SECTION 5.

[LOGIC UNIT]

REF PARTS
DESCRIPTION
NO. NO.
IC1 1130013750 S.IC EM639165TS-7G
IC2 1130013750 S.IC EM639165TS-7G
IC21 1130015113 S.IC JS28F128J3D-75(SX-3073A-3)
IC51 1130011591 S.IC IDT70V24L15PFG
IC53 1110005731 S.IC S-80928CNMC-G8Y-G
IC54 1130007431 S.IC TC7S14FU(TE85R,F)
IC55 1130012600 S.IC SN74AHC1G04DCKR
IC102 1130013010 S.IC SN74AHC1G08DCK3
IC103 1140014730 S.IC HD6417751RBG240V
IC105 1130015120 S.IC CY22393FXC(SX-3073F)
IC201 1130013750 S.IC EM639165TS-7G
IC202 1130013750 S.IC EM639165TS-7G
IC203 1140011571 S.IC HD64404BTDV
IC208 1130014030 S.IC BD6516F-E2
IC209 1190001920 S.IC AK5355-VT-E2
IC210 1190001920 S.IC AK5355-VT-E2
IC211 1190001910 S.IC AK4384-VT-E2
IC604 1140014710 S.IC HD64F2370VFQ34V
IC605 1140015050 S.IC XC9572XL-10TQG100C
(SX-3073E)
IC607 1130013010 S.IC SN74AHC1G08DCK3
IC608 1130013010 S.IC SN74AHC1G08DCK3
IC609 1130005252 S.IC TC74HC08AF(EL,F)
IC610 1130014800 S.IC R1EX24064ATA00A
IC661 1130012600 S.IC SN74AHC1G04DCKR
IC721 1130010111 S.IC TC7WH04FU(TE12L,F)
IC851 1180003100 S.REG BD9302FP-E2
IC871 1180003100 S.REG BD9302FP-E2
IC901 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC902 1110003870 S.IC NJM2058M-TE1-#ZZZB
Q725 1510000771 S.TRA 2SA1586-GR(TE85L,F)
Q727 1530003900 S.TRA KTC4075 BL-RTK/P
Q731 1590003680 S.TRA KRC402 RTK/P
Q1031 1560001221 S.FET ECH8301-TL-E
D51 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D52 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D53 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D54 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D55 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D56 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D57 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D58 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D59 1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
D60 1750001320 S.DIO KDS4148U RTK/P
D61 1750001320 S.DIO KDS4148U RTK/P

