Apr. 2009

[DCDC UNIT]

REF PARTS
DESCRIPTION
NO. NO.
IC101 1180003100 S.REG BD9302FP-E2
IC201 1190002450 S.IC BD9851FEV-E2
Q201 1550000230 S.FET SSM3J117TU(TE85L)
D101 1750000960 S.DIO RB081L-20
D102 1750000960 S.DIO RB081L-20
D201 1790001450 S.DIO RB160L-40 TE-25
L101 6200010881 S.COI CDRH124NP-330MC
L102 6200013280 S.COI SLF10145T-330M1R6-PF
L103 6200013280 S.COI SLF10145T-330M1R6-PF
L201 6200011551 S.COI CDRH6D28NP-270NC
L202 6200011300 S.COI EXCML16A270U
L203 6180003501 S.COI SLF6028T-100M1R3-PF
L204 6200011300 S.COI EXCML16A270U
R101 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R102 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R103 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R104 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R105 7030005451 S.RES ERA3YED 153V (15K)
R106 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R107 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R108 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R109 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R110 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R111 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R201 7030005691 S.RES ERA3YED 123V (12K)
R202 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R203 7030007230 S.RES ERA3YED 102V (1K)
R204 7030006461 S.RES ERA3YED 152V (1.5K)
R205 7030005981 S.RES ERA3YED 333V (33K)
R206 7030003700 S.RES ERJ3GEYJ 154 V (150K)
R207 7030005451 S.RES ERA3YED 153V (15K)
R208 7030005321 S.RES ERA3YED 103V (10K)
R209 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R210 7030003740 S.RES ERJ3GEYJ 334 V (330K)
C101 4030007070 S.CER C1608 CH 1H 330J-T
C102 4030007070 S.CER C1608 CH 1H 330J-T
C103 4030008650 S.CER C1608 JB 1H 332K-T
C104 4030008650 S.CER C1608 JB 1H 332K-T
C105 4030007130 S.CER C1608 CH 1H 101J-T
C106 4030007130 S.CER C1608 CH 1H 101J-T
C107 4030011600 S.CER C1608 JB 1E 104K-T
C108 4030011600 S.CER C1608 JB 1E 104K-T
C109 4030011600 S.CER C1608 JB 1E 104K-T
C110 4030011600 S.CER C1608 JB 1E 104K-T
C111 4030011600 S.CER C1608 JB 1E 104K-T
C112 4510009700 S.ELE EEEFK1C101P
C113 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B)
C114 4030018960 S.CER C3216 JB 1C 106MT-N
C115 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B)
C116 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B)
C117 4030019500 S.CER GRM21BB31A106KE18
(GRM40 B)
C201 4510009700 S.ELE EEEFK1C101P
C202 4030011600 S.CER C1608 JB 1E 104K-T
C203 4030011600 S.CER C1608 JB 1E 104K-T
C204 4030018960 S.CER C3216 JB 1C 106MT-N
C205 4030018960 S.CER C3216 JB 1C 106MT-N
C206 4030010020 S.CER C1608 JB 1H 122K-T
C207 4030007070 S.CER C1608 CH 1H 330J-T
C208 4030008860 S.CER C1608 JB 1H 153K-T
C209 4030011600 S.CER C1608 JB 1E 104K-T
C210 4030011600 S.CER C1608 JB 1E 104K-T
C211 4030019090 S.CER C2012 JB 1C 225M-T
C212 4030011600 S.CER C1608 JB 1E 104K-T
C213 4030017490 S.CER C1608 JB 1A 105K-T
C214 4030018960 S.CER C3216 JB 1C 106MT-N
J1 6910020210 CON IMSA-9180S-12Z900
F1 5210001050 S.FUS ICP-S0.5TN
EP101 6910014730 S.BEA MPZ2012S331A-T
EP102 6910014730 S.BEA MPZ2012S331A-T
EP103 6910014730 S.BEA MPZ2012S331A-T
EP201 6910014730 S.BEA MPZ2012S331A-T
EP202 6910014730 S.BEA MPZ2012S331A-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V
M.
LOCATION
T 51.2/22.5
T 11/12.7
T 22.8/15.8
T 59.9/21.7
T 42.4/21.7
T 23.4/27.3
T 64/11.8
T 67.2/24.2
T 35.1/24.2
T 7.4/28.5
T 22.6/31.5
T 21.5/20.6
T 19.7/16.5
T 52.6/30.8
T 49.8/30.8
T 55.4/32.1
T 47/30.8
T 52.6/29.5
T 57.4/28.7
T 44.9/28.7
T 60.1/30.8
T 44.2/30.8
T 47/32.1
T 58/30.8
T 23.8/8.4
T 22.5/8.4
T 20.5/6.4
T 20.5/9
T 15.6/9.6
T 21.3/12.3
T 19.2/10.3
T 18.5/8.2
T 19.2/11.6
T 23.2/13
T 55.4/30.8
T 49.6/32.1
T 55.4/29.5
T 47/29.5
T 47/28.2
T 55.4/28.2
T 52.4/28.2
T 49.8/29.5
T 55.7/17.2
T 46.6/17.2
T 52.7/17.2
T 47.4/10
T 59.1/27.7
T 52.8/13.9
T 41.5/27.7
T 60.8/27.7
T 43.3/27.7
T 7.7/20.8
T 14/26
T 18.6/24.7
T 19.1/26.4
T 17.2/16.5
T 20.5/7.7
T 16.9/10.1
T 19.2/12.9
T 23.2/11.7
T 6.4/8.9
T 12.4/26.3
T 5.6/13.4
T 5/11.4
T 19.1/28.6
T 51.5/41.1
T 61.7/31
T 40.9/31
T 71.3/16.1
T 19.2/31.5
T 12.4/31
S.=Surface mount
