Introduction
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your
Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this
vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and
maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts
at all times in this (or any other) automobile. And, of course, please do not operate a vehicle if you may be affected by
alcohol, medication or any impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels
attached to the driver's door opening and on the left wheel housing in the engine compartment.
For further information please contact your retailer, or:
In the USA:
Volvo Cars of North America
Customer Relations
P.O. Box 914
Rockleigh, New Jersey 07647-0914
800-458-1552
In Canada:
Volvo Canada Ltd.
175 Gordon Baker Road
Willowdale, Ontario M2H 2N7
800-663-8255
General Information
Shiftlock (automatic transmission)
When your car is parked, the gear selector is locked in the (P) ark position. To release the selector from this position,
turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front side of the
gear selector and move the selector from (P) ark.
2 0 0 2
VOLVO
S60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2002 S60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo 2002 S60

Summary of Contents for Volvo 2002 S60

  • Page 1 Introduction Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 2 Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
  • Page 3 In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment. To reduce your vehicle's environmental impact, you can: Maintain proper air pressure in your tires.

  • Page 4: Table Of Contents

    6. Horn 7. Instrument panel 8. Audio controls 9. Windshield wipers 10. Parking brake (hand brake) 11. Center console switches 12. Climate control 13. Audio system 14. 12 V socket 15. Hazard warning flashers 16. Glove compartment 17. Panel vents 18.
  • Page 5 Contents Contents Safety Instruments and controls Climate control Audio Interior Locks and alarm Starting and driving Wheels and tires Car care Maintenance and service Specifications Index Back Cover Contents Top of Page...
  • Page 6 Seat belts Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 7 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 8 Driver's side airbag As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS) to complement the three-point seat belt system. The inflatable airbag is installed folded up in the center of the steering wheel.
  • Page 9 SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible. pg. 13 Airbags (Supplemental Restraint System) NOTE: Deployment of SRS components occurs only one time during an accident.
  • Page 10 There should be no loose articles, e. g. coffee cups, on the floor, seat or dash area. Never try to open the SRS cover on the steering wheel or the passenger side dash. This should only be done by an authorized Volvo service technician.
  • Page 11 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car. The SRS system is a supplement to the seat belts.
  • Page 12 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars. The system is designed to supplement the protection provided by the three-point seat belt system.
  • Page 13 Never try to repair any part of the SRS or SIPS bag systems yourself. Any interference in the system could cause malfunction and serious injury. All work on these systems should be performed by an authorized Volvo retailer. pg. 18 Side airbags (SIPS airbags)
  • Page 14 SIPS airbag deployment (see illustration in the center column above). Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician.
  • Page 15 2 0 0 2 VOLVO Instruments and controls pg. 29 Instruments and controls Instrument panel Indicator and warning symbols Switches in the center console Steering wheel adjustment Lighting panel Turn signals Windshield wipers/washer Hazard warning flashers, rear window/sideview mirror defroster, heated front seats...
  • Page 16 5. Odometer 6. Speedometer 7. Warning symbol 8. High beam indicator 9. Tachometer Indicates engine speed in thousands of revolutions per minute (rpm). Do not drive for long with the needle in the red section. The engine has an built-in function preventing excessively high engine speeds. When this function operates, you may discern some pulsation, which in that case is quite normal.
  • Page 17 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected.

