QIP27xx Series
Set-Top T erminals
Standard- Definition
Watch and Record DVR

Advertisement

   Summary of Contents for MOTOROLA QIP2708

  • Page 1: User Guide

    User Guide QIP27xx Series Set-Top T erminals Standard- Definition Watch and Record DVR...

  • Page 2

    This reminder is provided to call the system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close as possible to the point of cable entry as practical.

  • Page 3

    Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

  • Page 4: Declaration Of Conformity

    Drive, San Diego, CA 92121, 1-800-225-9446, declares under sole responsibility that the product identifies with 47 CFR Part 2 and 15 of the FCC Rules as a Class B digital device. Each product marketed is identical to the representative unit tested and found to be compliant with the standards.

  • Page 5

    TRANSFER the Software (including all component parts and printed materials) permanently to another person, but only if the person agrees to accept all of the terms of this License. If you transfer the Software, you must at the same time transfer the Product and all copies of the Software (if applicable) to the same person or destroy any copies not transferred.

  • Page 6

    ___________________________________________________________________________________ Copyright © 2006 by Motorola, Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc.

  • Page 7: Table Of Contents

    QIP27xx User Guide CONTENTS Introduction ..................... 3 QIP27xx — Front and Back Panels ..........4 Front Panel ................. 4 Front Panel Description ..............4 Back Panel .................. 5 Back Panel Description..............5 Operation ....................6 Turning Power On and Off............... 6 Changing Channels ................

  • Page 8: Table Of Contents

    Connecting your Set-Top to a Stereo TV and Stereo VCR ....16 Connecting a Stereo TV and Stereo VCR........17 Connecting your Set-Top to an A/V Receiver, TV, and VCR..... 18 Connecting an A/V Receiver, TV, and VCR........19 Data Devices ..................20 Data Features ..................

  • Page 9: Introduction

    In addition, the QIP27xx offers full DVR functionality to record and play back the shows you want to watch. With its second tuner, the QIP27xx also allows “watch and record” capabilities so you can really take control of your viewing options.

  • Page 10: Qip27xx — Front And Back Panels, Front Panel, Front Panel Description

    (left, right, up, down) ON — Indicates power is on when lit DISPLAY — Displays channel number and time of day REMOTE indicator — Is lit when remote control is in use CHANNEL — Scrolls up or down through the channels...

  • Page 11: Back Panel, Back Panel Description

    Back Panel Description Item Description RF IN — Connects to digital TV input from your service provider IR — Enables QIP27xx to control a VCR while recording a selected program (not supported by all program guides) SMART CARD — Supports Smart Card interface (currently not enabled) SPDIF (coaxial) —...

  • Page 12: Operation, Turning Power On And Off, Changing Channels, Adjusting The Volume, Electronic Program Guide

    OPERATION Turning Power On and Off Press on the front panel to turn the set-top on or off. When using POWER the remote control, be sure you press before pressing CABLE POWER Changing Channels You can change channels in two ways: •...

  • Page 13: Digital Video Recorder (dvr), Record Programming, Maintain A Personal Program Library, Control Live Tv

    QIP27xx User Guide DIGITAL VIDEO RECORDER (DVR) The QIP27xx is equipped with an internal hard drive for digital video recording of standard definition TV (SDTV) programs. Storage time depends on the video format of the received program. What is DVR? DVR, which stands for digital video recorder, records and plays digital video using hard-disk drive technology.

  • Page 14: Simultaneously Record Two Shows, Simultaneously Record Shows And Watch A Recorded Program

    Record two programs from two different channels at the same time Simultaneously Record Shows and Watch a Recorded Program Watch a program recorded on your QIP27xx while recording up to two other programs at the same time. You can also easily switch between viewing the pre-recorded program and either of the programs that you are recording.

  • Page 15: On-screen Graphics, Connecting Your Set-top

    (such as the User Setting menu), closed captions, and electronic program guides. The QIP27xx overlays these graphics whenever you open a menu, enable closed captions, or scroll through a program grid. CONNECTING YOUR SET-TOP This section describes how to connect the QIP27xx set-top to your home entertainment system.

