Installation Manual
FM502
WARNING!
This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and safety
instructions. Failure to follow installation and safety instructions can result in hazards
developing due to improper assembly. You agree to properly install this product and
that if you fail to do so GTO Access Systems, LLC, shall in no event be liable for direct,
indirect, incidental, special or consequential damages or loss of profits whether based
in contract tort or any other legal theory during the course of the warranty or at any
time thereafter. The installer and/or user agree to assume responsibility for all liability
and use of this product releasing GTO Access Systems, LLC, from any and all liability.
If you are not in agreement with this disclaimer or do not feel capable of properly
following all installation and safety instructions you may return this product for full
replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before attempting to
install and use this automatic gate opener. This gate opener produces a high level of
force. Stay clear of the unit while it is operating and exercise caution at all times.
All automatic gate openers are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which
regulates gate operator safety, by Underwriters Laboratories Inc.
For more information on Mighty Mule's full line of Automatic Gate Openers and Access Controls visit our website at www.mightymule.com
GTO Sales: 800-543-4283 • Fax 850-575-8912
GTO Technical Service 800-453-1236
For 24 hour/day, 7 day/week Technical Service visit http://support.gtoinc.com
For more information on Mighty Mule's full line of Automatic Gate Openers and Access Controls visit www.mightymule.com
Printed in China for GTO Access Systems, LLC.
Copyright
©
2015 GTO Access Systems, LLC rev 12.14.15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM502 and is the answer not in the manual?

Questions and answers

Jack Hale
April 26, 2025

I have M Mule a red panel 502 gate opener. I need to reset the gate limits. Instructions please?

User image 680c24fd42125
1 comments:
Mr. Anderson
May 13, 2025

To reset the gate limits on a Mighty Mule FM502 gate opener:

1. Press your transmitter to return the gates to their closed positions.
2. Press and hold the "LEARN MAST LIMIT" or "LEARN 2ND LIMIT" button for 5 seconds to clear the memory for the open limit positions.
3. Follow steps one (1) to seven (7) again to reprogram the limits.

This answer is automatically generated
