Parts List - Icom ID-RP2 Service Manual

SECTION 4
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130009850 S.IC TC74LCX245FT (EL)
IC2 1130011731 S.IC µPD444008LLE-A12
IC3 1130011731 S.IC µPD444008LLE-A12
IC4 1130011360 S.IC HD74LVC14TELL
IC5 1140011870 S.IC HD6417750SF167
IC6 1130011731 S.IC µPD444008LLE-A12
IC7 1130011731 S.IC µPD444008LLE-A12
IC8 1130012730 S.IC AM79C973BVD\W
IC9 1130007030 S.IC TC7W08FU (TE12L)
IC10 1120002990 S.IC MAX3232CSE
IC11 1130012300 S.IC MBM29LV320TE-90TN/SC-1407
IC12 1130012310 S.IC MBM29LV160TE90TN/SC-1408
IC13 6910015300 S.DC LM2676S-3.3
IC14 1130012330 S.IC EPCS1SI8 / SC-1409
IC15 1130011710 S.IC EP1C6Q240C8
IC16 1130011420 S.IC µPD98409GN-LMU
IC17 1120002960 S.IC TC74AC541FT (EL)
IC18 1130006891 S.IC TC7S04FU (TE85R, F)
IC19 1140011420 S.IC EP1C6T144C7
IC20 1120002960 S.IC TC74AC541FT (EL)
IC21 1120002960 S.IC TC74AC541FT (EL)
IC22 1190001980 S.IC SN65LVDS391D
IC23 1120002960 S.IC TC74AC541FT (EL)
IC24 1140011410 S.IC EP1C6T144C8
IC25 1190001970 S.IC SN65LVDT33D
IC26 1190001970 S.IC SN65LVDT33D
IC27 1130012051 S.IC FT232BL
IC28 1130012051 S.IC FT232BL
IC29 1130009570 S.IC BR93LC46F-WE2
IC30 1130009570 S.IC BR93LC46F-WE2
IC33 1180002470 S.REG TA48018F (TE16L1,NQ)
IC34 1180002601 S.REG TA48015F (TE16L1,NQ)
IC35 1130011160 S.IC IDT2305-1DC
IC36 1130006551 S.IC TC7S08FU (TE85R, F)
Q1 1590001040 S.TR DTA113ZU T106
Q2 1590000430 S.TR DTC144EUA T106
Q3 1590000430 S.TR DTC144EUA T106
Q4 1590001040 S.TR DTA113ZU T106
D1 1790000700 DIO DSA3A1
D2 1710001190 DIO 1N5820
D3 1730002531 S.ZEN NNCD6.2G-T1
D4 1730002531 S.ZEN NNCD6.2G-T1
D5 1730002531 S.ZEN NNCD6.2G-T1
D6 1730002531 S.ZEN NNCD6.2G-T1
D7 1730002531 S.ZEN NNCD6.2G-T1
D8 1730002531 S.ZEN NNCD6.2G-T1
D13 1730002531 S.ZEN NNCD6.2G-T1
D19 1790000700 DIO DSA3A1
D20 1790000700 DIO DSA3A1
D21 1750000550 S.DIO 1SS355 TE-17
D22 1750000550 S.DIO 1SS355 TE-17
X1 6050010910 S.XTL CR-670 (25.000 MHz)
X2 6050011620 S.XTL SMD-49 (22.000 MHz)
X3 6050011030 S.XTL DMX-26S (32.768 kHz)
X5 6050011290 S.XTL CR-715 (6 MHz)
X6 6050011290 S.XTL CR-715 (6 MHz)
L1 6200010750 S.COL 931BS-220M=P3
L2 6200005741 S.COL ELJRE 47NG-F
L3 6200005741 S.COL ELJRE 47NG-F
L4 6190001561 S.COL CDRH5D18NP-101NC
R1 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R2 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R3 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R4 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R5 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R6 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R7 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R8 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R9 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R10 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R11 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R13 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)

