MAINTENANCE WORK ON CHASSIS AND ENGINE

Changing the rear brake linings

13.79
Warning
Skin irritations Brake fluid can cause skin irritation on contact.
–
Avoid contact with skin and eyes, and keep out of the reach of children.
–
If brake fluid gets into your eyes, rinse thoroughly with water and contact a doctor immediately.
Warning
Danger of accidents Reduced braking due to old brake fluid.
–
Have the front and rear brake fluid replaced according to the service plan in an authorized KTM workshop.
Warning
Environmental hazard Problem materials cause environmental damage.
–
Dispose of oil, grease, filters, fuel, cleaning substances, brake fluid, batteries, etc. according to regulations.
Info
Never user DOT 5 brake fluid! This is based on silicone oil and is colored purple. Oil seals and brake lines are not designed for
DOT 5 brake fluid.
Avoid contact between brake fluid and painted parts. Brake fluid attacks paint!
Use only clean brake fluid from a sealed container!
–
Check that leaf spring
caliper support are seated correctly.
Info
The arrow on the leaf spring points in the rotation direction of the brake
disc.
500122-10
–
Fit the brake pads, insert bolt
Info
Make sure that the decoupling plate
brake pad.
–
Operate the foot brake lever repeatedly until the brake linings lie on the brake disc
and there is a tight spot.
400237-10
x
–
Remove the rear brake linings.
–
Stand the vehicle upright.
–
Remove screw cap
–
Press the brake piston back to its basic position and make sure that no brake fluid
overflows from the brake fluid reservoir.
–
Install the rear brake linings.
–
Add brake fluid to level
Brake fluid DOT 4 / DOT 5.1 (
400233-10
–
Mount the screw cap with the membrane and the O-ring.
Info
Clean up overflowed or spilt brake fluid immediately with water.
in the brake caliper and sliding plate

, and mount locking split pins

is mounted on the piston side of the

x ( p. 70)
with membrane and the O-ring.
 
( p. 70)
x
.

p. 116)
71
in the brake

.

