Page 1: Quick Installation Guide
EMX-A55E AMD G-Series™ APU with A55E Controller Hub(FCH) Mini-ITX Motherboard Quick Installation Guide Ed –29 June , 2011 Part No. E2017XA5500R... -
Page 2: Technical Support
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright 2011 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. - Page 3 2F keduka-Bldg, 2-27-3 Taito, Room 805, Building 9,No.99 Tianzhou Rd., Taito-Ku, Tokyo 110-0016 Japan Caohejing Development Area, Tel: +81-3-5807-2321 Xuhui District, Shanghai Fax: +81-3-5807-2322 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Information: sales.japan@avalue.com.tw Information: sales.china@avalue.com.cn Service: service@avalue.com.tw Service: service@avalue.com.tw EMX-A55E Quick Installation Guide 3...
-
Page 4: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following items have been shipped: 1 x EMX-A55E Mini ITX Main board 1 x CD-ROM contains OS drivers 1 x CPU Cooler ... - Page 5 Quick Installation Guide 2. Hardware Configuration EMX-A55E Quick Installation Guide 5...
-
Page 6: Product Overview
EMX-A55E 2.1 Product Overview 6 EMX-A55E Quick Installation Guide... -
Page 7: Specifications
DirectX 11, OpenGL 4.0, dedicated hardware (UVD 3.0) LVDS 1, 18bpp (Single link LVDS up to 1400 x 1050) T56N (18W) supports up to 2560 x 1600 T40N (9W) supports up to 1920 x 1200 EMX-A55E Quick Installation Guide 7... - Page 8 FAN Speed Control by Thermal Sensor Temperature Voltage 3.3V, +5V, 5Vsb, +12V, -12V Buzzer Onboard buzzer Watchdog Timer Programmable 1~255 sec/min Onboard TPM1.1/1.2 By Infineon SLB9635 (Optional) BIOS BIOS Core AMI EFI BIOS Flash BIOS Flash 16Mb SPI 8 EMX-A55E Quick Installation Guide...
- Page 9 Shared Memory up to 2GB Power Play 380, 200MHz, configure Power to 2.7~5.7W SATA Support SATA III(6Gbps) Internal Connector Debug Port HDT header Display LVDS 1, (optional) Inverter LVDS INV 3.3 V Audio Front Panel Amplifier SPDI/F Serial EMX-A55E Quick Installation Guide 9...
- Page 10 Power Type AT/ATX Power Requirement +3.3V, +5V, +12V, -12V, 5Vsb LED Indicator 4; alive, green; dead, red HDD Status 4; access, flash yellow Power on rear IO 1; Blue Expansion Slot Mini-PCI Express PCIex 4 10 EMX-A55E Quick Installation Guide...
- Page 11 SATA cable Kit 1 data and 1 power Serial Port I/O Shield Driver CD Startup Manual None FP_Power button, power LED, HDD LED kit None OS Support List Windows XP SP3, Windows 7 Pro, Linux Fedora 14 EMX-A55E Quick Installation Guide 11...
- Page 12 In addition, the board has a number of jumpers that allow you to configure your system to suit your application. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. 12 EMX-A55E Quick Installation Guide...
- Page 13 AT/ATX Mode Select AT MODE ATX MODE Connectors Label Function Note COM3, COM4 Serial Port COM3 COM4 Connector JFP1+JFP2 System Panel & Speaker PIN7-10 SPK3 PIN3-6 POWER BT PIN1-10 SPK4 PIN9-12 SYS_RESET JFP3 Power LED & Keylock EMX-A55E Quick Installation Guide 13...
- Page 14 EMX-A55E LVDS1 18-bit LVDS Connector 3.3V JBL3 LCD POWER (VDDSAFE ) 3.3V/5V SELECTION JBL1 Inverter PWR JBL1 LCD Inverter Connector AAFP Audio Mic.-In & Line-Out Connector SPDIF_OUT1 SPDIF OUT 14 EMX-A55E Quick Installation Guide...
