Chapter 2
The FOCUS GC User Interface

Handshake Configuration Menu

The FOCUS GC can be coupled to other instruments, such as an autosampler or a
mass spectrometer. To allow other devices to run properly, you must indicate how
the signal will change. For example, the menu line specifies that another device
will start the GC when the remote start signal changes from high to low.
Parameter
CONFIG.
HANDSHAKE
Remote Start IN
Inhibit Ready
End of Run OUT
Start of RUN
OUT
GC Ready OUT
Prep-Run OUT
60
Table 2-11. Configure Handshake Menu
Range
Pulse High to Low (default)
Pulse Low to High
When Low (default)
When High
Pulse High to Low (default)
Pulse Low to High
Pulse High to Low (default)
Pulse Low to High
When Low (default)
When High
Pulse High to Low (default)
Pulse Low to High
CONFIG HANDSHAKE
Remote start in
Inhibit ready
End of run out
Start of run out
GC ready out
Prep run out
This line is the title bar.
This parameter allows another device to start
the FOCUS GC.
This parameters delays readiness until the GC
receives a signal from another device.
This parameter signals another device that the
run has ended.
This parameter signals another device that the
run has started.
This parameter signals another device that the
GC is ready.
This parameter signals another device that the
GC is preparing for a run.
Configuration Menu
H L
High
H L
H L
High
High
Description
