Pll Unit - Icom IC-7600 Service Manual

[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
EP1608 6910015970 S.BEA MMZ1608B 301CT-AS
EP1609 6910012350 S.BEA MMZ1608Y 102BT
EP1610 6910012350 S.BEA MMZ1608Y 102BT
EP1611 6910012350 S.BEA MMZ1608Y 102BT
EP1612 6910014690 S.BEA MPZ1608S221A-T
EP1613 6910014690 S.BEA MPZ1608S221A-T
EP1614 6910014690 S.BEA MPZ1608S221A-T
EP1615 6910014690 S.BEA MPZ1608S221A-T
EP1616 6910014690 S.BEA MPZ1608S221A-T
EP1617 6910014640 S.BEA MPZ2012S221A-T
EP1618 6910014690 S.BEA MPZ1608S221A-T
EP1701 6910014690 S.BEA MPZ1608S221A-T
EP1702 6910012350 S.BEA MMZ1608Y 102BT
EP1703 6910012350 S.BEA MMZ1608Y 102BT
EP1704 6910014690 S.BEA MPZ1608S221A-T
EP1705 6910012350 S.BEA MMZ1608Y 102BT
EP1706 6910012350 S.BEA MMZ1608Y 102BT
EP1707 6910014690 S.BEA MPZ1608S221A-T
EP1708 6910014690 S.BEA MPZ1608S221A-T
EP1709 6910014690 S.BEA MPZ1608S221A-T
EP1710 6910014640 S.BEA MPZ2012S221A-T
EP1801 6910014690 S.BEA MPZ1608S221A-T
EP1802 6910014690 S.BEA MPZ1608S221A-T
EP1803 6910014690 S.BEA MPZ1608S221A-T
EP1804 6910014690 S.BEA MPZ1608S221A-T
EP1805 6910014690 S.BEA MPZ1608S221A-T
EP1901 6910018930 S.BEA MPZ2012S601A
EP1902 6910018930 S.BEA MPZ2012S601A
EP2001 6910014690 S.BEA MPZ1608S221A-T
EP2002 6910014690 S.BEA MPZ1608S221A-T
EP2003 6910014690 S.BEA MPZ1608S221A-T
EP2004 6910014690 S.BEA MPZ1608S221A-T
EP2031 6910014690 S.BEA MPZ1608S221A-T
EP2101 6910012350 S.BEA MMZ1608Y 102BT
EP2102 6910012350 S.BEA MMZ1608Y 102BT
EP2103 6910012350 S.BEA MMZ1608Y 102BT
EP2104 6910012350 S.BEA MMZ1608Y 102BT
EP2121 6910012350 S.BEA MMZ1608Y 102BT
EP2131 6910012350 S.BEA MMZ1608Y 102BT
EP2132 6910012350 S.BEA MMZ1608Y 102BT
EP2201 6910012350 S.BEA MMZ1608Y 102BT
EP2301 6910014730 S.BEA MPZ2012S331A-T
EP2302 6910014730 S.BEA MPZ2012S331A-T
EP2303 6910014730 S.BEA MPZ2012S331A-T
EP2304 6910014730 S.BEA MPZ2012S331A-T
EP2401 6910015970 S.BEA MMZ1608B 301CT-AS
EP2402 6910015970 S.BEA MMZ1608B 301CT-AS
EP3001 6910012350 S.BEA MMZ1608Y 102BT
EP3601 6910012350 S.BEA MMZ1608Y 102BT
EP3602 6910012350 S.BEA MMZ1608Y 102BT
EP3715 6910015970 S.BEA MMZ1608B 301CT-AS
EP4101 6910014730 S.BEA MPZ2012S331A-T
EP5001 6910014690 S.BEA MPZ1608S221A-T
EP5101 6910014690 S.BEA MPZ1608S221A-T
EP6001 6910015970 S.BEA MMZ1608B 301CT-AS

[PLL UNIT]

H/V REF PARTS
M.
LOCATION NO. NO.
