4.0 Specifications

Model number ................................................................................................................................. JWL-1840EVS
Stock number .............................................................................................................................................. 719600
Motor and electricals:
Motor type .................................................................................................... totally enclosed fan cooled, induction
Horsepower ....................................................................................................................................... 2HP (1.5 kW)
Phase .................................................................................................................................................................... 3
Voltage ........................................................................................................................................................... 230 V
Cycle ............................................................................................................................................................... 60Hz
Listed FLA (full load amps) ................................................................................................................................ 5 A
Power input requirements ....................................................................................................... single phase, 230V
Starting amps ..................................................................................................................................................... 3 A
Running amps (no load) ..................................................................................................................................... 2 A
Power transfer ................................................................................................................................................ V-belt
Drive ...................................................................................................... electronic variable speed, inverter control
On/off switch ............................................................................................................. paddle switch with safety key
Remote switch ....................................................................................................................................... with E-stop
Power cord .......................................................................................................................... SJT 3x14AWG (300V)
Power cord length ............................................................................................................................... 6 ft. (183cm)
Remote switch cord ............................................................................................................. SJT 3x14AWG (300V)
Power plug installed ............................................................................................................................. 6-15P 230V
Recommended circuit size
Noise emission without load
Capacities:
Working distance between centers:
with single bearing center ................................................................................................. 40-1/2 in. (1029 mm)
with live cone center ............................................................................................................ 38-1/4 in. (972 mm)
Working distance between centers, optional 20" bed ext. mounted:
with single bearing center ................................................................................................. 60-1/2 in. (1537 mm)
with live cone center .......................................................................................................... 58-1/4 in. (1480 mm)
Max. distance between spindle face and tailstock quill, optional 20" bed ext. mounted .............. 62 in. (1575 mm)
Swing over bed ........................................................................................................................... 18.5 in. (470 mm)
Swing over tool rest base ......................................................................................................... 14-1/4 in. (362 mm)
Indexing ................................................................................. 36 positions, positive locking, 10 degree increments
Swing over 20" bed extension in low position (optional accessory) ............................................ 36.6 in. (930 mm)
Headstock and Spindle:
Spindle taper ................................................................................................................................................... MT-2
Spindle thread, inboard .................................................................................................................. 1-1/4 in. x 8 TPI
Spindle thread, outboard ...................................................................................................................... 3/4"-16 (LH)
Spindle speed range .......................................................................................................... variable within 40-3200
Spindle speeds (RPM) ..................................................................................... 40-1200 (low) and 100-3200 (high)
Headstock spindle bore ................................................................................................................... 3/8 in. (10 mm)
Spindle direction ...................................................................................................................... forward and reverse
Headstock movement ................................................................................................................................... sliding
1
subject to local/national electrical codes
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
1 ............................................................................................................................... 15A
2 ................................................................................. 78 dB at 20 inches from motor
5