PARTS LIST

[LOGIC UNIT]
H/V REF
M.
LOCATION NO.
T 109/62.6 D62
T 84.1/62.6 D63
T 103.2/37.1 D66
B 119.8/87.1 D67
B 65.8/89.4
B 61/88.6
B 58.1/87.9
T 115.7/35.5 D68
T 70.8/30.7 D101
B 97.8/18 D102
T 8.9/79.8 D206
B 14.8/80.1 D207
T 40.7/80.6 D711
T 65.8/95.2 D715
B 90.8/6.7 D727
B 76.7/6.7 D731
B 65.9/6.7 D732
B 140.3/66.4 D851
D852
B 131.9/35.3 D871
T 142.8/87 D872
T 148.5/87 D901
T 119/77.2 D902
T 148/64.6 D903
T 147.8/77.7 D904
B 150.5/43.3 D905
T 179.5/87.9 D906
T 180.1/52.2 D907
B 141.1/6.6 D909
B 124.1/6.6 D910
D911
D912
B 155/39 D913
B 155.1/41.5
B 147.9/36.7
T 190.2/30.4 X101
X201
X202
[USA] T 52.5/27.1 X601
[EUR]
[EUR-1]
[ESP] L801
[KOR] L803
[TPE] L851
[CHN] L852
[ITR] L853
[EXP] L871
[EUR-1] T 52.5/23.6 L872
[ESP] L873
[KOR]
[TPE]
[CHN] R1
[FRA] R51
[EXP] R52
[USA] T 52.5/25.3 R53
[EUR] R54
[EUR-1] R61
[TPE] R62
[CHN] R91
[USA] T 52.5/28.8 R92
[EUR] R93
[EUR-1] R94
[ESP] R95
[KOR] R96
[TPE] R97
[ITR] R98
[EUR] T 52.5/20.1 R99
[EUR-1] R102
[ESP] R103
[CHN] R104
[ITR] R105
[EXP] R106
[EUR-1] T 52.5/21.8 R107
[ESP] R108
[KOR] R109
[TPE] R110
[CHN] R111
[FRA] R112
[EXP] R113
[USA] T 52.5/18.3 R114
[EUR] R115
[EUR-1] R116
[TPE] R117
[CHN] R118
[USA] T 52.5/16.6 R119
[EUR] R120
[EUR-1] R121
[ESP] R122
[KOR] R123
[ITR] R125
[EUR] T 52.5/14.8 R126
[EUR-1] R128
[ESP] R129
[CHN] R130
[ITR] R131
[EXP] R132
T 56.3/27.1 R133
T 56.3/23.6 R134
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 1
PARTS
DESCRIPTION
NO.
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1750001320 S.DIO KDS4148U RTK/P
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1750001320 S.DIO KDS4148U RTK/P
1790001241 S.DIO MA2S7280GL
1750001320 S.DIO KDS4148U RTK/P
1750001180 S.DIO KDS122 RTK/P
1750001180 S.DIO KDS122 RTK/P
1750000960 S.DIO RB081L-20
1750000960 S.DIO RB081L-20
1750000960 S.DIO RB081L-20
1750000960 S.DIO RB081L-20
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
1790000980 S.DIO MA742(TX)
6050011610 S.XTA CR-751 SMD-49 25.000 MHz
6050010680 S.XTA CR-628 SMD-49 24.576 MHz
6050011910 S.XTA CR-780 DSX530G 48 MHz
6050011810 S.XTA CR-755 SMD-49 15.9744 MHz
6200005011 S.COI NLV25T-100J
6200005011 S.COI NLV25T-100J
6200013280 S.COI SLF10145T-330M1R6-PF
6200013280 S.COI SLF10145T-330M1R6-PF
6200010881 S.COI CDRH124NP-330MC
6200013280 S.COI SLF10145T-330M1R6-PF
6200013280 S.COI SLF10145T-330M1R6-PF
6200010881 S.COI CDRH124NP-330MC
7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003640 S.RES ERJ3GEYJ 473 V (47K)
7030003640 S.RES ERJ3GEYJ 473 V (47K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003260 S.RES ERJ3GEYJ 330 V (33)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003560 S.RES ERJ3GEYJ 103 V (10K)
7030003200 S.RES ERJ3GEYJ 100 V (10)
H/V
M.
LOCATION
T 56.3/25.3
T 56.3/28.8
T 56.3/18.3
[EUR] T 56.3/16.6
[EUR-1]
[ITR]
[FRA]
T 56.3/14.8
B 66.5/18.7
B 68.2/18.7
T 45.8/95.6
T 49.2/95.6
B 154.5/63.6
B 154.5/65.2
B 155.1/43.7
B 145/36.7
B 150.8/36.6
T 188.1/88.1
T 171/86.2
T 171.4/52.2
T 188.7/52.2
B 161.5/33.9
B 176.5/33.9
B 164/33.9
B 166.5/33.9
B 169/33.9
B 171.5/33.9
B 174/33.9
T 120.5/11.1
T 120.5/13.6
T 101.3/6.3
T 101.3/3.8
B 159.6/31.1
T 97.8/18.1
T 36.8/63.7
T 37.6/97.5
T 126.6/65.3
T 63/8
B 157.1/32.2
T 196.3/89.3
T 164.1/83.7
T 192.9/77.3
T 164.6/53.5
T 196.9/49.9
T 193.4/62
T 107.7/24.3
T 130.2/45.4
B 63.2/89.4
B 109.6/87.6
B 129.3/88.4
T 53.6/30.4
T 56.6/30.4
T 53.6/43.8
B 56.6/37.6
T 56/50.4
T 55.2/47.4
T 56.4/47.4
T 57.6/47.4
T 57.2/50.4
T 59.6/50.4
T 58.8/47.4
T 71/19
T 68.6/19
T 54.8/50.4
T 58.4/50.4
B 71/19
T 67.4/19
B 69.8/19
T 69.8/16
T 71/16
T 72.2/19
T 68.6/16
T 65/16
T 66.2/16
T 66.2/19
T 65/19
T 63.8/19
T 63.8/16
T 61.4/19
B 56.6/24.4
T 60.2/16
T 61.4/16
T 60.2/19
T 67.4/16
T 69.8/19
T 72.2/16
T 73.4/19
B 73.4/19
B 75.1/19
B 72.2/19
T 73.4/16
T 77.6/19
S.=Surface mount
