Icom IC-7600 Service Manual page 151

Apr. 2009
[PLL UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R111 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R112 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R113 7030003510 S.RES ERJ3GEYJ 392 V (3.9K)
R114 7030003320 S.RES ERJ3GEYJ 101 V (100)
R115 7030003320 S.RES ERJ3GEYJ 101 V (100)
R116 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R131 7030003320 S.RES ERJ3GEYJ 101 V (100)
R133 7030003350 S.RES ERJ3GEYJ 181 V (180)
R152 7030003400 S.RES ERJ3GEYJ 471 V (470)
R154 7030003320 S.RES ERJ3GEYJ 101 V (100)
R155 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R157 7030003360 S.RES ERJ3GEYJ 221 V (220)
R158 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R159 7030003200 S.RES ERJ3GEYJ 100 V (10)
R160 7030003370 S.RES ERJ3GEYJ 271 V (270)
R161 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R181 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R182 7030003530 S.RES ERJ3GEYJ 562 V (5.6K)
R191 7030003320 S.RES ERJ3GEYJ 101 V (100)
R192 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R193 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R202 7030003860 S.RES ERJ3GE JPW V
R203 7030006521 S.RES ERA3YED 561V (560)
R204 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R222 7030009841 S.RES ERA3YHD 330V (33)
R223 7030009861 S.RES ERA3YED 471V (470)
R224 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R252 7030009851 S.RES ERA3YED 271V (270)
R253 7030006521 S.RES ERA3YED 561V (560)
R254 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R272 7030006521 S.RES ERA3YED 561V (560)
R273 7030006521 S.RES ERA3YED 561V (560)
R274 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R275 7030003280 S.RES ERJ3GEYJ 470 V (47)
R281 7030008240 S.RES ERJ12Y0R00U
R282 7030008240 S.RES ERJ12Y0R00U
R283 7030008240 S.RES ERJ12Y0R00U
R284 7030008240 S.RES ERJ12Y0R00U
R301 7030003470 S.RES ERJ3GEYJ 182 V (1.8K)
R302 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R303 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R304 7030003260 S.RES ERJ3GEYJ 330 V (33)
R305 7030003860 S.RES ERJ3GE JPW V
R309 7030003410 S.RES ERJ3GEYJ 561 V (560)
R321 7030003860 S.RES ERJ3GE JPW V
R323 7030003200 S.RES ERJ3GEYJ 100 V (10)
R352 7030003410 S.RES ERJ3GEYJ 561 V (560)
R353 7030007860 S.RES ERJ3GEYJ 8R2V (8.2)
R354 7030003410 S.RES ERJ3GEYJ 561 V (560)
R361 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R362 7030003320 S.RES ERJ3GEYJ 101 V (100)
R363 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R380 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R385 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R386 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R387 7030003360 S.RES ERJ3GEYJ 221 V (220)
R392 7030003860 S.RES ERJ3GE JPW V
R393 7030009961 S.RES ERA3YED 221V (220)
R394 7030007230 S.RES ERA3YED 102V (1K)
R401 7030007220 S.RES ERA3YED 202V (2K)
R402 7030007220 S.RES ERA3YED 202V (2K)
R403 7030007230 S.RES ERA3YED 102V (1K)
R404 7030007220 S.RES ERA3YED 202V (2K)
R405 7030007230 S.RES ERA3YED 102V (1K)
