Icom IC-7600 Service Manual page 80

[DISPLAY UNIT] (DS)
REF ORDER
NO. NO.
S1202* 2260002740 LS8J2M
S1203* 2260002740 LS8J2M
S1204* 2260002740 LS8J2M
S1205* 2260002740 LS8J2M
S1206* 2260002740 LS8J2M
S1207* 2260002740 LS8J2M
S1208* 2260002740 LS8J2M
S1209* 2260002740 LS8J2M
S1210* 2260002740 LS8J2M
S1211* 2260002740 LS8J2M
S1212* 2260002740 LS8J2M
S1213* 2260002740 LS8J2M
S1214* 2260002740 LS8J2M
S1215* 2260002740 LS8J2M
EP2 6910020190 L5S30853P00
MP1 8930077470 3073 EARTH SHIELD
MP2 8930077470 3073 EARTH SHIELD
MP3 8510002280 VCOSHIELD PLATE (A) (FX-15)
MP4 8510002280 VCOSHIELD PLATE (A) (FX-15)
MP11 8930077000 3073 LCD HOLDER
MP12 8930078950 3073 A-LCD SPONGE
MP13 8930062550 SPONGE (HP)
MP23 8930043610 INSULATION SHEET (EZ)
MP24 8930043610 INSULATION SHEET (EZ)
MP33 8930072060 SHIELD SPONGE (BU)
MP34 8930072060 SHIELD SPONGE (BU)
MP35 8930055981 SHIELD SPONGE (F)-1
MP36 8930055981 SHIELD SPONGE (F)-1
MP37 8930055981 SHIELD SPONGE (F)-1
MP38 8930049131 SHIELD TAPE (D)-1
MP39 8930049131 SHIELD TAPE (D)-1
MP40 8930049131 SHIELD TAPE (D)-1
MP41 8930049131 SHIELD TAPE (D)-1
MP51 8930058700 SHIELD SPONGE (R)
MP52 8930058700 SHIELD SPONGE (R)
MP53 8930058700 SHIELD SPONGE (R)
[VR-A UNIT] (VRA)
REF ORDER
NO. NO.
R1 7210002970 RV-314 (RK0972210 10KB/10KB)
R2 7210002970 RV-314 (RK0972210 10KB/10KB)
J32* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J33* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN)
[VR-B UNIT] (VRB)
REF ORDER
NO. NO.
R1 7210002970 RV-314 (RK0972210 10KB/10KB)
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
S1 2250000410 TP90D96E20-30F-2178-1
[VR-C UNIT] (VRC)
REF ORDER
NO. NO.
R1 7210001130 RK097111T005A 10KB
R2 7210001130 RK097111T005A 10KB
R3 7210001130 RK097111T005A 10KB
R4 7210001130 RK097111T005A 10KB
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
[RIT UNIT] (RIT)
REF ORDER
NO. NO.
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
S1 2250000650 EVEGC2F2524B
[MIC UNIT] (MIC)
REF ORDER
NO. NO.
J1 6510000191 FM214-8SS (P)-1
J2* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
[JACK UNIT] (JCK)
REF ORDER
NO. NO.
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J2 6510023891 S-G4617#01F
J102 6510023900 LGR4619-7000
6 - 2
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
1
1
