Installation Manual for the
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and
safety instructions. Failure to follow installation and safety instructions can result
in hazards developing due to improper assembly. You agree to properly install
this product and that if you fail to do so Gates That Open, LLC shall in no event
be liable for direct, indirect, incidental, special or consequential damages or loss
of profits whether based in contract tort or any other legal theory during the
course of the warranty or at any time thereafter. The installer and/or user agree to
assume responsibility for all liability and use of this product releasing GTO from
any and all liability. If you are not in agreement with this disclaimer or do not
feel capable of properly following all installation and safety instructions you may
return this product for full replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before
attempting to install and use this automatic gate opener. This gate opener
produces a high level of force. Stay clear of the unit while it is operating and
exercise caution at all times.
All automatic gate openers are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which regulates gate opener safety,
as established and made effective March 1, 2000, by Underwriters Laboratories Inc.
Telephone GTO Sales: 1-800-543-GATE (4283) or (850) 575-0176 • Fax (850) 575-8912
or GTO Technical Service: 1-800-543-1236 or (850) 575-4144 • Fax (850)575-8950
HEAVY DUTY
WARNING!
3121 Hartsfield Road • Tallahassee, Florida, USA 32303
www.gtoaccess.com
ANNIVERSARY
SERIES
US
2007 Gates That Open, LLC
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silver-HD Dual 25th annivesary series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mighty Mule Silver-HD Dual 25th annivesary series

  • Page 1 The installer and/or user agree to assume responsibility for all liability and use of this product releasing GTO from any and all liability. If you are not in agreement with this disclaimer or do not feel capable of properly following all installation and safety instructions you may return this product for full replacement value.
  • Page 2 Product Usage The GTO Gate Operator meets all of the safety requirements of a Class I Residential Vehicular Gate Operator and is intended for use solely with vehicular swing gates in single-family residential applications.
  • Page 3: Table Of Contents

    Table of Contents Gate Opener Class Categories -------------------------------------------------------------inside cover Units and Standards Conversion Chart ---------------------------------------------------inside cover PLEASE READ THIS FIRST! -------------------------------------------------- page iii Important Safety Instructions -------------------------------------------------- page 1 Disconnecting the Opener -------------------------------------------------------------page 1 Important Safety Instructions for the Consumer ------------------------------------page 2 Secondary Means of Protection Against Entrapment ------------------------------page 5 Required Safety Precautions for Gates -----------------------------------------------page 6 Warning Signs and Labels -------------------------------------------------------------page 7...
  • Page 4: Please Read This First

    “OFF” is the factory setting; meaning the gate will stay open until you press the transmitter button (or keypad, etc.) again. Please call GTO at (800) 543-GATE [4283] or (850) 575-0176 for more information about our GTO/ACCESS SYSTEMS professional line of gate operators and accessories.
  • Page 5: Important Safety Instructions

    Because GTO automatic gate openers are only part of the total gate operating system, it is the responsibility of the consumer to ensure that the total system is safe for its intended use.
  • Page 6: Important Safety Instructions For The Consumer

    IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury or death, for which the manufacturer cannot be held responsible. When designing a system that will be entered from a highway or main thoroughfare, make sure the system is placed far enough from the road to prevent traffic congestion.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS Entrapment Zones for a proper Pull-To-Open installation: Zone 1 – leading edge of the gate and the fence post. Zone 2 – between the gate and the gate post. Zone 3 – the path of the gate. Zone 4 –...
  • Page 8 If any of these signs or warning decals become damaged, illegible or missing, replace them immediately. Contact GTO for free replacements. The gate is automatic and could move at any time, posing a serious risk of entrapment. No one should be in contact with the gate when it is moving or stationary.
  • Page 9: Secondary Means Of Protection Against Entrapment

    ENTRAPMENT ALARM (UL 325; 30A.1.1A) The GTO® Gate Opener is designed to stop and reverse within 2 seconds when the gate comes in contact with an obstruction. Additionally, these openers are equipped with an audio entrapment alarm which will activate if the unit obstructs twice while opening or closing.
  • Page 10: Required Safety Precautions For Gates

