A P P E N D I X
Connector Pinouts
This appendix gives the connector pinouts for the following Netra ct server cards:
"CPU Card" on page A-2
"CPU Front Transition Card, Netra ct 800 Server" on page A-5
"CPU Front Transition Card, Netra ct 400 Server" on page A-12
"CPU Rear Transition Card" on page A-17
"Alarm Card, Netra ct 800 Server" on page A-25
"Alarm Card, Netra ct 400 Server" on page A-30
"Alarm Rear Transition Card, Netra ct 800 Server" on page A-35
A-1
