Preparations
Applies to cars with a centrally mounted loudspeaker
Remove the four screws in the loudspeaker (1)
Lift up the loudspeaker. Disconnect the connector (2)
Place the loudspeaker to one side.
M3902614
Preparations
Pry off the panel in front of the gear selector lever. Use a weatherstrip tool as
illustrated. Remove the panel in front of the gear selector lever.
M8502988
Preparations
Press in the catches on the front edge of the gear selector lever panel. Lift the
panel upwards, first the front edge and then the rear edge. Remove the panel
around the gear selector lever.
M4302463
Preparations
Remove the two screws from the dashboard environment panel.
M8503027