  • Page 18: Seat Belt Reminder

    172. If the light stays on after restart, have the car towed to the nearest authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.
  • Page 19 Stop the car in a safe place and switch off the engine. Restart the engine. If the indicator light goes off, no further action is necessary. If the indicator light remains on, drive to an authorized Volvo retailer to have the system inspected. pg. 36 Indicator and warning symbols Messages in the text window When a warning light in the instrument panel comes on, a message is also displayed in the text window.
  • Page 20 1. Folding head restraints (option) This button is used to fold down the outboard rear head restraints. The ignition key must be in position I or II or the engine must be running. NOTE: If the head restraints have been folded down, they must be returned to their original position manually. The head restraints should be in the upright position before the rear seat backrests are folded down.
  • Page 21 This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. pg. 39 Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver.
  • Page 22 Volvo recommends the use of daytime running lights. If, however, you would prefer to have these lights turned off (USA only), please consult your Volvo retailer. Please note that the use of daytime running lights is mandatory in Canada.
  • Page 23 (the LED in the AUTO switch should be off). Acceleration The air conditioning is momentarily disengaged during full-throttle acceleration. Climate control maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant...
  • Page 24 Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a. This substance will not deplete the ozone layer. The system contains 2.2 lbs (1000 g) R134a and uses PAG oil. Passenger compartment blower Approximately 50 minutes after the ignition is turned off, the blower may come on automatically, and run for seven minutes, to remove condensation in the A/C evaporator.
  • Page 25 D Vertical air flow Direct the outer air vents toward the side windows to defrost. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows. pg. 56 Electronic climate control, ECC (2.4T and T5) pg.
  • Page 26 Set the control to the temperature you prefer. Defroster This function defrosts/ de-ices the windshield and front side windows. The LED in the switch will light up to indicate that the defrost function is engaged. Blower speed increases automatically and the air in the passenger compartment is dehumidified.
  • Page 27 While the Defroster function is selected, the air conditioning is temporarily activated to dehumidify the air, even if you have manually switched the air conditioning off. This will only function if the blower is not switched off. Recirculation Press this switch to engage the recirculation function (air in the passenger compartment recirculates - no fresh air enters the compartment).
  • Page 28 2. No LED lights. Recirculation is not activated unless needed to cool the passenger compartment in a warm climate. 3. The MAN LED lights. Recirculation is now activated. Keep in mind the following: Make it a rule to have the air quality sensor activated at all times. Recirculation is limited in cold climates to avoid fogging.
  • Page 29 Temperature Turn the control to set the temperature for the driver's and passenger's sides of the car. For cooler air, the air conditioning function must be engaged. Rear window and sideview mirror defrosters This function defrosts/ de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged.
  • Page 30 Air distribution Use the air distribution control positions (marked with dots) between the different symbols to fine-tune air distribution for maximum comfort. Contents Top of Page...
  • Page 31 2 0 0 2 VOLVO Audio pg. 63 Audio Audio system HU-413 - overview Audio system HU-613 - overview Audio system HU-803 - overview Audio systems HU-413/ HU-613/ HU-803 Audio systems HU-803 - radio Program types (HU-803 only) AUM (Advanced User Mode)
  • Page 32 Radio Cassette CD changer 6. Cassette eject 7. Selector knob for: Stored radio frequencies CD changer (option) - selecting disc 8. Cassette opening 9. Tape direction selector CD random play 10. On/ off - press Volume - turn 11. Bass - press and turn Treble - press, pull and turn 12.
  • Page 33 10. Active Sound Control (ON or OFF) 11. Scan function 12. Dolby B Noise Reduction 13. Automatic presetting of radio stations 14. Bass - press and turn Treble - press, pull and turn 15. Tape direction selector 16. Cassette opening 17.
  • Page 34 18. Automatic presetting of radio stations 19. Display pg. 67 Audio systems HU-413/ HU-613/ HU-803 Switch on/off Press the knob to switch on or turn off the radio. Volume control Turn the knob clockwise to increase volume. Volume control is electronic and does not have an end stop. If you have a key pad in the steering wheel, increase or decrease the volume with the + or - buttons.
  • Page 35 pg. 68 Audio systems HU-413/ HU-613/ HU-803 Fader - Balance front/rear Adjust front/ rear speaker balance by pressing the button to extend the control and turning it to the left (more sound from the rear speakers) or to the right (more sound from the front speakers). A "detent" indicates "equalized" balance. Press the button back in when you have made the adjustment.
  • Page 36 Press the left or right-hand side of the button to seek lower or higher frequencies. The radio seeks the next audible station and sets it. Press the button again to continue seek. Steering wheel keypad If you have a keypad in the steering wheel, press the right or left arrow to select preset stations. Scan function Press the SCAN button (HU-613) or the SOURCE knob (HU-803) to start the station scan function.
  • Page 37 The RDS or Radio Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
  • Page 38 News News Information Inform Sports Sports Talk Talk Rock Rock Classic rock Cls_ Rock Adult hits Adlt_ Hit Soft rock Soft_ Rck Top 40 Top_ 40 Country Country Oldies Oldies Soft Soft Nostalgia Nostalgia Jazz Jazz Classical Classicl Rhythm and Blues R_&_ B Soft Rhythm and Blues Soft_ R&...
  • Page 39 Contents Top of Page...
  • Page 40 2 0 0 2 VOLVO Interior pg. 101 Interior Front seats Interior lighting Floor mats Storage compartments Rear seat and trunk Spare wheel and tools pg. 102 Front seats Manual height adjustment - front seat The front edges of the driver and passenger seat cushions can be adjusted to seven different settings and the rear edges to nine different settings.
  • Page 41 pg. 103 Front seats Folding the backrests in the front seat The front passenger seat backrest can be folded to a horizontal position to make room for a long load. Fold the backrest as follows: Move the seat as far back as possible. Adjust the backrest to the upright position.
  • Page 42 This feature will not function if you lock your car with the key. This feature will not function if you lock you car with the key. Seat adjustment If your Volvo is equipped with power seats, the following may be adjusted with the two switches at the side of the seat: A - Front edge of seat (raise/lower)
  • Page 43 Do not adjust the seat while driving. The seat should be adjusted so that the brake pedal can be depressed fully. In addition, position the seat as far rearward as comfort and control allow. The seat rails on the floor must not be obstructed in any way when the seat is in motion. pg.
  • Page 44 108 Floor mats Vanity mirror The light comes on when you open the cover. Floor mats (option) Volvo offers floor mats specially manufactured for your car. They must be properly placed and secured in the mat clips.
  • Page 45 WARNING! An extra mat on the driver's floor can cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded. No more than one protective floor covering may be used at one time. Contents Top of Page...
  • Page 46 2 0 0 2 VOLVO Locks and alarm pg. 117 Locks and alarm Keys and remote controls Locking and unlocking Child safety lock Alarm pg. 118 Keys and remote controls Keys Two keys are provided with your car; a master key and a service key. The master key, the remote control, and the central locking button may all be used to lock and unlock all of your car's locks.
  • Page 47 If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following condition: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 48 Using the remote control Press the LOCK button once to lock all doors and trunk. Press the UNLOCK button once to unlock the driver's door and fuel filler door. Press this button again (within 10 seconds) to unlock all doors and the trunk. To pop open the trunk (without unlocking the doors), press the OPEN trunk button twice within 3 seconds.
  • Page 49 Doing so would ACTIVATE: the break in alarm, which would sound if one of the doors were opened the optional interior motion and inclination alarm sensors. Doing so would DEACTIVATE: the sunroof and interior courtesy light controls. the central locking buttons on the front door armrests, although the interior door handles would still function to allow occupants to leave the car.
  • Page 50 The switch on the driver's door armrest can be used to lock or unlock all doors and the trunk, and to set the alarm. pg. 122 Locking and unlocking Opening/locking the trunk lid with the remote control Do as follows to unlock the trunk lid only: Press the "Open trunk"...
  • Page 51 Exposure of people to these high temperatures for even a short period of time can cause heat-related injury or death. Small children are particularly at risk. pg. 124 Child safety lock Manual child safety locks - rear doors The controls are located on the rear door jambs. Use a screwdriver to adjust these controls. A The door cannot be opened from the inside.