R406 7030007220 S.RES ERA3YED 202V (2K)
R407 7030007230 S.RES ERA3YED 102V (1K)
R408 7030007220 S.RES ERA3YED 202V (2K)
R409 7030007230 S.RES ERA3YED 102V (1K)
R410 7030007220 S.RES ERA3YED 202V (2K)
R411 7030007230 S.RES ERA3YED 102V (1K)
R412 7030007220 S.RES ERA3YED 202V (2K)
R413 7030007230 S.RES ERA3YED 102V (1K)
R414 7030007220 S.RES ERA3YED 202V (2K)
R415 7030007210 S.RES ERA3YEB 102V (1K)
R416 7030007200 S.RES ERA3YEB 202V (2K)
R417 7030007210 S.RES ERA3YEB 102V (1K)
R418 7030007200 S.RES ERA3YEB 202V (2K)
R419 7030007210 S.RES ERA3YEB 102V (1K)
R420 7030007200 S.RES ERA3YEB 202V (2K)
R421 7030007210 S.RES ERA3YEB 102V (1K)
R422 7030007200 S.RES ERA3YEB 202V (2K)
R423 7030007210 S.RES ERA3YEB 102V (1K)
R424 7030007200 S.RES ERA3YEB 202V (2K)
R425 7030009861 S.RES ERA3YED 471V (470)
R427 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R428 7030003320 S.RES ERJ3GEYJ 101 V (100)
R430 7030003200 S.RES ERJ3GEYJ 100 V (10)
R431 7030003320 S.RES ERJ3GEYJ 101 V (100)
R432 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R433 7030003360 S.RES ERJ3GEYJ 221 V (220)
R434 7030003240 S.RES ERJ3GEYJ 220 V (22)
R435 7030003330 S.RES ERJ3GEYJ 121 V (120)
R436 7030003220 S.RES ERJ3GEYJ 150 V (15)
R437 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R438 7030003320 S.RES ERJ3GEYJ 101 V (100)
R439 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R440 7030003370 S.RES ERJ3GEYJ 271 V (270)
R441 7030003320 S.RES ERJ3GEYJ 101 V (100)
R442 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R443 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R444 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R445 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R446 7030003360 S.RES ERJ3GEYJ 221 V (220)
R447 7030003440 S.RES ERJ3GEYJ 102 V (1K)
[PLL UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
T 117.3/97.4 R448 7030003860 S.RES ERJ3GE JPW V
T 115.3/94.6 R449 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 104.8/96.9 R450 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 101.5/99.9 R451 7030005871 S.RES ERA3YKD 104V (100K)
B 103.1/100.7 R452 7030005871 S.RES ERA3YKD 104V (100K)
T 105.9/108 R453 7030003340 S.RES ERJ3GEYJ 151 V (150)
T 93.1/76.3 R454 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 93.9/78.2 R455 7030003350 S.RES ERJ3GEYJ 181 V (180)
T 124.6/105.3 R456 7030003650 S.RES ERJ3GEYJ 563 V (56K)
B 115/101 R457 7030003360 S.RES ERJ3GEYJ 221 V (220)
B 125/104.4 R459 7030003220 S.RES ERJ3GEYJ 150 V (15)
B 121.7/103.5 R460 7030003220 S.RES ERJ3GEYJ 150 V (15)
B 120.7/107.2 R461 7030003310 S.RES ERJ3GEYJ 820 V (82)
T 85.5/67.3 R462 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 84.7/69.4 R463 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 82.7/72.1 R464 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 55.8/78 R471 7030003860 S.RES ERJ3GE JPW V
T 53.8/80.1 R481 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 75.7/39.8 R482 7030003530 S.RES ERJ3GEYJ 562 V (5.6K)
T 77.6/39 R502 7030006521 S.RES ERA3YED 561V (560)