    Entrapment Protection GTO’s inherent obstruction settings, even when properly adjusted, may not be sensitive enough to prevent bodily injury in some circumstances. For this reason, safety devices such as safety edge sensors (or photoelectric sensors), which stop and reverse gate direction upon sensing an obstruction, are suggested for enhanced protection against entrapment.
  • Page 11: Warning Signs And Labels

    IMPORTANT SAFETY INSTRUCTIONS These warning labels should be found at the locations specified below. If any of them are missing, immediately contact GTO for replacements. 9901178 Gates That Open, LLC • Tallahassee, Florida USA Product identification and manual operation instruction label (1) installed on the right side of the control box.
  • Page 12: Parts List

    Dual Gate Opener Parts List Opener and Mounting Hardware Customer Support Card (1) Gate Opener (1) w/ 32' Power Cable Gate Opener (1) w/ 6' Power Cable Closed Position Gate Bracket (2) Post Bracket (4) Post Pivot Bracket (2) Stop Plate (2) Hardware 3/8"...
  • Page 13: Installation

    (continued) Control Box and Electrical Components Batteries (2) WARNING Receiver (1) GTO Transmitter(2) Moving Gate Can Cause Injury Or Death KEEP CLEAR! Gate may move at any time. Do not allow children to operate gate or play in gate area.
  • Page 14: Technical Specifications

    • The system is powered by two 12 Vdc, 7.0 Ah, sealed, rechargeable acid batteries. • Battery charge is maintained by a18 Vac output transformer rectified to 14.5 Vdc (20 VA) through the GTO control board. One (1) blade-style control board fuse rated for 25 A.
  • Page 15: Installation Overview

    Installation Overview Pull-to-Open Gates (Gate Opens into the Property) The diagram shown below is an example of a pull-to-open installation on a chain link fence and dual gates. Mounting the openers on a masonry column requires special procedures; see Column Installation Information on page 38 if you intend to mount the openers on columns.
  • Page 16: Installation Of The Mounting Hardware

    Installation of Mounting Hardware The position of the post bracket determines the leverage and efficiency of the opener. The post bracket position also sets the clearance between the opener and gate in the open and closed positions (minimum 2 inches). The curved design of the post bracket works well for installations on round and square fence posts.
  • Page 17: Determining The Mounting Position

    Determining the Mounting Position of the Post Bracket Assembly and the Gate Bracket Step 3 NOTE: The following steps are 3/8" x 2" Bolt Insert the " x 2" bolt through intended for pull-to-open gate the center hole of the post installations.
  • Page 18 IMPORTANT: While determining the mounting point for the post pivot bracket assembly, be sure that the position allows for minimum 2 inches of clearance between the gate and the opener in both the open and closed positions, as shown in the diagrams below.
  • Page 19 Installing the Post Bracket Assembly and Gate Bracket Step 7 Mark reference points for bolt holes on the fence post through middle of bracket slots. Mark reference points for bolt holes on the gate cross member through middle of gate bracket slots. After marking your reference points, remove the opener and brackets from the fence and gate.
  • Page 20: Mounting The First Opener

    Mounting the Master Opener Step 11 Attach the opener to the securely bolted post bracket assembly and gate bracket using clevis pins, bushings, and hairpin clips, or the Pin Locks (included). Verify that the opener is level and adjust the post bracket assembly if necessary. Post Bracket Assembly bolted to fence post Level Opener...
  • Page 21: Installation Of The Closed Position Stops

    The optional ground stop post is used to provide a secure point for the SECOND gate to close against. If you will be using the GTO Horizontal Gate Lock accessory with your gate opener system, the closed position ground stop is REQUIRED, as shown in Steps 2 and 3 on the next page.
  • Page 22 Step 2 Install a low profile ground stop (not provided) beneath the Closed Position Stop Plate mounted on the gate leaf that CLOSES FIRST SECOND gate stop plate. The ground stop needs to be positioned near the end of the gate as shown in Illustration A and may be made of metal SIDE VIEW or concrete and should be firmly secured in the ground (we...
  • Page 23: Mounting The Control Box

    Use mounting holes and screws NOTE: The batteries that came with your GTO® provided to mount gate opener, MUST be placed in the top (horizontal) control box to a battery slot with the terminals on the RIGHT. The extra secure surface.
  • Page 24: Connecting The Opener Power Cables

