Before You Begin

Introduction
Congratulations on receiving a Motorola RNG200N HD Dual Tuner DVR. This document will help you set up your RNG200N to quickly get it up
and running.
READ THIS FIRST
1. Determine if you are connecting to a:
High-Defi nition TV (HDTV)
or monitor
Standard-Defi nition TV
2. Determine if you are connecting the audio to a home theater receiver or directly to the TV:
• For an HDMI or IEEE-1394 video connection, no additional audio connections to the TV are required.
• For a DVI video connection, additional audio connections to the TV are required.
• If the receiver or TV has a digital audio (S/PDIF) input, use the Optical Audio (S/PDIF) output. Otherwise, use the left and right (RCA
phono) audio outputs.
3. Locate the cabling diagram(s) that best match the confi guration.
4. Connect the audio and video cables in a manner matching that diagram.
5. Connect the Cable In terminal to the coaxial cable wall outlet.
6. Connect the power supply to the set-top and the electrical wall outlet.
7 . Perform the operational check for the remote control.
8. Optimize the high-defi nition settings.
Additional information for adjusting user settings
The RNG200N User Settings menu allows you to adjust the video, audio, and closed captioning confi guration of the set-top.
The User Settings menu can be accessed from the set-top remote by pressing Power and then Menu within 2 seconds.
For more detailed instructions on changing the set-top confi guration through the User Settings menu, please refer to the RNG200N User Guide
available online at
http://motorola.com/homevideo/support.
RNG200N Quick Start Guide
Use the HDMI, component video (YPbPr), or IEEE-1394 outputs. No other video connection supports HDTV.
If the TV has no HDMI input but does have a DVI input, connect a DVI-to-HDMI adapter or cable to the HDMI
out connector on the set-top and the DVI input connector on the TV.
Use the RF Out connector on the set-top, if the TV does not support S-Video or composite video connections.
The RF connection carries video and audio.
1