T 78.2/34.6 R503 7030006521 S.RES ERA3YED 561V (560)
T 61.9/88.1 R504 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 73.7/104.9 R522 7030009841 S.RES ERA3YHD 330V (33)
T 72.4/99.5 R523 7030009861 S.RES ERA3YED 471V (470)
T 45/88.1 R524 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.9/104.9 R552 7030009851 S.RES ERA3YED 271V (270)
T 55.5/99.5 R553 7030006521 S.RES ERA3YED 561V (560)
T 28.3/88.1 R554 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 40.1/104.9 R572 7030006521 S.RES ERA3YED 561V (560)
T 38.8/99.5 R573 7030006521 S.RES ERA3YED 561V (560)
T 12.3/87.9 R574 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 23.3/104.9 R575 7030003280 S.RES ERJ3GEYJ 470 V (47)
T 22/99.6 R581 7030008240 S.RES ERJ12Y0R00U
T 30.6/77.9 R582 7030008240 S.RES ERJ12Y0R00U
B 33.1/92.5 R583 7030008240 S.RES ERJ12Y0R00U
B 49.7/92.5 R601 7030003470 S.RES ERJ3GEYJ 182 V (1.8K)
B 66.4/92.5 R602 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
B 78.2/106.7 R603 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 33.2/77.9 R604 7030003260 S.RES ERJ3GEYJ 330 V (33)
T 31.2/76.1 R609 7030003860 S.RES ERJ3GE JPW V
T 38.8/74.2 R621 7030003860 S.RES ERJ3GE JPW V
T 31.7/71.5 R623 7030003200 S.RES ERJ3GEYJ 100 V (10)
T 45.1/74.2 R624 7030003860 S.RES ERJ3GE JPW V
T 63.4/67.5 R652 7030003370 S.RES ERJ3GEYJ 271 V (270)
T 45.1/71.5 R653 7030003230 S.RES ERJ3GEYJ 180 V (18)
T 40.4/63.6 R654 7030003370 S.RES ERJ3GEYJ 271 V (270)
T 14.2/78.3 R661 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 13.5/75.2 R662 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 12.3/75.2 R663 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 25.6/73.2 R680 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 21.7/74.2 R685 7030003440 S.RES ERJ3GEYJ 102 V (1K)
B 20/75 R686 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 71/66.2 R687 7030003360 S.RES ERJ3GEYJ 221 V (220)
T 75.5/68.1 R692 7030003860 S.RES ERJ3GE JPW V
T 75.6/69.3 R693 7030009651 S.RES ERA3YHD 820V (82)
T 75.5/70.5 R694 7030007230 S.RES ERA3YED 102V (1K)
T 68/74.5 R701 7030007200 S.RES ERA3YEB 202V (2K)
T 69.3/74.5 R702 7030007210 S.RES ERA3YEB 102V (1K)
T 66/73.8 R703 7030007200 S.RES ERA3YEB 202V (2K)
T 115.7/28.7 R704 7030007210 S.RES ERA3YEB 102V (1K)
T 114.4/28.7 R705 7030007200 S.RES ERA3YEB 202V (2K)
T 115.1/30.8 R706 7030007210 S.RES ERA3YEB 102V (1K)
T 112.1/27.4 R707 7030007220 S.RES ERA3YED 202V (2K)
T 113/29.4 R708 7030007230 S.RES ERA3YED 102V (1K)
T 110.3/27.2 R709 7030007220 S.RES ERA3YED 202V (2K)
T 110.9/29.3 R710 7030007230 S.RES ERA3YED 102V (1K)
T 109/27.2 R711 7030007220 S.RES ERA3YED 202V (2K)
T 108.1/30.6 R712 7030007230 S.RES ERA3YED 102V (1K)
T 107.7/27.2 R713 7030007220 S.RES ERA3YED 202V (2K)
T 108.1/29.3 R714 7030007230 S.RES ERA3YED 102V (1K)
T 106.4/27.2 R715 7030007220 S.RES ERA3YED 202V (2K)
T 105.2/30.6 R716 7030007230 S.RES ERA3YED 102V (1K)
T 105.1/27.2 R717 7030007220 S.RES ERA3YED 202V (2K)
T 105.2/29.3 R718 7030007230 S.RES ERA3YED 102V (1K)
T 103.8/27.2 R719 7030007220 S.RES ERA3YED 202V (2K)
