Indicator Self-Test - Compaq ProLiant Storage System User Manual

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Indicator
On-Line*
Drive Access
Drive Failure*
* Requires system software or intelligent controller support

Indicator Self-Test

When the ProLiant Storage System is first powered on, or when a new drive is
plugged in, the drive tray indicators turn on one at a time, from left to right.
Then they all turn off at the same time. This informs the user that the lights are
working. Also, when first powered on, the front bezel Service Required
indicator turns on and off.
Table 4-3
Drive Tray Indicator Definitions
OFF
The drive is inactive
The drive is not
being accessed
No failure
ON
The drive is configured and
recognized by the operating
system or intelligent
controller
The drive is being accessed
The drive has failed and is
ready for removal and
replacement
Compaq ProLiant Storage System User Guide
4-5
Blinking
Volume
reconstruction is
under way
--
--
