Chapter 2–Installing an internal DAT tape drive

Install drive

DAT SCSI Tape Drives
20
1. M3 mounting screws

Figure 2-2 Example, attaching mounting screws

Static electricity can damage electronic components.
Caution
Always wear an antistatic wriststrap if one is
available. If not, after you have disconnected power
from the server and removed the cover, touch a bare
metal part of the chassis. Similarly, touch a bare
metal part of the drive before installing it.
Slide the tape drive into the open bay, aligning the tray or rails with the slots
in the bay.
1
2
2. M3 offset mounting screws