    Connecting Opener Power Cables MASTER Operator Step 4 Insert the stripped power cable wires into the appropriate terminals on the MASTER CABLE terminal block. The green wire should be inserted into the GRN terminal, the white wire into WHT, the blue wire into BLU, brown wire into BRN, the orange wire into the ORG, the red wire into the RED, and the black wire into the BLK terminal.
  • Page 25: Powering The System

    (available at local electrical supply stores) must be used. • All low voltage wire used with the GTO Gate Opener must be 16 gauge dual conductor, ® stranded, direct burial wire (see page 22 and the accessory pages). Do not run more than 1000 feet of wire.
  • Page 26 IMPORTANT INFORMATION ABOUT LOW VOLTAGE WIRE The only wire acceptable for use with GTO products is 16 gauge stranded, low voltage, PVC sheathed wire. This particular gauge enables the transformer to provide an adequate charge through the control board to the battery at distances up to 1000 ft.
  • Page 27: Connecting The Transformer

    Step 6 Strip " of insulation from the ends of the low voltage wire. Attach these stripped ends to the transformer terminals. A dab of household petroleum jelly on each terminal will help prevent corrosion. Make sure the exposed wires do not touch each other! Transformer Step 7 Plug the transformer into the electrical outlet.
  • Page 28: Control Board Settings

    CONTROL BOARD SETTINGS DIP Switches DIP Switch Settings (MODES) DIP Switch #1 - Soft Start/Stop ON - Soft start enabled (factory preset). OFF - Soft start disabled. The Soft Start/Stop feature slowly starts the gate as it begins to open and slows the gate as it comes to the closed position.
  • Page 29: Setting Closed Position Limits

    Setting the Closed Position Limits for Pull to Open Applications TURN CONTROL BOX ON NOTE: The OPEN limit is when the opener is fully retracted and the gate is in the full open position. The open limit setting can only be adjusted by moving the gate bracket. To achieve the optimum closed position, you must adjust the CLOSED limit setting: Step 1 Confirm that the power switch is in the ON position, and the gates are in the OPEN POSITIONS.
  • Page 30: Setting Your Personal Transmitter Code

    'LEARN MAST LIMIT' or 'LEARN 2ND LIMIT' button for 5 seconds. This will clear the memory for the closed limit positions. Follow Steps 1-7 again. Setting Your Personal Transmitter Code All GTO transmitters are set to a standard code at the factory and are ready to operate your GTO® Gate Opener ® . For your safety and security, however, we strongly recommend that you replace the factory setting with your own personal code.
  • Page 31: Obstruction Sensitivity

    • Standard receiver cable length is 10 feet (receivers with a longer cable are available as special order items; call the GTO Sales Department). NEVER splice receiver cable! • Run the cable through PVC conduit to protect it from damage.
  • Page 32: Connecting Accessories

    Connnecting Accessories Input Connections • All control inputs are dry-contact, normally open, inputs. DO NOT apply external voltage sources to these inputs. • All inputs are connected with respect to COMMON terminal. • The status LED will blink once when any input is activated. COM: Circuit common (reference for all logic input) • Two (2) terminals to provide extra common connection point. CYCLE/CLOSE: (Typically for use with push button or hard-wired keypad) • Each activation at this input will cycle the operation as follows: CYCLE OPEN–STOP–CLOSE–STOP–OPEN SAFETY: (Typically for use with photo...
  • Page 33: Wiring Accessories

    LOCK CONTROL INPUTS CONTROL INPUTS 2ND OPERATOR INPUT MASTER OPERATOR 2ND OPERATOR MASTER OPERATOR RECEIVER GTO 18 VOLT TRANSF. OR GTO RCVR. SOLAR PANEL According to Application Automatic Gate Lock (FM144 & FM142) Edge Sensor Push Button Control (RB101) Photo Beams (R4222)
  • Page 34: Push To Open Installation

    Push to Open Installation Determining The Mounting Position of The Post Bracket Assembly Swinging gates shall not open into public access areas! 3/8" x 2" Bolt A "Push-to-Open" gate opens out from the property. A Push-to-Open Bracket is required for this type of installation (see Post Bracket Accessory Catalog).
  • Page 35: Setting Open Position Limits

