SECTION 4 PARTS LIST
[FRONT UNIT]
REF ORDER
NO. NO.
R1 7210000140 VARIABLE
R2 7210000690 VARIABLE
S1 2260001260 SWITCH
SP1 2510000040 SPEAKER
W1 8900008620 CABLE
WS1 8600033720 M.OTHER
WS2 8600033730 M.OTHER
[MIC UNIT]
REF ORDER
NO. NO.
C1 4030006860 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4030006860 S.CERAMIC
J1 6510004820 CONNECTOR
J2 6510003410 CONNECTOR
WS1 8600036390 M.OTHER
EP1 0910050531 PCB
[SWITCH UNIT]
REF ORDER
NO. NO.
J1 6510003430 CONNECTOR
J2 6510003390 CONNECTOR
S1 2230000380 SWITCH
W8 6910001030 JUMPER
WS1 8600036400 M.OTHER
EP1 0910051070 PCB
DESCRIPTION
RK1631110D9DA (10KA)
RK1631110D9CA (10KB)
SW-118 (SDDFA3)
C065K12I0810
OPC-844
FX1623 P02FR
FX1623 P03FR
DESCRIPTION
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
FM14RS-7SS
B05B-EH-S
FX2169 P01*P02MI
B 5201A
DESCRIPTION
B07B-EH-S
B03B-EH-S
SPUE44067A
IPS-1041-4
FX2169 P01*P02SW
B 5251
[LED UNIT]
REF ORDER
NO. NO.
R1 7030003430 S.RESISTOR
R2 7030003430 S.RESISTOR
R3 7030003430 S.RESISTOR
R4 7030003430 S.RESISTOR
R5 7030003430 S.RESISTOR
R6 7030003430 S.RESISTOR
R7 7030003430 S.RESISTOR
J1 6510003440 CONNECTOR
DS1 5040002450 LED
DS2 5040002450 LED
DS3 5040002460 LED
DS4 5040000650 LED
DS5 5040000640 LED
DS6 5040000650 LED
DS7 5040001360 LED
WS1 8600036410 M.OTHER
EP1 0910050541 PCB
[LOGIC UNIT]
REF ORDER
NO. NO.
IC1 1140001480 S.IC
IC2 1130004080 S.IC
IC4 1130004712 IC
IC5 1130004790 S.IC
IC6 1130004011 S.IC
IC7 1130004921 S.IC
IC8 1110001501 S.IC
IC9 1180000970 S.IC
IC10 1130002390 S.IC
IC11 1130002390 S.IC
IC12 1110000960 S.IC
IC13 1110000960 S.IC
IC14 1110002420 S.IC
IC15 1110003090 IC
IC16 1110000960 S.IC
IC17 1110000960 S.IC
IC18 1110000960 S.IC
IC19 1110000960 S.IC
IC20 1130005640 S.IC
IC21 1110001590 S.IC
Q1 1590000680 S.TRANSISTOR DTC114EUA T106
Q3 1590000680 S.TRANSISTOR DTC114EUA T106
Q4 1590000680 S.TRANSISTOR DTC114EUA T106
Q5 1590001600 S.TRANSISTOR UMD3 TL
Q6 1590000680 S.TRANSISTOR DTC114EUA T106
Q7 1590000680 S.TRANSISTOR DTC114EUA T106
Q8 1590000680 S.TRANSISTOR DTC114EUA T106
Q9 1590000680 S.TRANSISTOR DTC114EUA T106
Q10 1590000680 S.TRANSISTOR DTC114EUA T106
Q11 1590001450 S.FET
Q12 1590000680 S.TRANSISTOR DTC114EUA T106
Q13 1590001450 S.FET
Q14 1590000680 S.TRANSISTOR DTC114EUA T106
D1 1790001200 S.DIODE
D2 1790001200 S.DIODE
D3 1790001200 S.DIODE
4 - 1
DESCRIPTION
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
B08B-EH-S
TLG208
TLG208
TLR208
TLY205
TLR205
TLY205
TLG205
FX2169 P01*P02LE
B 5202A
DESCRIPTION
µPD78213GC-AB8
µPD71055GB-3B4
NM27C256Q150
TC74HC374AF
TC74HC138AF
TC74HC04AF(TP1)
S-80845ALUP-EA9-T2
AN78L05M-(E1)
µPD4049UBG
µPD4049UBG
NJM4558M-T1
NJM4558M-T1
NJM2073M-T1
LA4425A
NJM4558M-T1
NJM4558M-T1
NJM4558M-T1
NJM4558M-T1
TC4W53F (TE12L)
TA75393F (TP1)
2SJ144-GR (TE85R)
2SJ144-GR (TE85R)
MA6S121(TX)
MA6S121(TX)
MA6S121(TX)
S.=Surface mount
