HP Compaq 6000 Pro Maintenance & Service Manual page 23

Table 3-4 Computer Setup—Security (continued)
USB Security Allows you to enable or disable groups of USB ports or individual USB ports:
●
●
●
Slot Security Allows you to disable or enable any PCI Express x16 or x1 slot
Network Service Enables/disables the computer's ability to boot from an operating system installed on a network
Boot server. (Feature available on NIC models only; the network controller must be either a PCI Express
expansion card or embedded on the system board.)
System IDs Allows you to set:
●
●
●
●
DriveLock Security Allows you to assign or modify a master or user password for hard drives. When this feature is
enabled, the user is prompted to provide one of the DriveLock passwords during POST. If neither is
successfully entered, the hard drive will remain inaccessible until one of the passwords is
successfully provided during a subsequent cold-boot sequence.
NOTE:
is attached to the system. You may need to power cycle the system to manage DriveLock-enabled
drives.
See the Desktop Management Guide for more information.
Front USB Ports
◦
USB Port 11
◦
USB Port 12
Rear USB Ports
◦
USB Port 1
◦
USB Port 3
◦
USB Port 8
◦
USB Port 9
◦
USB Port 10
Accessory USB Ports
◦
USB Port 2
◦
USB Port 4
◦
USB Port 6
◦
USB Port 7
Asset tag (18-byte identifier), a property identification number assigned by the company to the
computer.
Ownership tag (80-byte identifier) displayed during POST.
Chassis serial number or Universal Unique Identifier (UUID) number. The UUID can only be
updated if the current chassis serial number is invalid. (These ID numbers are normally set in
the factory and are used to uniquely identify the system.)
Keyboard locale setting (for example, English or German) for System ID entry.
This selection will only appear when at least one drive that supports the DriveLock feature
Computer Setup (F10) Utilities
15
