4-2 REFERENCE FREQUENCY SIGNAL LEVEL ADJUSTMENT
ADJUSTMENT
ADJUSTMENT CONDITION
REFERENCE
1 • Receiving
FREQUENCY
SIGNAL
LEVEL
1) Connect a RF Voltmeter to J81.
2) Adjust the reference frequency
signal level.
<Viewing from the BOTTOM side>
MAIN UNIT
REFERENCE SIGNAL LEVEL
REFERENCE SIGNAL LEVEL
J81
J81
REFERENCE SIGNAL LEVEL
REFERENCE SIGNAL LEVEL
(CHECK POINT)
(CHECK POINT)
4 - 2
OPERATION
PLL
UNIT
RF UNIT
L61
L61
L62
L62
ADJUSTMENT
VALUE
POINT
L61, L62
Maximum
(repeatedly)
level
