Icom IC-7600 Service Manual page 79

SECTION 6.
[FRONT UNIT] (FR)
REF ORDER
NO. NO.
W1 8900018460 OPC-1950
W2 8900009231 OPC-908A
W3 8900017820 OPC-852A
W4 8900009231 OPC-908A
W5 8900009231 OPC-908A
W6 8900009231 OPC-908A
W7 8900018480 OPC-1952
W8 8900018480 OPC-1952
EP1 6910020500 RMS20-250-201-1P/E
EP2 6910015650 MOUNT PLATE (S-G2218-3#01)
EP3 6910015650 MOUNT PLATE (S-G2218-3#01)
MP1 8210025390 3073 FRONT PANEL (Incl. MP13–15)
MP2 8010021410 3073 SUB CHASSIS (Incl. MP3)
MP3 8930077140 3073 JACK PLATE
MP4 8310072650 3073 WINDOW PLATE
MP5 8510019120 3073 LOGIC COVER
MP11 8930076840 3073 A-LENS
MP12 8930076850 3073 B-LENS
MP13 8930076860 3073 C-LENS
MP14 8930076870 3073 D-LENS
MP15 8930076880 3073 E-LENS
MP21 8610013940 KNOB K-281 (Incl. MP11)
MP22 8610013950 KNOB K-282 (Incl. MP11)
MP23 8610013960 KNOB K-283 (Incl. MP12)
MP24 8610013810 KNOB K-284
MP25 8610013820 KNOB K-285
MP26 8610013830 KNOB K-286
MP27 8610013970 KNOB K-287 (Incl. MP12)
MP28 8610013850 KNOB K-288
MP29 8610013860 KNOB K-289
MP30 8930076890 3073 KEYBOARD
MP31 8610013870 KNOB N-378
MP32 8610013880 KNOB N-379
MP33 8610013290 KNOB N-361 (Incl. MP39)
MP34 8610011830 KNOB N-301 (Incl. MP39)
MP35 8610013900 KNOB N-380 (Incl. MP37, 39)
MP36 8610011741 KNOB N-307-1 (Incl. MP38)
MP37 8610013320 KNOB N-362 RING
MP38 8610009240 KNOB SPRING NO.7800P
MP39 8610007420 KNOB SPRING NO.6601
MP42 8610010040 KNOB N-239 FINGER REST
MP43 8930076900 3073 D-RUBBER
MP44 8930060190 2591 N-SPRING
MP45 8930076990 3073 BRAKE PLATE
MP46 8930076910 3073 BRAKE BUTTON (Incl. MP45)
MP47 8610013921 KNOB N-268 BASE-3 (Incl. MP42, 44, 51)
MP48 8310072900 3073 NAME PLATE
MP51 8930077340 3073 BRAKE SHEET
MP52 8930077360 3073 BRAKE PAD
MP53 8930077370 DOUBLE SIDE TAPE (BB)
MP54 8930077380 DOUBLE SIDE TAPE (BC)
MP55 8930074750 FERRITE SHEET (V)
MP56 8930059330 SHIELD SPONGE (W)
MP57 8930074750 FERRITE SHEET (V)
MP58 8930029050 THERMAL SHEET (AL)
MP61 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP62 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP63 8810008761 SCREW BT B0 2X8 NI-ZC3 (BT)
MP64 8930079010 SPONGE (KK)
MP65 8930061490 SHIELD SPONGE (AB)
MP66 8930055981 SHIELD SPONGE (F)-1
MP67 8930055981 SHIELD SPONGE (F)-1
MP68 8930055981 SHIELD SPONGE (F)-1
MP69 8930059330 SHIELD SPONGE (W)
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
MECHANICAL PARTS
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
5
1
3
1
1
1
1
1
1
1
1
1
1
1
3
1
3
1
)
4
1
4
5
1
1
1
1
1
1
1
1
2
2
2
1
1
1
2
4
6
17
4
1
1
1
1
1
[LOGIC UNIT] (LG)
REF ORDER
NO. NO.
J801* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J802* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J901* 6510018921 B8B-PH-SM4-TB (LF) (SN)
J1001* 6510024151 50FY-BMT-TB (LF) (SN)
J1002* 6510022191 B3B-PH-SM4-TB (LF) (SN)
J1101* 6510024151 50FY-BMT-TB (LF) (SN)
S51* 2260002740 LS8J2M
MP1 8930078890 3073 EARTH SPRING
MP2 8930065741 2590 D-EARTH SPRING-1
MP4 8930058170 SHIELD SPONGE (O)
MP101 8510002280 VCO SHIELD PLATE (A) (FX-15)
MP102 8930058700 SHIELD SPONGE (R)
MP103 8930079230 3073 SHIELD SPRING
MP104 8930071550 SHIELD SPONGE (BM)
MP202 8930079230 3073 SHIELD SPRING
MP203 8930071550 SHIELD SPONGE (BM)
MP601 8930065741 2590 D-EARTH SPRING-1
MP851 8510015720 2590 DC-DC A-CASE
MP852 8930063980 SHIELD SPONGE (AL)
MP871 8510015720 2590 DC-DC A-CASE
MP872 8930063980 SHIELD SPONGE (AL)
[DISPLAY UNIT] (DS)
REF ORDER
NO. NO.
J4* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J21* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J31* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J33* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J107 6510026080 XM7A-0441
J113* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J114* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J301* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J407* 6510026740 IMSA-9637S-60Y922
J601* 6510026730 IMSA-9637S-08Y902
J603* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN)
J604* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
S1001* 2260002740 LS8J2M
S1002* 2260002740 LS8J2M
S1003* 2260002740 LS8J2M
S1004* 2260002740 LS8J2M
S1005* 2260002740 LS8J2M
S1006* 2260002740 LS8J2M
S1007* 2260002740 LS8J2M
S1008* 2260002740 LS8J2M
S1009* 2260002740 LS8J2M
S1010* 2260002740 LS8J2M
S1011* 2260002740 LS8J2M
S1012* 2260002740 LS8J2M
S1013* 2260002740 LS8J2M
S1014* 2260002740 LS8J2M
S1015* 2260002740 LS8J2M
S1016* 2260002740 LS8J2M
S1017* 2260002740 LS8J2M
S1018* 2260002740 LS8J2M
S1019* 2260002740 LS8J2M
S1020* 2260002740 LS8J2M
S1021* 2260002740 LS8J2M
S1022* 2260002740 LS8J2M
S1023* 2260002740 LS8J2M
S1024* 2260002740 LS8J2M
S1025* 2260002740 LS8J2M
S1026* 2260002740 LS8J2M
S1027* 2260002740 LS8J2M
S1028* 2260002740 LS8J2M
S1029* 2260002740 LS8J2M
S1030* 2260002740 LS8J2M
S1031* 2260002740 LS8J2M
S1101* 2260002740 LS8J2M
S1102* 2260002740 LS8J2M
S1103* 2260002740 LS8J2M
S1104* 2260002740 LS8J2M
S1105* 2260002740 LS8J2M
S1106* 2260002740 LS8J2M
S1107* 2260002740 LS8J2M
S1108* 2260002740 LS8J2M
S1109* 2260002740 LS8J2M
S1110* 2260002740 LS8J2M
S1111* 2260002740 LS8J2M
S1112* 2260002740 LS8J2M
S1113* 2260002740 LS8J2M
S1201* 2260002740 LS8J2M
6 - 1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
