Specifications

JWL-1642EVS JWL-1642EVS-2
Stock Number.....................................................708359 ................................................................708360
Over Bed............................................................16"............................................................................. 16"
Swing Over Tool Rest Base................................12"............................................................................. 12"
Distance Between Centers .................................42"............................................................................. 42"
Speeds (RPM)....................................................50-1200 and 120-3200 ................ 50-1200 and 120-3200
Spindle Nose......................................................1-1/4" x 8 T.P.I. ...................................... 1-1/4" x 8T.P.I.
Drive Spindle Through Hole................................3/8"........................................................................... 3/8"
Tailstock Spindle Through Hole ..........................3/8"........................................................................... 3/8"
Tailstock Spindle Travel......................................4" ................................................................................ 4"
Tool Rest............................................................14"............................................................................. 14"
Face Plate..........................................................6" ................................................................................ 6"
Headstock Taper ................................................MT-2 ...................................................................... MT-2
Tailstock Taper...................................................MT-2 ...................................................................... MT-2
Spindle Center to Floor (approx.)........................44-1/2"................................................................. 44-1/2"
Motor..................................................................1-1/2 HP, 3Ph, 230V..............................2HP, 3PH, 230V
...........................................................................Input Power 115V Only.......... Input Power 230V Only
Net Weight (approx.)...........................................440 Lbs ..............................................................440Lbs.
Shipping Weight (approx.) ..................................475 Lbs ..............................................................475Lbs.
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, WMH Tool Group reserves the right to change specifications at any time and
without prior notice, without incurring obligations.