    Step 3 With the gate in the fully closed position and the opener retracted, swing the opener to the gate. Mark reference points for bolt holes on gate cross member through middle of gate bracket slots. The opener must be level. (Some vertical adjustment is possible by sliding the post bracket assembly up and down.) Drill "...
  • Page 36 Step 3 Note which gate has reached the desired closed position (typically it's the SECOND gate), program the closed limit setting by pressing and holding the corresponding 'LEARN MAST LIMIT' or 'LEARN 2ND LIMIT' button for 5 seconds. Step 4 Press the transmitter button and allow the gates to return to the closed position.
  • Page 37: Troubleshooting Guide

    Troubleshooting Guide If your gate opener does not function properly after it is installed, use this guide before calling the GTO Service Department. VOLTAGE READINGS 18 Vac Transformer ..................18.0 to 22.0 Vac, 2200 mA 5 W Solar panel (single) ................18.0 to 22.0 Vdc, 300 mA * measure voltage at panel and control box. Two 12 V, 7 amp hour Batteries .............12.5 to 13.5 Vdc 7.0 Ah *measure voltage at battery terminals with battery disconnected from circuit board Charging circuit ..................13.3 to 14.8 Vdc...
  • Page 38 Visual Feedback Indication Possible Diagnosis Check Status (clear) 1 blink Cycle Terminal Disconnect the push button, keypad, intercom keypad, or any other accessory Shorted wired to this terminal. Try the remote. If the remote works, then the problem is the accessory. Status (clear) 2 blinks Safety Terminal Disconnect the loop detector, photo beam, or any other accessory wired to this Shorted...
  • Page 39: Repair Service

    Ship the package(s) freight prepaid to: GTO, 3121 Hartsfield Road, Tallahassee, Florida, USA 32303. NOTE: Products returned to GTO without a Return Goods Authorization (RGA) number in LARGE BOLD PRINT on the outside of the package WILL NOT be accepted. Also, items returned to GTO freight collect WILL NOT be accepted. GTO Technical Service and Installation Assistance 8:00am–7:00pm •...
  • Page 40: Column Installation Information

    Column Installation Information F THIS OPENER WILL BE USED WITH GATES THAT ARE MOUNTED ON MASONRY, BRICK, OR ROCK (etc.) COLUMNS: READ THE FOLLOWING CAREFULLY BEFORE PROCEEDING The simplest solution is to install the opener in a push-to-open configuration (requires Push-To-Open Bracket, see Accessory Catalog).
  • Page 41: Accessory Catalog

    Accessories Please visit www.gtoaccess.com for photos and detailed descriptions of GTO Accessories. Or call 1-800-543-GATE (4283). POWERING ACCESSORIES Low Voltage Wire [RB509] The 16 gauge, stranded, dual conductor low voltage Wire is for connecting the AC powered transformer, solar panel or wired accessories to the system’s control board. This specially designed wire is UV treated, PVC coated, and ready for direct burial. Solar Panel Kits [FM122/FM123] If your gate operator is more than 1000 ft. away from an AC power outlet, you can choose to maintain the battery charge with the GTO Solar Panel Kit.
  • Page 42 100 ft. range between transmitter and receiver. Easy installation. LOCKING & SECURITY Accessories Automatic Gate Lock [FM144/FM142] The #1 Accessory For Swing Gate Operators! Designed for added security in conjunction with GTO Automatic Gate Operators. The gate lock unlocks and locks automatically when the gate opens and closes. The perfect solution for high wind conditions. Bulldog Pedestrian Gate Lock [FM145] Designed to mount on horizontal swing “walk through” wood, chain link, and metal pedestrian gates opening in or out. Ideal for securing pools, condominiums, schools and any pedestrian gate.
  • Page 43 1-800-543-GATE! The contents of all material available on this installation manual are copyrighted by Gates That Open, LLC (“GTO”), unless otherwise indicated. All rights are reserved by GTO, and content may not be repro- duced, downloaded, disseminated, published, or transferred in any form or by any means, except with the prior, written permission of GTO. Any reprinting of GTO publications is by permission only. Copyright infringement is a violation of federal law.
  • Page 44 ACCESS SYSTEMS PROFESSIONAL RESIDENTIAL 3121 Hartsfield Road • Tallahassee, Florida, USA 32303 (850) 575-0176 • Fax (850) 575-8912 Web site www.gtoaccess.com 24/7 Troubleshooting Wizard: http://support.gtoinc.com...
