System Specifi Cations - Automatic Technology GDO-7v2 SecuraLift Installation Instructions Manual

Default Settings & Specifi cations
Factory Default Settings
Maximum motor run time
Courtesy light time
Obstruction force margin
Auto close time
Technical Specifi cations
Power supply
Standby power
Motor power
Motor type
Shuttle travel distance
Maximum shuttle travel distance in the C-Rail
Maximum door opening:
Short term peak force
Lift force
Nominal force
Receiver type
Receiver code storage capacity
Transmitter frequency
Coding type
Number of code combinations
Code generation
Transmitter battery
Courtesy light
Controller fuse
NOTE:
1. The door must be well balanced. A person should be able to lift the door up manually with very little effort in
case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. Strong wind puts extra pressure
on the door and tracks which may in turn trigger the safety obstruction detection system intermittently.
GDO-7v2 SecuraLift®
26
Default
30 secs
4 mins
3
0 secs
Width:
Height:
Weight:
Owner Installation Instructions
Step
-
10 secs
1
5 secs
230V - 240Va.c. 50Hz
2.2 Watts
250 Watts (1/3 HP)
Alternating Current
* 2.7m approx. (Standard)
* 3.750m (with extension)
5500mm (16.5m 2 )
3000mm
100kg
800N (80kg)
600N (60kg)
150N (15kg)
UHF Multi-frequency FM Receiver
24 X 4 button Transmitter Codes
UHF Multi-frequency FM Transmitter
Code hopping
Over 4.29 billion random codes
Non-linear encryption algorithm
CR2032 (3 Volts)
Edison (screw mount) 240V 60W rough service (or
construction type)
5A slow blow
Maximum
-
10 mins
27
4 mins
