Push the ejection arms closed fully and secure both captive screws to seat and secure the power
7
supply in the chassis.
Ensure the power supply on/off switch is in the "O" off position.
8
Plug the power cord into the new power supply and attach the power cord tie strap to the power
9
cord.
Place the power supply on/off switch to the "I" on position. The Power status LED should be a
10
steady green and the Power status LED and Fan LED should be off.
Go to the Maintenance > Hardware screen of the BUI. Click
11
PSU to verify that the
▼
Replacing a SIM Board
The SIM boards are hot-swappable so you can replace them without removing power to the
system. The SIM boards are multi-pathed, so you can remove one of the SIM boards at any
time, regardless of the state of the blue SIM OK indicator. A faulted SIM board is indicated by
an amber LED.
Locate the failed SIM at the back of the disk tray.
1
Label and disconnect the tray interface cables.
2
Use two hands to disconnect the SAS cable. Grasp the metal body of the connector with one
3
hand and firmly grasp and pull the tab gently toward the connector body with the other, then
pull the connector body outward to extract it from the bulkhead. Do not twist or pull the tab in
any direction other than parallel with the connector body or it may break. If the tab breaks, use a
small sharp object (such as a fine-tipped screwdriver) to lift the metal spring at the top of the
connector shell to unlatch it.
Loosen the two extraction arm captive screws using your thumb and forefinger. If the captive
4
screws are too tight to loosen by hand, use a No.2 Phillips screwdriver to loosen each screw.
Chapter 2 • Hardware Maintenance
icon is green for the newly installed power supply.
for the controller and then click