PARTS LIST

DESCRIPTION M.
LOCATION
T 65.5/166.5
T 155/140.5
T 181/140.5
T 65.5/188.5
T 100/164.5
T 155/114.5
T 181/114.5
T 29/76.5
T 65.5/178
T 108.5/210
T 159.5/86
T 160.3/62.5
T 190/42.5
T 89/120.3
T 88.5/87
T 33/134
T 151.5/215.5
T 27/220.5
T 29/186
T 165.5/215.5
T 179.5/215.5
T 34/212.5
T 193.5/215.5
T 172.5/182
T 18.5/212.5
T 89.5/212.5
T
T 87.5/43
T
T 78.5/27
T 184.4/90
T 185.7/72.6
T 80/137
T 106.5/111.4
T 32/220.5
T 37.5/220.5
T 102.5/220.5
T 97.5/220.5
T 149/223
T 158/224.5
T 167/224.5
T 178.5/224.5
T 186.5/224.5
T 195/224.5
T 101.5/227
T 184.5/83.9
T 185.2/66.6
T 24/55.5
T 82.5/186.5
T 122/185.5
T
T 78.5/44
T 192.5/15
T 51/18.1
T 71.5/19.3
T 186.1/55.3
T 58/172.7
T 58/171
T 58/169.2
T 58/167.5
T 58/165.7
T 58/164
T 58/162.2
T 58/160.5
T 12.5/76
T 65.5/162
T 78.2/168
T 78.2/166.5
T 78.2/165
[MAIN UNIT]
H/V REF ORDER
NO. NO.
R14 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R15 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R16 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R18 7030003860 S.RES ERJ3GE JPW V
R19 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R20 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R21
R22 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ
7030010900 S.RES ERJ3GEYJ 750 V (75 Ω)
R23
R24 7030003570 S.RES ERJ3GEYJ 123 V (12 kΩ)
7030010900 S.RES ERJ3GEYJ 750 V (75 Ω)
R25
R26 7030005420 S.RES ERJ3GEYJ 202 V (2 kΩ)
7030010890 S.RES ERJ3EKF 49R9 V (49.9 Ω)
R27
R28 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R29 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R30 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R34 7030003860 S.RES ERJ3GE JPW V
R35 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R36 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R37 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R38 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R39 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
62/43
R40 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R41 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
53/27
R42 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030010890 S.RES ERJ3EKF 49R9 V (49.9 Ω)
R43
7030010890 S.RES ERJ3EKF 49R9 V (49.9 Ω)
R44
R45 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R46 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R47
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R48
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R49
R50 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R52 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R54 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R56 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R60 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R61 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R62 7030003860 S.RES ERJ3GE JPW V
R63 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R64 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R65 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R66 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R67 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R68 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R69 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R70 7030003860 S.RES ERJ3GE JPW V
R71 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R72 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R73 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R74 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R75 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R76 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R77 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R78 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R79 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
53/44
R80 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R82 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R83 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R85 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R88 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R89 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R90 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R91 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R94 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R95 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R96 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R97 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R98 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R99 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R100 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R101 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R102 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R103 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R104 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R105 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R106 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R107 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R108 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
B - 4 - 1
DESCRIPTION M.
LOCATION
T 78.2/163.5
T 78.2/161.5
T 78.2/160
T 78.2/158.5
T 74.7/163.5
T
T 26.5/95
T 32.5/59
T 24.5/59.5
T 30.5/21
T 35.5/59
T 30.5/39
T 37.5/56
T
T 60/188.5
T 78.2/171.5
T 78.2/173
T 78.2/174.5
T 78.2/176
T 78.2/177.5
T 77/182.5
T 78.2/169.5
T 48.5/73.5
T 48.5/72
T 48.5/69
T 48.5/67
T 48.5/63.5
T 48.5/65
T 48.5/70.5
T 38.5/59
T
T
T 71/188.7
T 90.8/195
T 93.6/195
T 96.3/195
T 96.5/186
T 100/186
T 103/186
T 101.5/189.5
T 89/143
T 90.5/143
T 99/143
T 103/143
T 104.5/143
T 108/186
T 109.5/186
T 110.4/216
T 111/186
T 113/186
T 116/184
T 121.5/178.5
T 106/143
T 107.5/143
T 109/143
T 110.5/143
T 116.2/143
T 114.7/143
T 113.2/143
T 170/94.5
T 146.5/85.5
T 125/174
T 125/172.5
T 125/175.5
T 121.5/171
T 121.5/169.5
T 121.5/168
T 121.5/166.5
T 93/115.8
T 103.6/112.1
T 85/115.8
T 64/104.5
T 64/99.5
T 64/101
T 64/103
T 35.5/111
T 37/111
T 89.5/63.5
T 86.5/63.5
T 92.5/63.5
T 91/63.5
T 64.5/85
T 64.5/83.5
S.=Surface mount
H/V
25/95
37/59
40/59
40/55
