1. M3 mounting screws

Figure 2-1 Example, attaching mounting screws

Install drive

Caution
Slide the tape drive into the open bay, aligning the tray or rails with the slots
in the bay.
August 2009
2. M3 offset mounting screws
Static electricity can damage electronic components.
Always wear an antistatic wriststrap if one is
available. If not, after you have disconnected power
from the server and removed the cover, touch a bare
metal part of the chassis. Similarly, touch a bare
metal part of the drive before installing it.
Install drive
1
2
#
15
