Optical Drive Connector Board

Description
Optical drive connector board
Optical drive SATA cable
Optical drive eject/brightness cable
The optical drive connector board is located near the bottom left side of the fan sink. It is secured by
two screws and has one connector.
Figure 7-41
To remove the optical drive connector board:
1.
Prepare the computer for disassembly (see
2.
Remove the small rear cover (see
3.
Remove the port cover (see
4.
Remove the stand (see
5.
Remove the drive cover (see
6.
Remove the memory cover (see
7.
Remove the upper rear panel (see
8.
Remove the I/O panel (see
9.
Remove the outer/left panel (see
10.
Remove two screws (1) that secure the board to the computer.
Optical drive connector board location
Port Cover on page
Stand on page
Optical Drive on page
Memory on page
Rear I/O Cover on page
Outer/Left Rear Panel on page
Preparing to Disassemble the Computer on page
Small Rear Cover on page
45).
46).
47).
53).
Upper Rear Panel on page
67).
Spare part number
643153-001
643159-001
643146-001
44).
55).
75).
Optical Drive Connector Board
43).
83