  • Page 52: Horn

    The ignition switch is tampered with. If there is movement in the passenger compartment (if the car is equipped with the optional movement sensor). The car is lifted or towed (if the car is equipped with the optional inclination sensor). The battery is disconnected (while the alarm is armed).
  • Page 53 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact your Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the trunk has been opened.
  • Page 54 Fuel requirements Octane rating Volvo engines are designed for optimum performance on unleaded premium gasoline with an AKI octane rating of 91 or above. AKI (ANTI KNOCK INDEX) is an average of the Research Octane Number, RON, and the Motor Octane Number, MON.

  • Page 55: Refueling

    To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated" fuels; however, the octane ratings listed on this page must still be met.
  • Page 56 Fuel filler door Press the button on the light switch panel (see illustration on page 40) when the car is at a standstill to unlock the fuel filler door. Please note that the fuel filler door will remain unlocked until the car is driven again at a speed of over approximately 5 mph (8km/h).

  • Page 57: Starting The Car

    Volvo original or approved fuel filler caps. pg. 131 Starting the car Starting the engine 1. Fasten the seat belt. WARNING! Before starting, check that the seat, steering wheel and mirrors are adjusted properly. Make sure the brake pedal can be depressed completely.

  • Page 58: General Information

    Ignition switch and steering wheel lock 0 Locked position: Remove the key to lock the steering wheel *. WARNING! Never turn the key to position O while driving or when the car is being towed. I Intermediate position - "radio position": Certain accessories, radio, etc. on, daytime running lights off. II Drive position: The key position when driving.