T 3.7/126 IC1 1180000421 S.IC
T 12.5/125.3 IC2 1130009691 S.IC
T 12.5/124 IC3 1130011530 S.IC
T 15.2/122.9 IC4 1130011530 S.IC
T 12.5/121 IC101 1190002101 S.IC
T 12.5/119.3 IC102 1130010560 S.IC
T 12.5/118 IC103 1180003190 S.REG UPD120N33TA-E1-A
T 3.7/116 IC104 1180003200 S.REG UPD120N18TA-E1-A
T 3.7/114.8 IC192 1130013010 S.IC
T 4/110.5 IC320 1110007400 S.IC
T 3.7/124.7 IC381 1130013270 S.IC
T 130/139.9 IC401 1130013010 S.IC
T 128.7/139.9 IC402 1130003831 S.IC
T 127.4/139.9 IC403 1140007881 S.IC
T 126.1/139.9 IC405 1130013010 S.IC
T 124.8/139.9 IC620 1110007400 S.IC
T 122.4/139.9 IC681 1130013270 S.IC
T 121.1/139.9 IC701 1140014960 S.IC
T 119.8/139.9
T 118.5/139.9
T 115.8/139.9 Q1 1590003680 S.TRA
T 41.7/142.5 Q51 1530003890 S.TRA
T 43/142.5 Q61 1530004011 S.TRA
T 44.3/142.5 Q71 1530003890 S.TRA
T 47/142.5 Q87 1530003890 S.TRA
T 48.3/142.5 Q121 1590003770 S.TRA
T 154.6/143 Q122 1590003680 S.TRA
T 158.2/143.1 Q123 1590003770 S.TRA
T 178.8/121.5 Q124 1590003680 S.TRA
T 178.8/124.1 Q125 1590003770 S.TRA
T 174.5/112.8 Q126 1590003680 S.TRA
T 178.8/120.2 Q127 1590003770 S.TRA
T 181.8/144.8 Q128 1590003680 S.TRA
B 192.2/62.7 Q151 1530003900 S.TRA
B 183.7/62.7 Q152 1530003340 S.TRA
T 175.3/30.3 Q181 1530003900 S.TRA
T 172.7/26.3 Q201 1560000491 S.FET
T 173.8/36.1 Q202 1530003960 S.TRA
T 158/58.7 Q221 1560000491 S.FET
T 158/60.4 Q222 1530003960 S.TRA
T 195.2/37 Q251 1560000491 S.FET
B 188.7/11.5 Q252 1530003960 S.TRA
B 183/19.2 Q271 1560000491 S.FET
B 186.4/17 Q272 1530003960 S.TRA
B 196.1/20 Q301 1530004011 S.TRA
B 193.5/79.5 Q361 1590003680 S.TRA
B 197.2/79.6 Q402 1530003900 S.TRA
B 136.9/38.8 Q403 1530003900 S.TRA
B 135.5/27.8 Q404 1590003770 S.TRA
B 132.5/25.6 Q421 1590003770 S.TRA
T 140.1/99 Q422 1590003680 S.TRA
B 2.3/79.1 Q423 1590003770 S.TRA
T 29.5/36.8 Q424 1590003680 S.TRA
T 38.9/76.6 Q425 1590003770 S.TRA
T 146.8/110.7 Q426 1590003680 S.TRA
Q427 1590003770 S.TRA
Q428 1590003680 S.TRA
Q451 1560000331 S.FET
Q452 1530003900 S.TRA
Q481 1530003900 S.TRA
Q501 1560000491 S.FET
Q502 1530003960 S.TRA
Q521 1560000491 S.FET
Q522 1530003960 S.TRA
Q551 1560000491 S.FET
Q552 1530003960 S.TRA
Q571 1560000491 S.FET
Q572 1530003960 S.TRA
Q601 1530004011 S.TRA
Q661 1590003680 S.TRA
Q681 1590003770 S.TRA
Q701 1530003900 S.TRA
Q702 1530003900 S.TRA
Q801 1530003890 S.TRA
Q831 1560000561 S.FET
Q851 1590003680 S.TRA
Q852 1590003770 S.TRA
Q853 1590003680 S.TRA
Q854 1590003770 S.TRA
Q1502 1590003680 S.TRA
Q1521 1590003680 S.TRA
Q1522 1590003770 S.TRA
Q2501 1590003680 S.TRA
Q2511 1590003680 S.TRA
Q2512 1590003770 S.TRA
D81 1750000581 S.DIO
D201 1720000831 S.VAR
D202 1720000831 S.VAR
D221 1720000831 S.VAR
D222 1720000831 S.VAR
D251 1750001720 S.VAR
D252 1750001720 S.VAR
D253 1750001720 S.VAR
D254 1750001720 S.VAR
D271 1750001720 S.VAR
D272 1750001720 S.VAR
D273 1750001720 S.VAR
D274 1750001720 S.VAR
D361 1750000581 S.DIO
D362 1750000581 S.DIO
D401 1750001320 S.DIO
D451 1720000681 S.VAR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 14
DESCRIPTION M.