T 102.3/30.6 R720 7030007220 S.RES ERA3YED 202V (2K)
T 102.5/27.2 R721 7030003650 S.RES ERJ3GEYJ 563 V (56K)
T 102.3/29.3 R722 7030003370 S.RES ERJ3GEYJ 271 V (270)
T 101.2/27.2 R724 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
T 99.4/30.6 R726 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
T 99.9/27.2 R727 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 99.4/29.3 R728 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 98.6/27.2 R729 7030003360 S.RES ERJ3GEYJ 221 V (220)
T 97.3/27.2 R730 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 92.9/9.2 R731 7030003470 S.RES ERJ3GEYJ 182 V (1.8K)
B 115.9/3.9 R732 7030003340 S.RES ERJ3GEYJ 151 V (150)
T 88.1/11.3 R734 7030003340 S.RES ERJ3GEYJ 151 V (150)
T 90/23.7 R735 7030003360 S.RES ERJ3GEYJ 221 V (220)
T 95/23.9 R736 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 92.1/16.4 R801 7030003260 S.RES ERJ3GEYJ 330 V (33)
T 89.4/16.4 R802 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 97.1/2.8 R803 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
T 94.5/2.8 R804 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
T 97.1/4.3 R805 7030003370 S.RES ERJ3GEYJ 271 V (270)
B 91.7/11 R806 7030003230 S.RES ERJ3GEYJ 180 V (18)
T 115.6/10.6 R807 7030003370 S.RES ERJ3GEYJ 271 V (270)
T 115.7/8.2 R808 7030003350 S.RES ERJ3GEYJ 181 V (180)
T 90.4/21.6 R811 7030003370 S.RES ERJ3GEYJ 271 V (270)
B 99.6/6.5 R812 7030003230 S.RES ERJ3GEYJ 180 V (18)
B 116.3/20.5 R813 7030003370 S.RES ERJ3GEYJ 271 V (270)
B 114.7/20.5 R831 7030003330 S.RES ERJ3GEYJ 121 V (120)
T 115/20.8 R832 7030003280 S.RES ERJ3GEYJ 470 V (47)
T 116.2/20 R833 7030003330 S.RES ERJ3GEYJ 121 V (120)
B 100.4/14.9 R834 7030003380 S.RES ERJ3GEYJ 331 V (330)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
16
DESCRIPTION M.
LOCATION
T 115.7/9.4
T 115.2/5.1
T 66.9/33.2
T 64/46.2
T 56.1/43.7
T 56.5/38.7
T 58.7/46.3
T 61.3/46.2
T 60.1/33.1
T 54.2/34.8
T 57.1/31.9
T 55.2/31.2
T 58.9/31.2
T 115.9/15.6
T 72.6/51.3
T 71.3/52
T 89.8/18.3
T 20.9/34.2
T 19.6/32.4
T 42.9/21.9
T 31.1/5.1
T 32.2/10.5
T 26/21.9
T 14.2/5.1
T 15.3/10.4
T 59.7/21.8
T 47.8/5.1
T 48.9/10.4
T 75.5/21.8
T 64.6/5.1
T 65.7/10.4
B 35/35.4
B 21.8/17.6
B 37.8/17.6
B 54.8/17.6
T 38.7/37.4
T 44.1/36.5
T 44.1/38.9
B 40.7/39.7
T 18.7/40.4
T 41.9/47.3
T 31.2/47.4
T 36.5/48.1
T
T 5/22.9
T 3.7/24.1
T 3.5/30.3
B 4.5/29.9
B 2.1/29.6
B 41.4/46.8
T 23.5/41.7
T 23.5/40.5
T 23.5/39.3
T 25.2/34.7
T 28.2/34.7
T 29.5/34.5
T 135.4/5.4
T 134.6/3.4
T 134.1/5.4
T 133.3/2.1
T 132.8/5.4
T 132/3.4
T 131.5/5.4
T 130.7/2.1
T 130.2/5.5
T 129.4/3.6
T 128.9/5.5
T 128.1/2.3
T 127.6/5.5
T 126.8/3.6
T 126.3/5.5
T 124.4/2.3
T 125/5.5
T 124.2/3.6
T 123.7/5.5
T 122.4/5.5
B 124.9/14.6
B 124.9/16.7
T 145/10.8
T 143.9/17.8
T 127.8/23.7
T 126.6/23.7
T 129/23.7
T 139.6/15.4
T 142/17.3
T 144.6/19.8
B 148.1/15.4
B 150.4/14.6
B 124.9/20.9
T 125.6/50.4
T 125.6/45.2
T 130.3/47
T 133.4/47.7
B 128.5/37.1
B 126.4/36.3
B 124.3/35.5
T 128.7/43.7
T 143.5/22.4
T 140.4/23.1
T 143.5/23.7
B 141.5/35.7
B 139.4/36.3
B 141.5/37.1
T 152.2/38.1
S.=Surface mount
H/V
5/27
