EMX-RLUC
13th Gen Intel® Core™ Soc BGA Processor, Thin Mini ITX
Motherboard.
User's Manual
Ed – 15 April 2025
st
1
Copyright Notice
Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No: E2047EMRU00R