  • Page 59: Manual Transmission

    Do not exceed posted speed limits. Avoid carrying unnecessary items (extra load) in the car. Maintain correct tire pressure. Check tire pressure regularly (when tires are cold). Remove snow tires when threat of snow or ice has ended. Note that roof racks, ski racks, etc, increase air resistance and also fuel consumption. Avoid using automatic transmission kickdown feature unless necessary.
  • Page 60 Shift positions Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. * Clutch interlock The clutch must be fully depressed before you can start your car.
  • Page 61 pg. 136 Automatic transmission (option) Automatic transmission AW55- 50 (option) P Park Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK).

  • Page 62: Geartronic (Option)

    pg. 137 Automatic transmission (option) W - Winter/Wet driving mode - enhanced vehicle traction Mode W will only function if the gear selector is in the (D) rive position. Press the button at the base of the gear selector to engage/disengage this driving mode (see illustration). When the W driving mode is engaged, this is displayed in the instrument panel (see page 30).
  • Page 63 P Park Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should also be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
  • Page 64 Automatic transmission - shift gate positions You can move the gear selector freely between the (MAN) ual and (D) rive positions while driving. Depress the button on the front of the gear selector knob to move between the R, N, D, and P positions. pg.

  • Page 65: All Wheel Drive (Option)

    If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 66 (see page 172 for the location of the brake fluid reservoir). If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected. WARNING! If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed...
  • Page 67 Contents Top of Page...
  • Page 68 2 0 0 2 VOLVO Wheels and tires pg. 155 Wheels and tires General information Tire pressure Tread wear indicators Changing wheels Uniform Tire Quality Grading pg. 156 General information General information about wheels and tires Your vehicle is equipped with tires according to the tire information label on the inside of the fuel filler door.
  • Page 69 Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. Special snow chains must be mounted on 195/65 R15. For tires of other dimensions, consult your Volvo retailer. If accessory, aftermarket or "custom" tires and wheels are installed and are of a size different than the original tires and wheels, chains in some cases CANNOT be used.
  • Page 70 With warm tires, correct only when the pressure is too low. The tire temperature rises after driving just a few miles. Vehicle loading The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label located on the inside of the fuel filler door. This label lists both tire and vehicle design limits.
  • Page 71 Recommended tire pressure (see decal on Fuel filler door) should be maintained irrespective of which position on the car the Temporary Spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "Temporary Spare"...
  • Page 72 Changing wheels The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. There are two jack attachment points on each side of the car (see illustration on next page). To change a wheel: Engage the parking brake.
  • Page 73 Position the jack correctly on the bar in the attachment (see illustration above) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non-slippery surface. Before raising the car, check that the jack is still correctly positioned in the attachment.
  • Page 74 greased. pg. 162 Uniform Tire Quality Grading Uniform Tire Quality Grading ALL PASSENGER CAR TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where applicable, on the tire sidewall between the tread shoulder and maximum section width.
  • Page 75 2 0 0 2 VOLVO Car care pg. 163 Car care Washing and cleaning the car Paint touch up pg. 164 Washing and cleaning the car Washing and cleaning the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 76 Leather upholstery/suede-like upholstery (alcanteraª) can be cleaned with a soft cloth and mild soap solution. For more difficult spots, Volvo offers a leather care kit. Under no circumstances should gasoline, naphtha or similar cleaning agents be used on the plastic or the leather since these can cause damage.
  • Page 77 Paint repairs require special equipment and skill. Contact your Volvo retailer for any extensive damage. Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment.
  • Page 78 Contents Top of Page...
  • Page 79 168 Volvo service Maintenance service Volvo advises you to follow the service program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.
  • Page 80 NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (Malfunction Indicator) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. Timing belt For proper functioning of the vehicle and its emission control systems, the timing belt must be replaced every 105,000 miles (168,000 km).
  • Page 81 Never try to repair any part of the SRS or SIPS bag systems yourself. Any interference in the system could cause malfunction and serious injury. Any work should only be performed by an authorized Volvo workshop. pg. 171 Working on your car...
  • Page 82 NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze).
  • Page 83 Engine oil must meet the minimum ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF and SJ/ Energy Conserving. Your Volvo has been certified using ILSAC oil specification GF-2 5W-30. Volvo recommends use of oil with a quality rating equal to or higher that ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF and SJ/Energy conserving.
  • Page 84 Operation in hot climates When temperatures exceed 86° F (30° C) in your area, Volvo recommends, for the protection of your engine, that you use a heavier weight oil, such as SAE 10W/30. See the viscosity chart below. Oil viscosity (stable ambient temperatures) Operation in temperate climates Incorrect viscosity oil can shorten engine life.
  • Page 85 level is maintained between the upper and lower marks on the dipstick. Low oil level can cause internal damage to the engine and overfilling can result in high oil consumption. The distance between the dipstick marks represents approx. 1.6 US qt (1.5 liter). The oil should preferably be checked when cold, before the engine has been started. NOTE: The engine must be stopped when checking the oil.
  • Page 86 NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze).
  • Page 87 (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Always entrust brake fluid changing to an authorized Volvo retailer. Power steering fluid reservoir The fluid level should always be between the MIN and MAX marks. Fluid type: ATF...
  • Page 88 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.

