Knockdown C-Rail Assembly
4 Cut cable tie
Swing and straighten
Adjust chain tension: Move the shuttle to middle of track. Use a spring scale to
measure required force to pull the shuttle adjust 1/2" hex bolt to tension chain.
Recommended pull force: 8kg (80N)
Step 1 - Knockdown C-Rail Assembly
Unpack and assemble the C-Rail as shown above in Fig 04.
Start
Slide sleeve
3
5 Swing
7
Slide sleeve
6
Turn tracks around 9
10
Screws
Screws
Owner Installation Instructions
1
Swing
2
Swing and straighten
Tension 1/2" hex bolt
8
GDO-9v2 SecuraLift ®
fi g
04
11
