Preparations
Tip the left front seat backwards
Push the floor carpet to one side to access the air ducts (1).
D8502411
Preparations
Remove the rear seat cushion (1). First pull the front edge of the seat cushion
up. Pull the cushion forwards. Then lift the seat cushion out.
D8503390
Preparations
Remove the sill trim panel at the left rear door.
M8502823
Preparations
Fold both the rear backrests forward
Remove the seat belts from the guides (1).
M8503545