  • Page 89: Dimensions, Weights

    *The Vehicle Identification Number (VIN) should always be quoted in all correspondence concerning your vehicle with the retailer and when ordering parts. pg. 195 Dimensions, weights Dimensions Length 180 in. (458 cm) Width 71 in. (180 cm) Height 56.2 in. (143 cm) Wheelbase 107 in.
  • Page 90 5 cyl. turbo (automatic transmission) AWD USA 4540 lbs Canada 2060 kg Capacity weight 5 cyl./5 cyl. turbo USA 890 lbs Canada 400 kg 5 cyl. turbo AWD USA 860 lbs Canada 390 kg Permissible axle weights, front * 5 cyl. USA 2330 lbs Canada 1060 kg 5 cyl.

  • Page 91: Capacities

    Meeting minimum ILSAC specification GF- 2, including ACEA A1, API SJ, SJ/ CF and SJ/ Energy Conserving. Volvo does not recommend the use of oil additives. Transmission Oil grade: Manual: Volvo synthetic transmission oil 97308 Automatic: Volvo transmission oil 1161540- 8 Different types of oil should never be mixed. Power steering...

  • Page 92: Cooling System

    Brake fluid Fluid type: Brake fluid DOT 4+ boiling point > 536°F (280° C), P/N 94374433 Cooling system Type Positive pressure, closed system. Coolant Volvo original coolant/ antifreeze Volume 5 cyl. non- turbo 8.5 US qts. (8.0 liters) 5 cyl. turbo 9.3 US qts (8.8 liters)

  • Page 93: Electrical System

    Trunk lighting SV 8.5 Glove compartment lighting BA 9 s Vanity mirror 1.2 W SV 5.5 pg. 201 Suspension Wheel dimension 15" 16" Rim diameter (mm) tire side diameter(mm) Toe- in front (degrees) 0.1°± 0. 1° 0.1°± 0. 1° Toe- in rear (degrees) 0.2°+±...

  • Page 94: Engine Specifications

    205 Volvo On Call Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial:...
  • Page 95 1-800263-0475 Technician certification In addition to Volvo factory training, Volvo supports certification by the National Institute for Automotive Excellence (A.S.E.). Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These professional technicians are best able to analyze vehicle problems and perform the necessary service procedures to keep you Volvo at peak operating condition.

  • Page 96: Audio System

    2 0 0 2 VOLVO Index pg. 207 Index A/C (air conditioning) Accessory bracket Adjustable steering wheel Advanced User Mode (AUM) - radio Air bags - dual threshold/stage Air cleaner Air distribution Air quality sensor Air vents Airbag - Side Impact (SIPS)
  • Page 97 Back up light Backrest Bass Battery Battery - replacing Belt check Blower (fan) Booster cushion Booster cushion (integrated) Brake circuit Brake fluid Brake light Brake system Bulbs Capacities Carbon Monoxide - Important Warning Cargo compartment Cassette player Catalytic converter CD player Ceiling lighting Center console - storage compartments Central locking system - remote control...
  • Page 98 Cup holder 110 , 111 Current fuel consumption Defroster Dimension designation (tires) Direction indicator, rear - bulb Direction indicators Dolby Surround Pro Logic Door mirror defroster Door mirrors Driving economically DSTC Dual- threshold airbags Economical driving Electric socket Electrical system Electrically operated windows Engine - starting Engine compartment...

  • Page 99: Hazard Warning Flashers

    Fuses Gasoline Gear position Geartronic Geartronic - kickdown Geartronic - manual shifting General information Generator Generator warning light Glove compartment Grocery bag holder Handling Hazard warning flashers Head restraint - center, rear Headlight flasher Headlight washer Headlight wiper blades Headlights Heated front seats High beam "flash"...
