Icom IC-7600 Service Manual page 83

[FILTER UNIT] (FIT)
REF ORDER
NO. NO.
RL101* 6330001721 ATN207-K1
RL102* 6330001721 ATN207-K1
RL151* 6330001721 ATN207-K1
RL152* 6330001721 ATN207-K1
RL201* 6330001721 ATN207-K1
RL202* 6330001721 ATN207-K1
RL251* 6330001721 ATN207-K1
RL252* 6330001721 ATN207-K1
RL301* 6330001721 ATN207-K1
RL302* 6330001721 ATN207-K1
RL351* 6330001721 ATN207-K1
RL352* 6330001721 ATN207-K1
RL401* 6330001721 ATN207-K1
RL402* 6330001721 ATN207-K1
J1 6510007020 TMP-J01X-V6
J2 6510007020 TMP-J01X-V6
J3* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
W9 8900009621 OPC-961A
W10 8900009631 OPC-962A
EP501 6510018330 F4053A
EP502 6510018330 F4053A
[CTRL UNIT] (CTR)
REF ORDER
NO. NO.
RL101* 6330000800 G5A-237P DC12V
RL102* 6330001770 SIP-1A-12Y
RL103* 6330001770 SIP-1A-12Y
RL104* 6330001460 FTR-F1 CA012V
RL105* 6330001460 FTR-F1 CA012V
CP1* 6910009670 HK3-S-T
J3 6510017150 TMP-S01X-C1
J101 6510017150 TMP-S01X-C1
J102 6510017150 TMP-S01X-C1
J103 6510017150 TMP-S01X-C1
J151* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
J241* 6510022031 B10B-ZR-SM4-TF (LF) (SN)
J261* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J262* 6510022581 24FMN-BMTTR-A-TBT (LF) (SN)
J291* 6510018971 B4B-PH-SM4-TB (LF) (SN)
W1 7120000490 ERD25T0
W2 7120000490 ERD25T0
MP1* 8510002020 MIXSHIELD CASE (SX-155)
[MAIN UNIT] (MA)
REF ORDER
NO. NO.
RL2301* 6330001721 ATN207-K1
RL2302* 6330001721 ATN207-K1
CP1253* 6910009670 HK3-S-T
J1002* 6510024151 50FY-BMT-TB (LF) (SN)
J1003 6510021861 BH-800-4GG
J1051* 6510024151 50FY-BMT-TB (LF) (SN)
J1501* 6510022601 30FMN-BMTTR-A-TBT (LF) (SN)
J1601* 6510022581 24FMN-BMTTR-A-TBT (LF) (SN)
J1701* 6510022581 24FMN-BMTTR-A-TBT (LF) (SN)
J1801* 6510022581 24FMN-BMTTR-A-TBT (LF) (SN)
J1901 6510024311 B4B-PH-K-S (LF) (SN)
J2001 6510023671 TCS4480-0141577
J2002 6510023661 TCS4470-0141577
J2101 6510026540 UBB-4R-D14T-4D (LF) (SN)
J2201 6510023720 LGY6501-0600C
J2301 6510024311 B4B-PH-K-S (LF) (SN)
J2302 6510023720 LGY6501-0600C
J2401 6510023720 LGY6501-0600C
J2501 6510023900 LGR4619-7000
J2502 6510024311 B4B-PH-K-S (LF) (SN)
J3001 6510007020 TMP-J01X-V6
J3401 6510007020 TMP-J01X-V6
J3701 6510007020 TMP-J01X-V6
J3702 6510007020 TMP-J01X-V6
J4101* 6510022801 B10B-PH-SM4-TB (LF) (SN)
J6001 6510007020 TMP-J01X-V6
J6002 6510007020 TMP-J01X-V6
J6102 6510026920 IMSA-9180B-12B-PT1
BT1001 3020000110 CR2032
W6001 7120000490 ERD25T0
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
[MAIN UNIT] (MA)
REF ORDER
NO. NO.
MP2101 8510015720 2590 DC-DC A-CASE
MP2201 8930065741 2590 D-EARTH SPRING-1
MP2301 8930065741 2590 D-EARTH SPRING-1
MP2501 8930065741 2590 D-EARTH SPRING-1
MP3001* 8510015900 2590 M-2LO CASE
MP3201* 8510012400 2177 D/A CASE
MP3202* 8510012400 2177 D/A CASE
MP3601* 6910001130 10M SHIELD CASE
MP3602* 8510005150 602 SHIELD CASE
MP3603 8510005160 602 SHIELD CASE COVER
MP3604 8510002280 VCOSHIELD PLATE (A) (FX-15)
MP3605 8930059380 SHIELD SPONGE (X)
MP3606 8930058840 SHIELD SPONGE (T)
MP4501 8510010460 1691 MAIN SHIELD PLATE
MP4502 8510002280 VCOSHIELD PLATE (A) (FX-15)
MP4503 8930065720 SHIELD SPONGE (AP)
MP5001 8930065741 2590 D-EARTH SPRING-1
MP5101 8930065741 2590 D-EARTH SPRING-1
MP6001* 8510012400 2177 D/A CASE
MP6002* 8510012400 2177 D/A CASE
MP6003* 8510013140 2241 DC-A CASE
MP6004* 8510013140 2241 DC-A CASE
MP6005* 8510019400 3073 M-CASE
MP6006 8510019410 3073 M-COVER
MP6007 8510013820 2356 A-SHIELD PLATE
MP6008 8930065741 2590 D-EARTH SPRING-1
MP6009 8930065741 2590 D-EARTH SPRING-1
[MCF-N UNIT] (M-N)
REF ORDER
NO. NO.
EP6001* 6910002161 CASE-BM7H-LF
EP6002* 6910002161 CASE-BM7H-LF
[MCF-M UNIT] (M-M)
REF ORDER
NO. NO.
EP5001* 6910002161 CASE-BM7H-LF
EP5002* 6910002161 CASE-BM7H-LF
EP7001* 6910002161 CASE-BM7H-LF
EP7002* 6910002161 CASE-BM7H-LF
[MCF-W UNIT] (M-W)
REF ORDER
NO. NO.
EP7001* 6910002161 CASE-BM7H-LF
EP7002* 6910002161 CASE-BM7H-LF
6 - 5
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
1
1
1
DESCRIPTION QTY.
1
1
