- Page 1 HMD904C PORTABLE MAGNETIC DRILL OPERATOR’S MANUAL FOR USE WITH “12,000-SERIES” HOUGEN FOR USE WITH “12,000-SERIES” HOUGEN CUTTERS CUTTERS ® ® ®...
-
Page 2: 10506 Set Screw For Cutter Installation
No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILITY or FITNESS for any period beyond the expressed warranty and shall not be liable for incidental or consequential damages. -
Page 3: Table Of Contents
Complete and mail the Product Registration Card now. 8. Attach the coolant bottle with the hardware provided. It is important that Hougen Manufacturing, Inc. have a 9. Your Magnetic Drill was factory adjusted prior to record of product ownership. -
Page 4: Safety Instructions
12. Non-Conforming Cutting Tools Keep Work Area Clean Your Mag Drill is designed to use Hougen Cutters. Cluttered areas and benches invite injuries. The use of drilling tools having different shank styles Keep dirt and chips from under the Cutter area. -
Page 5: Safety Switch Indicator Light
Keep tools sharp and clean for better and safer Changing of the circuit breaker to a higher amp rated breaker, or performance. Do not use dull or broken Hougen Cutters. bypassing the circuit breaker is not recommended and will void Follow instructions for lubricating and changing product warranty. -
Page 6: Operating Instructions
7. Make certain that cutter is clear of workpiece and turn motor ON by pressing the motor START switch. 8. Feed Hougen Cutter slowly into workpiece. Only after cutting path is established to a depth of about 1/16” can full force be applied to feed handles. -
Page 7: Installing Hougen Cutters
3. Turn Feed Handles until cutter mounting set screws are exposed and completely remove the set screws. 4. Insert proper pilot in shank end of Hougen Cutter. 5. Insert Hougen Cutter until fl at on cutter shank is aligned with set screw holes and is exactly perpendicular to axis of set screw holes. -
Page 9: Motor Parts
MOTOR ASSEMBLY 04527 04528 (OPPOSITE SIDE) 10538 11053 75289 04502 02413 11053 BOLT TORQUE SPECIFICATIONS - TIGHTEN TO 18 IN-LBS 75289 BOLT TORQUE SPECIFICATIONS - TIGHTEN TO 25 IN-LBS MOTOR PARTS LIST - 05477 Part # Description Part # Description 02413 Motor Cord 17611... -
Page 10: Wiring Diagram
CONTROL PANEL HOOKUP (P2) Circuit �� ��� Board Power Cord (P1) Circuit White Board Power Cord Black Motor Black Wire Motor White Wire From L.E.D Bulb To (J3) Power Cord Green Ground Attach To Housing Green Ground To Housing (J1) (J4) (J2) Safety Switch... -
Page 11: Electrical Panel Parts
CONTROL PANEL PARTS LIST Panel Assembly P/N 05188 04644 01226 ��� ����� 05871 04643 ����� 04614 05872 02548 ������ ����� 05829 ���� �� ������ ������ ������ ����� ����� ���� 02412 04879 ����� 04878 ��� ����� 04881 ����� ���� ��������� ������ �������� ���� �������... -
Page 13: Parts Listing
HMD904C PARTS LIST Part # Description Part # Description 02411 Strain Relief-Motor Cord 90028 Lock Washer 1/4 Heli 02413 Motor Cord 90052 Lock Washer #6 Ext 02420 Motor Cord Clamp 90077 Screw BHC #10-32 x 1/2 02422 Motor Cord Bracket... -
Page 14: Drill Maintenance & Operation Hints
5. Remove arbor and pack the bearing in the front support bracket with grease. Use Shell Cyprina-RA or equivalent. HINTS FOR SMOOTHER OPERATION 1. Keep insides of Hougen Cutter clear of chips. Chips will interfere with cutting to maximum depth, may impede the free oil fl ow and can cause cutter breakage. -
Page 15: Commercial Warranty
NOTES...
