Graphics Board

Description
Graphics card, G210, 512 MB
Graphics card, HD5570, 1 GB
Graphics card, GFX, 1 GB
The graphics board is located under the bottom part of the heat sink. You must remove the heat sink to
remove the graphics board. The board is secured with two screws.
Figure 7-23
To remove the graphics board:
1. Prepare the computer for disassembly (see
2. Remove the small rear cover (see
3.
Remove the port cover (see
4. Remove the stand (see
5. Remove the drive cover (see
6. Remove the memory cover (see
7. Remove the upper rear panel (see
8. Remove the small fan (see
9. Remove the heat sink (see
10. Remove two small screws (1) that secure the board to the computer.
Graphics board location
Port Cover on page
Stand on page
Optical Drive on page
Memory on page
Small Fan on page
Heat Sink (Thermal Module) on page
Preparing to Disassemble the Computer on page
Small Rear Cover on page
45).
46).
47).
53).
Upper Rear Panel on page
61).
Spare part number
621426-001
628380-001
652164-001
44).
55).
62).
Graphics Board
43).
