 5-1/5H 5/7D(Inches)
Size
Weight
0.2kg / 0.44 Ibs
Installation
Flush Mount Type
The depth of camera on the table indicates from wall surface after installation
Enterview Muliti (Multi Camera)
Remark
Power Source
DC 12V
Power Consumption
DC 12V, 0.3A
Display Input
1Vp-p/75, Composite CCIR/EIA, PAL/NTSC
Minimum Illuminance
0.1 Lux (B/W) / 3 Lux(Color)
Temperature
-10 C to +40 C
Environment
Humidity
Below 90% (relative)
Dimension
123W 308H 18D(mm) / 4-5/6W 12-1/8H 5/7D(Inches)
Size
Weight
1kg / 2.2 Ibs
Installation
Flush Mount Type
The depth of camera on the table indicates from wall surface after installation
Specification
Specification
Memo
Technical Helpline - 0121 786 1881