TA78L05F(TE12R,F) B
TC74HCT7007AF(F) S T
CD74HC4094M96 T
CD74HC4094M96 T
AD9951YSVZ <FE> T
SN74AHC244PWR T
T
T
SN74AHC1G08DCK3 T
BGA616 T
ADF4116BRUZ <FE> T
SN74AHC1G08DCK3 T
TC7S04F(TE85R,F) T
TC190G08EFG0046JDZ/SC1246A T
SN74AHC1G08DCK3 T
BGA616 T
ADF4116BRUZ <FE> T
TC190G02EFG-0058/SC1287A T
KRC402 RTK/P T
KTC3880S Y-RTK/P T
KTC3770U-C-RTK/P T
KTC3880S Y-RTK/P T
KTC3880S Y-RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KRC402 RTK/P B
KTC4075 BL-RTK/P T
2SC3357-T1 RF B 117.3/106.5
KTC4075 BL-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
KTC3770U-C-RTK/P T
KRC402 RTK/P B
KTC4075 BL-RTK/P T
KTC4075 BL-RTK/P T
KRA302E-RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P T
2SK210-GR(TE85R,F) T
KTC4075 BL-RTK/P T
KTC4075 BL-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
2SK508-T2B-A K52 T
KTC2875-B-RTK/P T
KTC3770U-C-RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KTC4075 BL-RTK/P B
KTC4075 BL-RTK/P T
KTC3880S Y-RTK/P T
2SK882-GR(TE85L,F) T
KRC402 RTK/P T
KRA302E-RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KRC402 RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
KRC402 RTK/P T
KRC402 RTK/P B
KRA302E-RTK/P T
1SV307(TPH3,F) B
KV1770STL-G T
KV1770STL-G B
KV1770STL-G T
KV1770STL-G B
1SV215(TPH3,F) T
1SV215(TPH3,F) T
1SV215(TPH3,F) B
1SV215(TPH3,F) B
1SV215(TPH3,F) T
1SV215(TPH3,F) T
1SV215(TPH3,F) B
1SV215(TPH3,F) B
1SV307(TPH3,F) T
1SV307(TPH3,F) T
KDS4148U RTK/P B
1SV262(TPH2,F) T
S.=Surface mount
H/V
LOCATION
94.4/59.7
133.6/64.3
122.4/64.6
133/75.2
110.6/100.7
126.1/95.9
115.7/86.4
115.8/91.4
77.6/36.8
43.3/67.2
70/70.3
114/3.1
90.5/9.5
104.1/13.6
75.2/53.2
38.4/47.5
29.3/39.8
130.6/15.3
138.4/75.4
101.5/41.6
109.9/41.5
109.5/51.1
133.1/87.2
85.8/93.8
87.2/92.2
85.2/96.3
87.6/95.2
85.8/91.1
86.9/89.2
86/99
87.9/98.2
82.7/70.2
53.9/78.1
74.1/96.5
73.6/102.5
57.2/96.5
56.8/102.5
40.1/96.5
40/102.5
23.1/96.5
23.1/102.5
33.2/76
20.9/77.3
93.2/20.9
115.6/12.5
94.1/4.8
81.3/9.9
83.1/12.4
81.3/7.4
82.7/5
81.7/14.3
83.1/16.6
81.3/18.6
83.1/20.8
61/44
61.9/34.8
22.8/34.1
30.8/13.4
31.2/7.5
14/13.5
14.3/7.5
47.6/13.4
47.9/7.5
64.5/13.5
64.7/7.5
41/37
5.1/27.9
67.8/51.5
123.9/12.4
141.9/19.2
127.9/46.7
149.4/37.4
138/52.1
137.8/49.8
109.5/55.3
106.6/54.7
73/63.6
21.5/62.4
21.2/64.1
85.1/50.4
7.2/47.5
5.6/45.5
97/49.7
74.5/88.8
74.3/88.7
57.5/88.7
57.5/88.7
39.1/87.9
41.4/87.9
41.4/88
39.1/87.9
22.3/87.2
24.6/87.1
24.5/87.9
22.3/88
22.7/75.5
26.1/75.4
88.9/6.7
64.7/33.5
