Fan - HP Compaq 6000 Pro Maintenance & Service Manual

Fan

Description
Fan
The fan is located near the top of the computer. It is secured with three screws.
Figure 7-47
To remove the fan:
1. Prepare the computer for disassembly (see
2. Remove the small rear cover (see
3. Remove the port cover (see
4. Remove the stand (see
5. Remove the drive cover (see
6. Remove the memory cover (see
7. Remove the upper rear panel (see
8. Remove the I/O panel (see
9. Remove the outer/left panel (see
10. Disconnect the fan cable from the system board connector.
Fan location
Port Cover on page
Stand on page
Optical Drive on page
Memory on page
Rear I/O Cover on page
Outer/Left Rear Panel on page
Preparing to Disassemble the Computer on page
Small Rear Cover on page
45).
46).
47).
53).
Upper Rear Panel on page
67).
Spare part number
644381-001
44).
55).
75).
43).
Fan
89