  • Page 16: Important Safety Considerations

    QIP6400 Follow these important safety guidelines when positioning and connecting the set-top: • Position the set-top with at least two inches of space above and on all sides. • Do not block the slots and openings on the set-top. •...

  • Page 17: Video Connection Options

    VIDEO connection. • RF Output (optional) — SDTV If your TV has an RF input only, connect it to the RF output on the set-top. The TV must be tuned to channel 3 or 4. If You Have: Follow: Stereo TV only...

  • Page 18: Recording Your Connections

    You can use this diagram to reconnect your system if you move the equipment or add new equipment. Disconnect the power from the set-top before connecting or changing any connections. Do not place another component or object on top of the set-top.

  • Page 19: Connecting An A/v Receiver — Audio Only

    SPDIF stereo audio outputs ( and L). In most cases, these outputs offer AUDIO R a higher level of audio quality, including support for Dolby Digital 5.1 surround sound. • Optical SPDIF: Connect the optical SPDIF cable to the OPTICAL...

  • Page 20: Connecting Your Set-top To A Stereo Tv

    CONNECTING YOUR SET-TOP TO A STEREO TV RF (75 ohm) S-Video Video Audio connector connector connector connector QIP27xx Series RISK OF ELECTRIC SHOCK DO NOT OPEN SWITCHED 105 -125V 60Hz 4A MAX 500W MAX Cable in Either / or Stereo TV...

  • Page 21: Connecting A Stereo Tv

    QIP27xx User Guide Connecting a Stereo TV Connect an RF coaxial cable to the service provider’s wall outlet and to the connector on the set-top. RF IN Connect the stereo audio cable to the connectors on AUDIO R the set-top and to the...

  • Page 22: Connecting Your Set-top To A Stereo Tv And Stereo Vcr

    CONNECTING YOUR SET-TOP TO A STEREO TV AND STEREO VCR RF (75 ohm) Video Audio connector connector connector SWITCHED 105 -125V 60Hz 4A MAX 500W MAX...

  • Page 23: Connecting A Stereo Tv And Stereo Vcr

    QIP27xx User Guide Connecting a Stereo TV and Stereo VCR Connect an RF coaxial cable to the service provider’s wall outlet and to the connector on the set-top. CABLE IN Connect a stereo audio cable to the connectors AUDIO OUT R...

  • Page 24: Connecting Your Set-top To An A/v Receiver, Tv, And Vcr

    CONNECTING YOUR SET-TOP TO AN A/V RECEIVER, TV, AND VCR RF (75 ohm) Video Audio Digital audio Optical connector connector connector connector connector QIP27xx Series CAUTION S-VIDEO RISK OF ELECTRIC SHOCK VIDEO OUT DO NOT OPEN ETHERNET RF IN SPDIF...

  • Page 25: Connecting An A/v Receiver, Tv, And Vcr

    The optical (square connector) or coaxial (round SPDIF SPDIF connector) audio outputs may be used in place of the stereo audio outputs ( and L). In most cases, these outputs offer a higher AUDIO R level of audio quality, including support for Dolby Digital 5:1 surround sound.

  • Page 26: Data Devices, Data Features

    Advanced data features require the proper application and network infrastructure to operate. Data Features In addition to high quality audio and video, the set-top has the capability to support the following data interfaces: USB 2.0, Ethernet. Your set-top may be equipped with the interface connections illustrated, but their functionality depends on the services offered by your service provider.

  • Page 27: Troubleshooting

    QIP27xx User Guide TROUBLESHOOTING Before calling your service provider, review this troubleshooting guide. This information is to help you quickly solve a problem. If your problem persists, contact your service provider. Problem Possible Solution The set-top will not The set-top may have received a software update and...

  • Page 28

    MUTE channels control to restore sound. If the set-top audio output is connected to the TV, verify that the button on the TV has not been pressed. MUTE If the set-top audio output is connected to a digital/home...

  • Page 29

    QIP27xx User Guide Problem Possible Solution There is no video Verify that the TV is powered on and set to the on the TV screen appropriate input source for the set-top. Verify that the set-top is powered on and tuned to an authorized digital TV channel.

  • Page 30

    Visit our website at: www.motorola.com 531634-001-b 6/06...
